- Page 1 RANGER SERIES 802.11b/g/n 150Mbps Wireless Micro USB Adapter DG-WN3150Nu 150 Mbps V1.0 2011-11-18...
-
Page 2: Fcc Warning
Please check with your local distributors for the latest information. No part of this document can be copied or reproduced in any form without written consent from the company. Trademarks: DIGISOL is a trademark of Smartlink Network Systems Ltd. All other trademarks are the property of the respective manufacturers. -
Page 3: Package Contents
Package Contents The following items should be present in your package: DG-WN3150Nu 150Mbps Wireless Micro USB Adapter (1 No.) Protection cap (1 No.) Quick installation guide Installation software CD (includes User Manual & Driver/Utility) Make sure that the package contains above items. If any of the listed items is damaged or missing, please contact your retailer immediately. -
Page 4: System Requirements
System requirements The following system requirements are recommended An empty USB 2.0 port Windows 2000, XP, Vista or Windows 7 operating system CD-ROM drive At least 100MB of available disk space Product View Below shown is the product view indicating the USB interface and Link/Activity LED (under the case). -
Page 5: Driver Installation
Driver Installation Please follow the instructions mentioned below to install your new wireless USB adapter: Note1: The following installation was operated under Windows XP. (Procedures are similar for Windows 2000/Vista.) Note2: If you have installed the Wireless PC Adapter driver & utility before, please uninstall the previous version first. - Page 6 Click 'Next' to begin with the driver and utility installation. The Installation procedure will need few minutes to complete the setup, please be patient.
- Page 7 Click 'Finish' to reboot your computer to complete the installation procedure. If you don't want to reboot the computer now, select 'No, I'll restart my computer later' option and click 'Finish'. Please note you have to reboot your computer before you can use your new wireless USB adapter.
-
Page 8: Connecting To A Wireless Network
Here! Driver Installation is now Complete! Connecting to a Wireless Network Left-click the DIGISOL configuration utility icon located at lower-right corner of computer desktop, and configuration menu will appear: Wireless utility will appear. Click 'Available Network' menu to search for wireless access points nearby. - Page 9 Please wait for a while, and all wireless access points which can be reached by this wireless network adapter will be displayed here If the wireless Access Point you wish to connect does not appear here, you can click ‘Refresh’ button to scan for wireless access points again;...
- Page 10 If a password is required to access the wireless access point, please input it in 'Network key' (and input it again in 'Confirm network key' for confirmation). Click 'OK' when password is properly inputted. NOTE: Network security type ('Network Authentication' and 'Data encryption') will be selected automatically based on wireless access point's security setting.
- Page 11 Network adapter will attempt to connect to access point now, this may require few seconds to minutes, please be patient. When the 'Status' become 'Associated', your computer is connected to access point you selected. Click 'Close' to close configuration menu. NOTE: If you are connected to an access point but the connection has dropped soon, please check security settings and re-check password spelling.
