MODEL 721.37060700
DIVISION 20
BASIC FIELD MANUAL
FOR
UPRIGHT VACUUM CLEANER
MODEL 721.37060700
July , 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 721.37060700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sears 721.37060700

Summary of Contents for Sears 721.37060700

  • Page 1 MODEL 721.37060700 DIVISION 20 BASIC FIELD MANUAL UPRIGHT VACUUM CLEANER MODEL 721.37060700 July , 2007...

  • Page 2: Table Of Contents

    CONTENTS MODEL 721.37060700 BEFORE SERVICING THE UNIT, READ THE “SAFETY PRECAUTIONS” IN THIS MANUAL. MODEL 721.37060700 MECHANICAL SERVICE INFORMATION TABLE OF CONTENTS 1. SAFETY PRECAUTION ..............................3 2. DESCRIPTION / SPECIFICATIONS …………....................... 4 3. DISPLAY LED ………………………….…........................5 4. DISASSENBLY ……………………………..………....................6 - 14 5.

  • Page 3: Safety Precaution

    1. SAFETY PRECAUTIONS. MODEL 721.37060700 BEFORE OPERATING VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Pre Filter (Motor Safety Filter) 3. Avoid suction such materials as : 1) This filter is reusable. 1) Liquid or wet dust : 2) Never use the vacuum cleaner without filter.

  • Page 4: Description / Specifications

    2. DESCRIPTION / SPECIFICATIONS MODEL 721.37060700 DESCRIPTION Wand Handle Controls Carpet Floor Hose Handle Release Wand Button Dust Bin Release Button Carry Handle Quick Release Cord Dust Tank Hanger 30 ft. Cord Bottom Plate Carpet Height Power Level Release Indicators...

  • Page 5: Display Led

    3. DISPLAY LED MODEL 721.37060700 POWER ON/OFF ADJUSTING THE PILE HEIGHT Press the right foot pedal to adjust the pile 1. Plug the power cord into a proper outlet. height. Each press will lower or raise the agitator one notch.

  • Page 6: Disassenbly

    4. DISASSEMBLY MODEL 721.37060700 NOTE: Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power supply cord from the wall outlet. Almost all of the parts of this vacuum cleaner 3) Press the wand release...
  • Page 7 4. DISASSEMBLY MODEL 721.37060700 2. Wheel Assembly replacement 6) Press the left foot pedal and turn vacuum cleaner over, push the latch on the Head to the right and then the hose can be removed. 1) Remove the C clip by using a straight screwdriver and remove Wheel Assembly.
  • Page 8 4. DISASSEMBLY MODEL 721.37060700 4. Head Cover replacement. 5. PCB ASSEMBLY DISPLAY REPLACEMENT 1) Rotate the two cover retainers to unlock the agitator cover. Height Adjustment Power LED PCB LED PCB Assembly Assembly LED PCB Assembly 1> LED PCB Assembly Display replacement.
  • Page 9 4. DISASSEMBLY MODEL 721.37060700 6. Agitator Motor replacement 7. Micro Switch replacement 1) Remove the agitator and belt as shown on 1) Remove the 1 screw and disconnect the 2 page 15. leads and remove the Micro Switch. 2) Remove the 4 screws and pull out the Bracket.

  • Page 10: Motor Replacement

    4. DISASSEMBLY MODEL 721.37060700 9. Lever Selector Replacement 1) Remove the 2 screws and remove the Lever Selector to this direction shown. 11. Motor Replacement 1) Open the HEPA Filter cover and turn the Exhaust filter counterclockwise and lift it up.
  • Page 11 4. DISASSEMBLY MODEL 721.37060700 3) Remove the 3 screws on the Housing Motor NOTE : Make sure that the mount packing and remove it. should be located in the correct position as shown when assembling 4) Disconnect 2 lead wires and remove the mount packing and seal packing.

  • Page 12: Power Cord Replacement

    4. DISASSEMBLY MODEL 721.37060700 14. Power Cord replacement NOTE : Make sure that the PCB Assembly should be located in the correct position as 1) Disconnect the connector. shown below when assembling Connector 2) Remove the 2 screws and the holder cord.
  • Page 13 4. DISASSEMBLY MODEL 721.37060700 15. HEPA Filter Cover replacement 2) Remove the Cap by using a straight screwdriver. 1) Remove the dust bin as shown below. 2) Remove the HEPA filter cover by using a 3) Remove the 1 screw and spring and replace straight screwdriver as shown.
  • Page 14 4. DISASSEMBLY MODEL 721.37060700 2) Remove the Crevice tool and D / Brush. 2) Press the wand release button on the carry handle and tilt the wand handle forward. 3) Remove the Holder Accessory as shown. 3) Lift the wand out and up.

  • Page 15: Maintenance And Care

    5. MAINTENANCE AND CARE MODEL 721.37060700 IMPORTANT : IMPORTANT : - Always unplug the power cord from electrical - Always unplug the power cord from electrical outlet before performing any service on outlet before performing any service on vacuum cleaner.

