De Sisti Lighting S.p.a.
Via Cancelliera # 10a, 00040 Albano Laziale (Rome- Italy).
Tel. ..39/06/934991 Fax. ..39/06/9343489
U.R.L. Address: www.desisti.it E-mail address: desisti@desisti..it
LEONARDO 5.000 W
MOD.350
(MANUAL OPERATED)
MANUFACTURER
De Sisti Lighting S.p.a.
Via Cancelliera # 10a, 00040 Albano Laziale (Rome- Italy).
Tel. +39/06/934991 Fax. +39/06/9343489
U.R.L.: www.desisti.it
1. INTRODUCTION
Congratulations on your purchase of a LEONARDO 5 kW lighting fixture from De Sisti Lighting, our
commitment to Total Customer Satisfaction and a consolidated experience in leading the innovation in the
manufacturing of lighting products for the professional Entertainment Industry mean you can depend upon
the quality of this product.
The LEONARDO 5 kW is a compact, highly efficient Fresnel lens spotlight using tungsten-quartz-halogen
filament lamps having G38 socket, L.C.L. of 165 mm. and max. 5 kW power.
www.audiovias.com
Quartz - Halogen Fresnel SPOTLIGHT
Standard EN-60598-2-17 Class 1
INSTRUCTION MANUAL
desisti@desisti.it
E-mail:
REPRESENTATIVE
Pag 1
.
MOD.351
(POLE OPERATED)
Advertisement
Related Manuals for De Sisti LEONARDO 350
Summary of Contents for De Sisti LEONARDO 350
- Page 1 E-mail: 1. INTRODUCTION Congratulations on your purchase of a LEONARDO 5 kW lighting fixture from De Sisti Lighting, our commitment to Total Customer Satisfaction and a consolidated experience in leading the innovation in the manufacturing of lighting products for the professional Entertainment Industry mean you can depend upon the quality of this product.
-
Page 2: Safety Instructions
2. YOKE AND ACCESSORIES ASSEMBLY BARNDOOR COLOUR FRAME "T" HANDLE M10x35 STEP BEARING M.O. STIRRUP ASSEMBLY CLUTCH DISK BOLT M10x30 WASHER 010 SPACER PIVOTED BRACKET SPOT-FLOOD "T" HANDLE CATCH HINGE SIDE CATCH SIDE (MANUAL OPERATED) MOD.350 BARNDOOR COLOUR FRAME BOLT M10x30 HINGE SIDE WASHER 010 SPACER... - Page 3 C. Before hanging the luminaire ensure that the suspension point (or the stand) is properly rated to accept the luminaire weight. D. In case of pole operated use, fit only a P.O. stirrup from De Sisti Lighting. E. A suitable secondary safety suspension device (safety cable, chain or equivalent) must be fitted between the suspension point and stirrup.
-
Page 4: Safety Standards
500 working hours and at least once a year. This frequency may need to be increased if rough or unknown (eg. rental) treatment is incurred. Replace only with original De Sisti Lighting spare parts. Non- original cables may not withstand the thermal and mechanical conditions of use B.
