Summary of Contents for Netzerotools M-Series
- Page 1 M-Series 432-0003-00-12 Installation Guide Revision 140 January 2012 www.netzerotools.com...
- Page 2 Flir M-324L M 324 L Thermal Night Vision Infrared Camera Maritime ______________________________________________________ Flir M-324XP M 324 XP Thermal Night Vision Infrared Camera Maritime _________________________________________________________ Flir M-612L M 612 L Thermal Night Vision Infrared Camera Maritime ______________________________________________________ Flir M-618CS M 618 CS Thermal Night Vision Infrared Camera Maritime _________________________________________________________ Flir M-625L M 625 L Thermal Night Vision Infrared Camera Maritime ______________________________________________________...
- Page 3 The M-Series thermal imaging system is controlled by US export laws. There are special versions of this system that are approved for international distribution and travel. Please contact FLIR Systems if you have any questions.
-
Page 4: Table Of Contents
Cleaning the JCU ......................... 17 Cleaning the Camera Optics ......................17 Cleaning the Camera Body ......................18 Specifications......................18 External Standards....................19 Acronyms........................20 Feature Comparison of M-Series Models..............22 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com... - Page 5 Contents This page is intentionally blank. 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com...
-
Page 6: Chapter 1 Installing M-Series Systems
Installing M-Series CHAPTER 1 Systems This manual describes the installation of the M-Series camera. If you need help or have additional questions, please call to speak with our support experts; see the phone numbers on the back cover of this manual. -
Page 7: Additional References
• Parts list and other reference information Additional References Your M-Series camera comes with a complete documentation set on a CD (FLIR Doc. # 432-0003-00-16) that includes this manual as well as others. All documents are in PDF format and can be viewed with Adobe Acrobat Reader: •... -
Page 8: Warnings And Cautions
Caution: Be careful not to leave fingerprints on the M-Series camera optics. Caution: The M-Series requires a power supply of 12 – 24V DC nominal, 5 Amp maximum. Absolute voltage range: 10 – 32V DC. Operating the camera outside of the specified input voltage range or the specified operating temperature range can cause permanent damage. -
Page 9: Installation Overview
• Six M6 x 60 stainless steel-threaded studs with washers and nylock nuts or acorn nuts, for attaching the M-Series camera body. The length required depends on the mounting platform thickness. See “Camera Mounting Options” on page 8 for more details. -
Page 10: Installation Planning
You should consider a number of factors in planning the installation of the M-Series camera and JCU. General Location Considerations First determine a good location for mounting the M-Series camera unit and the JCU. The camera requires at least three connections: • One for power •... -
Page 11: Camera Mounting Options
Upright Installation In most installations, the M-Series is mounted upright on top of a mounting surface, with the pan/tilt base below the camera; this is known as the ball up orientation. Optionally, the unit (unless it is the M-618CS model) can be hung upside down or ball down. -
Page 12: Camera Video Options
M-Series video output. Make sure the area you choose leaves enough room for the cable under the JCU (refer to the M-Series ICD for dimensions). The magnetic compass safe distance for the JCU is 55 cm (21.7 in). -
Page 13: Multiple Jcu/Camera Installations
Installing M-Series Systems When selecting a mounting location for the M-Series, consider cable lengths and cable routing. Ensure the cables are long enough, given the proposed mounting locations and cable routing requirements, and route the cables before you install the components. -
Page 14: Physical Installation
Installing the Camera Unit With the exception of theM-618CS model, which must be installed in the ball-up orientation, the M-Series camera can be mounted in an upright or upside down position. Two O-rings are provided for use during the camera installation. You should choose the one most appropriate for your configuration: •... -
Page 15: Installing The Joystick Control Unit (Jcu)
(OSD) menu system is used to configure the camera for the ball-down position. See the M-Series Operator’s Manual for details. When the camera is mounted upside down (ball down), the camera base must be rotated backwards, to point toward the stern of the vessel. - Page 16 If you intend to mount the JCU to a panel of 0.79 cm (0.31 in) thickness or less, remove the clamps from the mounting screws, turn them around and thread them back onto each of the four screws. In this configuration, the clamp foot faces the 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com...
-
Page 17: Electrical Connections
JCU and camera. This can be accomplished simply by pressing an ungloved finger across the Ethernet RJ45 connector of the cable for a few seconds. 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com... -
Page 18: Proper Grounding
2 m (6 ft). For longer cabling, the camera must be connected to a vessel ground using a low-resistance grounding strap connected directly to one of the M6 mounting bolts on the camera base as shown in the M-Series ICD (432-0003-00). -
Page 19: Video Connections
RJ45 waterproof enclosure connector (FLIR PN 4115028). The Ethernet network cable should be rated for use with PoE devices (IEEE802.3af) and should be 8-conductor T568B, Ethernet, double-shielded for EMI considerations (FLIR PN 308-0163-25 or equivalent). 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com... -
Page 20: Chapter 2 M-Series Reference
• A glossary of acronyms • A table comparing features of various M-Series models M-Series Maintenance The M-Series components are designed for years of rugged, trouble-free use. When the system is not in use, keep the JCU cover in place for additional protection. -
Page 21: Cleaning The Camera Body
If you have a problem with your thermal camera, do not attempt to repair it yourself. The M-Series camera is a sealed unit and can not be opened or serviced in the field. Consult your installation dealer or FLIR Systems Inc. for repair information. -
Page 22: External Standards
Wind 100 knot (115.2 mph) IEC 60945 External Standards Table 2.2 lists other sources of information and standards definitions that may be useful during the installation of your M-Series camera. External References TABLE 2.2 Standard Description ANSI/SCTE 01 2006 “F”... -
Page 23: Acronyms
Daylight TV, used to reference visible-band cameras Export Administration Regulations Electromagnetic Interference Flat Field Correction FLIR Forward Looking Infrared Field of View Frames per Second (refresh rate) HFoV Horizontal Field of View Interface Control Document International Electrotechnical Commission 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com... - Page 24 National Television System Committee Phase Alternating Line Pan/Tilt Power over Ethernet SCTE Society of Cable Telecommunications Engineers Software Developer’s Kit UPnP Universal Plug and Play Volts, Direct Current Visible (visible-band camera reference) 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com...
-
Page 25: Feature Comparison Of M-Series Models
M-Series Reference Feature Comparison of M-Series Models The following table lists each M-Series model and its supported features. Each model is available in four variations, identified by a unique part number: • <9 hz thermal frame refresh rate (FPS), NTSC video format •... - Page 26 640 x 480 30 Hz 18° 2x and 4x M-618CS 432-0003-32-00S Dual 640 x 512 <9 Hz 18° 2x and 4x 432-0003-32-00 Dual 640 x 512 25 Hz 18° 2x and 4x 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com...
- Page 27 M-Series Reference This page is intentionally blank. 432-0003-00-12 Rev 140 — M-Series Installation Guide www.netzerotools.com...
- Page 28 NOTES www.netzerotools.com...
- Page 29 www.netzerotools.com...
