Summary of Contents for Telefunken D40U300A4CW
- Page 1 LCD TV BEDIENUNGSANLEITUNG INSTRUCTION MANUAL MODE D‘EMPLOI ISTRUZIONI PER L‘USO D40U300A4CW...
- Page 2 TELEFUNKEN ® Markenlizenz: TELEFUNKEN ® licensed by: TELEFUNKEN Licenses GmbH TELEFUNKEN Licenses GmbH Vertrieb: Vestel Germany GmbH, Imported by: Vestel Germany GmbH, D-85748 Garching bei München D-85748 Garching/Munich 1 Die Marke TELEFUNKEN ist eine eingetragene Marke der TELEFUNKEN Licenses GmbH.
-
Page 3: Table Of Contents
Contents Safety Information ..........34 Markings on the Product........34 Environmental Information........35 Features ...............35 Accessories Included..........36 Standby Notifications ..........36 TV Control Buttons & Operation ......36 Inserting the Batteries into the Remote ....36 Connect Power ............37 Antenna Connection ..........37 Notification ............37 Specification ............37 Remote Control ............38 Connections............39 Switching On/Off ...........40... -
Page 4: Safety Information
• Ensure that no open flame sources, such as lit Safety Information candles, are placed on top of the TV. • To prevent injuries, this TV must be securely CAUTION attached to a wall by carefully following the RISK OF ELECTRIC SHOCK instructions (if the option is available). -
Page 5: Environmental Information
consumption accordingly. If you like to set the Backlight to a fixed value set as Custom and adjust the Backlight (located under the Energy Saving WARNING setting) manually using Left or Right buttons on the Do not ingest the battery, Chemical Burn remote. -
Page 6: Accessories Included
• PLL (Frequency Search) TV Control Buttons & Operation • PC input • Game Mode (Optional) • Picture off function • Ethernet (LAN) for Internet connectivity and service • 802.11n built in WIFI Support • Audio Video Sharing • HbbTV Accessories Included 1. -
Page 7: Connect Power
Connect Power Specification IMPORTANT: The TV set is designed to operate on PAL BG/I/DK/LL’ TV Broadcasting 220-240V AC, 50 Hz socket. After unpacking, allow SECAM BG/DK the TV set to reach the ambient room temperature VHF (BAND I/III) - UHF before you connect the set to the mains. -
Page 8: Remote Control
Remote Control Source: Shows all available broadcast and content sources Netflix: Launches the Netflix application, if this feature is supported by your TV YouTube: Launches the YouTube application Play: Starts to play selected media No function Rapid reverse: Moves frames backwards in media such as movies Language: Switches between sound modes (analogue TV), displays and changes audio/subtitle... -
Page 9: Connections
Connections Connector Type Cables Device NOTE: When connecting a device via the YPbPr or Side Mini Scart AV input, you must use the Connection connection cables to enable Mini Scart (bottom) connection. See the illustrations adapter cable on the left side. | To enable PC/YPbPr audio, you will need to use the Back Audio inputs Connection... -
Page 10: Switching On/Off
Direct, Single Satellite Cable or DiSEqC switch by Switching On/Off using “ ” or “ ” buttons. To Switch the TV On • Direct: If you have a single receiver and a direct Connect the power cord to a power source such as a satellite dish, select this antenna type. -
Page 11: Media Playback Via Usb Input
Note: Do not turn off the TV while initializing first time Media Browser Menu installation. Note that, some options may not be available You can play photo, music and movie files stored on a depending on the country selection. USB disk by connecting it to your TV. Connect a USB Using SatcoDX Feature disk to one of the USB inputs located on the side of You can perform SatcoDX operations using the... -
Page 12: E-Manual
other cables between the TV and the audio system (A/V receiver or speaker system). When ARC is active, TV does not mute its other audio outputs automatically. So you need to decrease TV volume to zero manually, if you want to hear audio from connected audio device only (same as other optical or co-axial digital audio outputs). -
Page 13: Tv Menu Contents
TV Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode Mode can be set to one of these options: Cinema, Game, Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen. - Page 14 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
-
Page 15: Conditional Access
System - Options Menu Contents Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options. - Page 16 This setting configures the power up mode preference. Last State and Standby Power Up Mode options are available. Virtual Remote Enable or disable the virtual remote feature. With this setting you can enable and disable CEC functionality completely. Press Left or Right button to enable or disable the feature.
