- Page 1 Service Manual Audio MPixx VP6200/30GB GDR9900 Zusätzlich erforderliche Unterlagen für den Komplettservice Additionally required Service Documents for the Complete Service Service Manual Sicherheit Safety Materialnr./Part No. 720108000001 Materialnummer/Part Number 720107739500 Änderungen vorbehalten/Subject to alteration H-S43 0106 • Printed in Germany http://www.grundig.com...
-
Page 2: Table Of Contents
GRUNDIG Service MPixx VP 6200/30GB Es gelten die Vorschriften und Sicherheitshinweise The regulations and safety instructions shall be valid gemäß dem Service Manual "Sicherheit", Material- as provided by the "Safety" Service Manual, part nummer 720108000001, sowie zusätzlich die eventu- number 720108000001, as well as the respective ell abweichenden, landesspezifischen Vorschriften! national deviations. -
Page 3: Technische Daten
We expressly point out that only operating software authorized by Wir weisen ausdrücklich darauf hin, dass nur von GRUNDIG frei- GRUNDIG is allowed. If a failure is caused by an operating software gegebene System-Software zulässig ist. Wurde als Fehlerursache which has been downloaded from not authorized sources, indepen-... -
Page 4: Bedienhinweise
Bedienhinweise Dieses Kapitel enthält Auszüge aus der Bedienungsanleitung. Weitergehende Informationen entnehmen Sie bitte der gerätespezifischen Bedienungsanleitung, deren Materialnummer Sie in der Ersatzteilliste finden. - Page 5 GRUNDIG Service MPixx VP 6200/30GB 1 - ...
- Page 6 GRUNDIG Service MPixx VP 6200/30GB 1 - 6...
-
Page 7: Operating Hints
Operating Hints This chapter contains excerpts from the operating instructions. For further particulars please refer to the appropriate user instructions the part number of which is indicated in the relevant spare parts list. - Page 8 GRUNDIG Service MPixx VP 6200/30GB 1 - ...
- Page 9 GRUNDIG Service MPixx VP 6200/30GB 1 - ...
-
Page 10: Ausbauhinweise
GRUNDIG Service MPixx VP 6200/30GB Ausbauhinweise / Disassembly Hints Gehäuse öffnen / Open the cabinet: Schrauben/screws A Rastnasen/latches B 1 - 10... -
Page 11: Schaltpläne Und Platinenabbildungen
Schaltpläne und Platinenabbildungen / Circuit Diagrams and Layout of the PCBs Blockschaltplan / Block Diagram 12MHz LCD MODULE CMOS_FLASH USB2.0 CONTROLLER IDE_D[ 0:15] ARM_D[ 0:15] ,ARM_A[ 0:19] MAIN PROCESSOR SDR_DO[ 0:15] ,SDR_A[ 0:14] TMS320DM320ZHK IPD[ 0:7] SDRAM VIDEO DECODER 24.576MHz SDRAM CPD[ 0:7] 48MHz... -
Page 12: Netzteil
GRUNDIG Service MPixx VP 6200/30GB Netzteil / Power Supply PLUS1 +3.3V CHARGE_PIN DC_VCC +5V 100K 5% 1005 100K 5% 1005 POWER_SW RESET# 100K 5% 1005 RESET# 100pF 25V 1005/NC ADT_IN ADT_IN V_max 4.7K 1% 1005 1K 5% 1005 100K 5% 1005... - Page 13 GRUNDIG Service MPixx VP 6200/30GB Netzteil / Power Supply 100K 5% 1005 POWER_ON 4.7K 1% 1005 +3.3V RP41 (500mA) 100 ohm 5% 1005 USB_3.3V 1uF 6.3V 1005 USB_ENABLE RP10 100K 5% 1005 +1.8V (400mA) RP13 255K 1% 1005 100uF 6.3V TANT_B (TMCNBOJ107MTRF)
-
Page 14: Peripherie I/O
GRUNDIG Service MPixx VP 6200/30GB Prozessor / Processor: Peripherie I/O / Peripherals I/O +3.3V +1.8V 80 ohm 1A 1608 +VCC_PLL 100nF 25V 1005 100nF 25V 1005 100nF 25V 1005 100nF 25V 1005 100nF 25V 1005 CP29 100nF 25V 1005 +VCC_SDR... - Page 15 GRUNDIG Service MPixx VP 6200/30GB Peripherie I/O / Peripherals I/O +3.3V RNP1 +3.3V +3.3V 80 ohm 1A 1608 GIO14 GIO10 GIO40 GIO15 +VCC_SDR GIO37 GIO11 1K 100mA 1608(SBK160808T102V-2) CP27 CP28 1uF 6.3V 1005 10nF 16V 1005 +3.3V 47K 5% PULL-UP/DOWN REG 1608X5 RNP2 +3.3V...
