- Page 1 Quick Installation Guide Guía de instalación rápida 5-Port Gigabit Ethernet Switch SGE05 8-Port Gigabit Ethernet Switch SGE08...
-
Page 2: Table Of Contents
Contents English 1. Before You Start 2. Hardware Installation 3. LEDs Technical Specifications Troubleshooting Quick Installation Guide - KEEBOX SGE05/SGE08 Version 05.14.2010 Version 05.13.2009... -
Page 3: English
Before You Start Verify Package Contents SGE05/SGE08 Multi-Language Quick Installation Guide Power Adapter: SGE05 (5V DC, 1A) / SGE08 (5V DC, 2A) Minimum requirements Computer with Network adapter installed CAT-5e or CAT-6 Network Cable The surface must support at least 1.5 Kg for the Switch The power outlet should be within 1.82 meters (6 feet) of the Switch... -
Page 4: Hardware Installation
Hardware Installation 1. Connect the Power Adapter to the SGE05/SGE08 and then to a power outlet. 2. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port on the SGE05/SGE08. Quick Installation Guide - KEEBOX SGE05/SGE08... -
Page 5: Leds
Troubleshooting LEDs SGE05 SGE08 1. Power Green: Power is on Not Illuminated: Power is off 2. LINK/ACT Green (Solid): Connection for the port is 1000Mbps Green (Blinking): Activity is occurring from the link Amber (Solid): Connection for the port is 10/100Mbps... -
Page 6: Technical Specifications
Troubleshooting Technical Specifications SGE05 SGE08 IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX Standards IEEE 802.3ab 1000Base-T; IEEE 802.3x Flow Control Ethernet: Cat. 3, 4, 5, up to 100m Fast Ethernet: Cat. 5, 5e, up to 100m Network Media Gigabit Ethernet: Cat. 5, 5e, 6, up to 100m... - Page 7 Check the connection of the power adapter to the SGE05/SGE08 and the power outlet. 2. Check that the power outlet is receiving power. 2. When I connect a computer to one of the ports on the SGE05, the Link/ACT LED turns on, but I am not getting Gigabit speeds.
- Page 8 AC/DC Power Adapter, Cooling Fan, and Power Supply carry a 1 year warranty If a product does not operate as warranted during the applicable warranty period, KEEBOX shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer. The repair/replacement unit's warranty continues from the original date of purchase.
- Page 9 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 10 Copyright © 2010 KEEBOX. All Rights Reserved.