  • Page 16: Schematic Diagram

    6. SCHEMATIC DIAGRAM MODEL 721.37060700 26AWG Tact Switch Power Display 8 Line (9Pin) Height 17AWG, BROWN 8 Line (8Pin) Display Main Motor Head Light Sensor 17AWG, BROWN 20AWG, BK 20AWG, WH Nylon Connecter Bridge 17AWG, BK diode 20AWG, BROWN 17AWG, WH...

  • Page 17: Trouble Shooting

    Review this chart to find do-it-yourself solutions for minor performance problems. Any service or repair needed, other than as described in this Use & Care Guide,should be performed through your local Sears Parts & Repair Center WARNING Electrical shock and personal injury hazard.

  • Page 18: Replacement Part List

    REPLACEMENT PART LIST MODEL 721.37060700 1300 8007 8007 8005 1103 8007 1101 1102 LOCATION PART NO. DESCRIPTION QUANTITY 1101 MCK37609001 Cover,Body 1102 MCK37610101 Cover Front 1103 AGR35999101 Pipe Assembly 1300 ACQ34949401 Top Cover Assembly 8005 FAB00631101 Screw,Tapping( 4,L8) 8007 FAB30147901...

  • Page 19: Exploded View

    EXPLODED VIEW MODEL 721.37060700 1217 1216 1219 1218 1215 1214 8003 1211 1213 1207 1210 1204 8007 1212 1209 8005 1208 7202 8007 8007 1205 1600 1206 LOCATION PART NO. DESCRIPTION QUANTITY 1204 MFG37809701 Locker 1205 4930FI4669A Holder,Cord 1206 MAM37608401...
  • Page 20 EXPLODED VIEW MODEL 721.37060700 7201 1500 8007 1800 LOCATION PART NO. DESCRIPTION QUANTITY 1201 MCQ37627601 Damper,mount packing 1202 MFZ37627901 Packing 1800 ANE32945301 Housing Assembly, motor 1400 EAU36637101 AC MOTOR Assembly 1500 ADQ33064201 Filter Assembly,exhaust 7201 EBR36636101 PCB Assembly 8007 FAB30147901...
  • Page 21 EXPLODED VIEW MODEL 721.37060700 2700 2107 2800 8006 2112 2108 2109 2110 2111 8002 8002 7301 7302 7303 8002 LOCATION PART NO. DESCRIPTION QUANTITY 2107 Plate MGJ38973401 2108 Window,Viewing MKC37387601 2109 Cover,Display MCK37387201 2110 Cover,Display MCK37387401 2111 Button,control MBG37846401 2112...
  • Page 22 EXPLODED VIEW MODEL 721.37060700 8002 2204 2203 8006 2220 8002 2205 7401 2210 2206 8004 8009 8008 2211 2207 2209 2208 2222 2202 2212 2221 2224 2225 2600 2201 2223 7402 2900 2216 2213 8006 2215 2219 2300 2226 - 22 -...
  • Page 23 EXPLODED VIEW MODEL 721.37060700 LOCATION PART NO. DESCRIPTION QUANTITY Base head 2201 MAM37389701 Bracket Motor 2202 MAZ37420001 Lever selector 2203 MFC37391501 Lever Assembly 2204 AFF36156801 Sensor Assembly 2205 EBD37969601 Shaft 2206 MHJ37792401 Locker 2207 MFG37419701 Ratchet 2208 MGU37788301 Locker 2209...
  • Page 24 EXPLODED VIEW MODEL 721.37060700 2500 2400 2600 LOCATION PART NO. DESCRIPTION QUANTITY 2400 AGU32945801 Plate Assembly,Bottom 2500 AGU33838501 Plate Assembly,Base 2600 AGU32945901 Plate Assembly,Base - 24 -...
  • Page 25 EXPLODED VIEW MODEL 721.37060700 3200 3100 4000 LOCATION PART NO. DESCRIPTION QUANTITY Handle Assembly 3100 AED32943301 Pipe Assembly,Suction 3200 AGR34907801 Hose Assembly,Flexible 4000 AEM32943501 - 25 -...
  • Page 26 EXPLODED VIEW MODEL 721.37060700 5300 5007 5008 5100 5021 5200 LOCATION PART NO. DESCRIPTION QUANTITY 5007 MDQ37613701 Frame,Filter 5008 MDJ37614401 Filter,Motor Safety 5021 MJC37612601 Strainer,Inner 5100 AJL35084901 Tank Assembly,Dust 5200 AGU35076801 Plate Assembly,Bottom 5300 ACQ35100801 Cover Assembly,Dust - 26 -...

  • Page 27: Exploded View

    EXPLODED VIEW MODEL 721.37060700 6100 6200 6300 ILLUSTRATION PART NO. DESCRIPTION QUANTITY Nozzle Crevice 6100 MFV37630801 Brush Assembly,Dust 6200 ABC32946201 Nozzle Assembly,Turbine 6300 AGB32946401 - 27 -...