-
Page 16: Bus I/O
Prozessor / Processor: RNP5 +3.3V ARM_D12 ARM_D11 ARM_D10 Bus I/O ARM_D14 ARM_D8 ARM_D15 ARM_D13 ARM_D9 47K 5% PULL-UP/DOWN REG 1608X5 RNP6 +3.3V ARM_D0 ARM_D[15:0] ARM_D15 ARM_D3 ARM_D7 SDR_DQ[31:0] ARM_D15 SDR_DQ31 ARM_D14 ARM_D1 ARM_D4 SDR_DQ31 ARM_D14 SDR_DQ30 (MSB) ARM_D13 SDR_DQ30 ARM_D13 SDR_DQ29 ARM_D12 ARM_D5... -
Page 17: Speicher
GRUNDIG Service MPixx VP 6200/30GB Speicher / Memory SDR_A[14..0] SDR_DQ[31..0] SDR_A0 SDR_DQ0 SDR_A1 SDR_DQ1 SDR_A2 SDR_DQ2 SDR_A3 SDR_DQ3 SDR_A4 SDR_DQ4 SDR_A5 SDR_DQ5 SDR_A6 SDR_DQ6 SDR_A7 SDR_DQ7 +3.3V SDR_A8 SDR_DQ8 SDR_A9 SDR_DQ9 SDR_A10 SDR_DQ10 DQ10 SDR_A11 SDR_DQ11 DQ11 SDR_A14 SDR_DQ12 DQ12... -
Page 18: Lcd-Spannungsversorgung
GRUNDIG Service MPixx VP 6200/30GB LCD-Spannungsversorgung / LCD Power Supply LCD VGL/VGH POWER 470nF 25V 1005 470nF 25V 1005 BAT54S/SOT BAT54S/SOT 1uF 6.3V 1005 -10V 470nF 25V 1005 +3.3V BAT54S/SOT 10uF 10V 3216 LCD_AVDD 3.3uH (LLF4017/(2RH2D11)) MBRM120/SOD123 LLF4017T-4R7NR80 1000nF 16V 2012 4.7uF 10V 2012... -
Page 19: Lcd-Datenschnittstelle
GRUNDIG Service MPixx VP 6200/30GB LCD-Datenschnittstelle / LCD Data Interface HSYNC_LCD 10 ohm 5% 1005 HSYNC VSYNC_LCD 10 ohm 5% 1005 VSYNC 10 ohm 5% 1005 DATACLK VCLK RESET_LCD# 10 ohm 5% 1005 RESET_LCD R200 10 ohm 5% 1005/NC RESET#... -
Page 20: Cameramodul
GRUNDIG Service MPixx VP 6200/30GB Cameramodul / Camera Module +2.8V 2.8_VI IRLML6401TR (SOT-23) 80 ohm 1A 1608 100K 5% 1005 10uF 6.3V TANT_P CAMERA_CLK_ON 1K 5% 1005 2.8_VI 1K 100mA 1005 CMOS_MCLK 10pF 50V 1005/NC 48MHz,JOC-7528, 2.8V, 7*5 18pF 50V 1005 +2.8V... -
Page 21: Videodecoder
Videodecoder +1.8V +1.8AV 80 ohm 1A 1608 1uF 6.3V 1005 1uF 6.3V 1005 CV20 1uF 6.3V 1005 100uF 6.3V TANT_B 100nF 25V 1005 Active Low Standby Mode +3.3V +1.8AV Preserves the value 47K 5% 1005 100nF 25V 1005 RV27 22 ohm 5% 1005 VDEC_ENABLE or 47nF/10V 1005 37.4ohm 1% 1005... -
