Before Operating Your Washer
Read your Washer Owner's Guide. It has important safety
and warranty information. It also has many suggestions for
best washing results.
To reduce the risk of fire, electric shock, or
injury to persons, read the IMPORTANT SAFETY INSTRUC-
TIONS in your Washer Owner's Guide before operating this
appliance.
Operating Steps
Read Washing Procedures in your Owner's Guide. It
explains these operating steps in detail.
1. Sort laundry into loads that can be washed together.
2. Prepare items for washing.
3. Pretreat stains and heavy soil.
4. Add the measured amount of detergent to wash tub
before adding the laundry load.
5. If desired, add liquid bleach to bleach dispenser. DO
NOT pour bleach directly onto the load.
6. If desired, add liquid fabric softener to fabric softener
dispenser. DO NOT pour fabric softener directly onto
wash load.
Printed in U.S.A.

OPERATING INSTRUCTIONS

7. Add laundry load loosely to wash tub. Dry load should
not be higher than top of agitator vanes. For best
results, DO NOT overload.
8. Select the wash cycle and settings according to type,
size and soil level of each load.
9. Close lid and pull out Cycle Selector knob to start
washer. The washer will fill with water but will not agitate
or spin with the lid open.
To stop the washer, push in the Cycle Selector knob. To
change a cycle, push in the Cycle Selector knob and turn
it clockwise to the desired setting. Pull out the knob to
restart the washer.
10. Remove items at end of cycle. Wait about 2-3 minutes
for safety lid lock to release.

Cycle Selection

Push in and turn the Cycle Selector knob clockwise to
the desired cycle. For best results, follow the washing
instructions on the fabric care labels.
The Whites, Colors and Knits/Delicates cycles progress
through wash agitation, drain and spin with a spray rinse,
rinse agitation, and a spray rinse during the final spin.
Whites Cycle
This cycle provides up to 15 minutes of normal agitation and
a fast spin for most fabrics.
Power Spin provides 12 minutes of spin for maximum
removal of water. This conserves energy by reducing
drying time.
Extra Rinse Cycle
Use the Extra Rinse cycle after any complete wash cycle
when an additional deep rinse may be needed to remove
excess detergent and soil. It provides 3 minutes of rinse
agitation in cold water, followed by a spray rinse at the
selected rinse water temperature during spin.
If desired, add liquid fabric softener to the water (not the
fabric softener dispenser) or use a softener sheet in the
dryer. DO NOT pour fabric softener directly onto the load.
Colors Cycle
This cycle provides up to 12 minutes of normal agitation
and a fast spin for cottons and blends with a no-iron
finish. A cool down spray rinse helps reduce wrinkling.
Select the Perm Press Prewash setting to help
loosen soil and remove stains before washing. Add the
recommended amount of detergent and other
laundry products desired to tub. Add load. Select a cold
water rinse and appropriate load size. Load will agitate 4
minutes, drain and spin. Follow Perm Press Prewash with a
complete Colors cycle and a half dose of detergent.
P/N 134753300A (0610)