-
Page 17: General Tv Operation
Internet Lock: If this option is set to ON, the open General TV Operation browser application in the portal will be disabled. Set Using the Channel List to OFF to release the application again. The TV sorts all stored stations in the Channel List. Set PIN: Defines a new PIN number. -
Page 18: Teletext Services
Now/Next Schedule TV by pressing the OK to continue with the reboot operation. Navigate (Directional buttons): Press the Directional buttons to navigate through the channels 3 AM search and upgrade mode and programmes. Your TV will search for new upgrades at 3:00 o’clock if Options (OK button): Displays event options. -
Page 19: Pc Input Typical Display Modes
PC Input Typical Display Modes AV and HDMI Signal Compatibility The following table is an illustration of some of the Source Supported Signals Available typical video display modes. Your TV may not support all resolutions. SECAM Index Resolution Frequency NTSC4.43 640x350 85Hz (SCART) -
Page 20: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Video Codec Resolution Bit Rate Container MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG MPEG1/2 transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), 1080Px2@30fps, MPEG4 40Mbps... -
Page 21: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Audio Codec Sample rate Bit Rate Container MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 32Kbps ~ MPEG1/2 Layer1 16KHz ~ 48KHz MPEG transport stream (.ts, .trp, .tp), MPEG program stream 448Kbps (.DAT, .VOB, .MPG, .MPEG), WAV (.wav) MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 8Kbps ~... -
Page 22: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 72Hz 75Hz 56Hz 60Hz 66Hz 70Hz 640x480 þ þ 800x600 þ þ... -
Page 23: Advanced Settings
Connectivity network wall socket Wired Connectivity To Connect to a Wired Network • You must have a modem/router connected to an active broadband connection. • Ensure that Nero Media Home software is installed to your PC (for Audio Video Sharing function). See “Nero Media Home Installation”... -
Page 24: Other Information
If the selected network is protected with a password, please enter the correct key by using the virtual Broadband keyboard. You can use this keyboard via the directional connection buttons and the OK button on the remote control. Wait until the IP address is shown on the screen. This means that the connection is now established. -
Page 25: Invalid Domain
Then press the Source button on the remote and connect to the internet. Contact your internet service switch to Wireless Display source. provider and request information on how to connect a different device, such as your TV, to the internet. A screen appears stating that the TV is ready for connection. -
Page 26: Internet Portal
If you select the media type as Videos and choose 8. Click the Install button. The installation begins a device from the selection menu. Then select the and finishes automatically. A progress bar will folder with video files in it on the next screen and all indicate the state of the installation process. -
Page 27: Hbbtv System
HBBTV System Internet Browser HbbTV (Hybrid Broadcast Broadband TV) is a To use the internet browser, enter the portal first. Then new industry standard that seamlessly combines launch the Internet application on the portal. TV services delivered via broadcast with services (*) The appearance of the internet browser logo may change delivered via broadband and also enables access In the initial screen of the browser, the thumbnails of... -
Page 28: Smart Center
Smart Center Smart Center is a mobile application running on iOS and Android platforms. With your tablet or phone, you can easily stream your favourite live shows and programmes from your smart TV. Also; you can launch your portal applications, use your tablet as a remote control for your TV and share media files. - Page 29 FollowMe TV Feature (if available) PORTAL: This tab displays the Portal applications in scrollable view. Unless FollowMeTV (if available) is Tap on the FOLLOW ME TV widget located at the active, the selected application will be displayed on bottom left of the screen of your mobile device to your TV screen.
- Page 30 Requirements 1. Smart TV 2. Network connection 3. Mobile Device based on Android or iOS platform (Android OS 4.0 or higher; IOS 6 or higher version) 4. Smart Center app.(to be found on online application stores based on Android and iOS platforms) 5.