Page 22: Audio-Eingang
Audio-Eingang / Audio Input VCC_FM LINE IN BLOCK (+VIDEO) FM BLOCK VCC_FM AUDIO_MCLK CVBS_IN +3.3V AUDIO_MCLK 4.7K 1% L_IN 1K 100mA 1uF 6.3V 4.7K 1% 47pF 50V FM_ANT TC-38-363-06 VIEDO AUDIO I N ENABLE RA47 0 ohm 5% 1uF 6.3V FM_LIN DATA OUT_L... -
Page 23: Audio Ausgang
GRUNDIG Service MPixx VP 6200/30GB Audio-Ausgang / Audio Output 2.7uH LQH31MN2R7K CVBS 240 ohm 200mA 2.7uH LQH31MN2R7K +3VA CA10 120pF 50V RA10 CA11 LOUT RA11 75 ohm 5% 1K 100mA 470nF 25V OPA353NA/250 CA15 RA12 CA14 47K 5% 560pF 50V... -
Page 24: Usb-Teil
USB-Teil / USB Section USB_3.3V 100nF 25V 1005 80 ohm 1A 1608 +3.3V +3.3V USB_3.3V GPIO1 R124 R125 10K 5% 1005 10K 5% 1005 CBLID 100nF 25V 1005 GPIO1 VBUS INTRQ R126 22 ohm 5% 1005 20K 5% 1005 IDE_IRQ 100nF 25V 1005 DCS0 R127... -
Page 25: Ide-Festplattentreiber
IDE-Festplattentreiber / IDE Hard Disk Driver U19A +3.3V ARM_A21 IDE_CS0# SN74LVC00APWR 4.7K 1% 1005 IDE HARD DRIVER U19B IDE_CS1# ARM_A22 ARM_D[15:0] ARM_D0 ARM_D1 IDE_D0 SN74LVC00APWR ARM_D2 IDE_D1 ARM_D3 IDE_D2 ARM_D4 IDE_D3 ARM_D5 IDE_D4 GND_8 GND_41 ARM_D6 IDE_D5 ARM_A[22:0] ARM_D7 IDE_D6 ARM_D8 IDE_D7 ARM_A21... -
Page 26: Bedien-Teil
Bedien-Teil / Control Section BAT+ +3.3V +3.3V R174 +3.3V 100K 1% 1005 R173 1K 5% 1005/NC 1nF 50V 1005 PWDWN R177 MTHOLE_A 100nF 25V 1005 150K 1% 1005 SN74LVC1G17DBVR R175 R176 1K 5% 1005/NC 47K 5% 1005 DM320 MTHOLE_A KEY BLOCK +3.3V MTHOLE_A R178... -
Page 27: Leiterplatte
Leiterplatte / PCB... -
Page 29: Ersatzteilliste
GRUNDIG Service MPixx VP 6200/30GB Ersatzteilliste NUR FÜR INTERNEN GEBRAUCH AUDIO Spare Parts List FOR INTERNAL USE ONLY 11 / 2005 MPIXX VP 6200/30GB MATERIAL-NR. / PART NO.: 774011045100 BESTELL-NR. / ORDER NO.: GDR9900 POS. NR. ABB. MATERIAL-NR. ANZ.
