Summary of Contents for GSE MCG-101
- Page 1 MCG-101 Operations Manual sa le s@gsa t. us : gsa t .us...
-
Page 2: Table Of Contents
Codecs System Operation Protocols System Functions/Extensions Equipment Overview GPS Tracking XGate Satellite Email Service Power Setup Configure XGate to work with MCG-101 Power Requirements/Specs Test Your Configuration LED Status Indicators Dimensions and Weight Analog Port Troubleshooting Adding Additional Phones Adding Additional Phones (diagram) -
Page 3: Introduction
Introduction System Theory The MCG-101 was designed to provide the most powerful and versatile Iridium communications system to offices, remote locations, aircraft, and maritime. The system provides an intelligent solution for Iridium satellite phones to operate as a telephone, Internet gateway, intelligent GPS device, send/receive SMS, and attach to other devices through RS232 and ethernet. -
Page 4: System Capabilities
sa les@gsa t.us : gsa t .us System Capabilities System capabilities include all major PBX features, including: Call Features Codecs Interactive Directory Listing Local and Remote Call Agents Authentication ADPCM/G711/G722/G7231/G72 Macros AutomatedAttendant 6/G729/GSM/iLBC/Linear/LPC- Predictive Dialer Blacklists 10/Speex Privacy Blind Transfer Overhead Paging Protocols Call Detail Records... -
Page 5: Equipment Overview
The MCG-101 is a wall mounted satellite terminal that contains Iridium technology. The terminal contains an internal SIM card that must be installed. The MCG-101 also has an exposed connector for attaching the required external antenna. The status of the entire system can be monitored through an attached computer. -
Page 6: Power Setup
sa les@gsa t.us : gsa t .us Power Setup Power Power Requirements 5W or 51 BTU per hour DC Input Voltage 5V@ 3A Environmental Requirements Operating temperature: 32 to 113ºF (0 to 45ºC) Storage temperature: -13 to 158ºF (-25 to 70ºC) Operating relative humidity: 10 to 85% (noncondensing) Operating altitude:... -
Page 7: Led Status Indicators
sa les@gsa t.us : gsa t .us LED Status Indicators Power Signal Ethernet Off: Off: Off: No Power No signal but registered Disconnected Solid: Solid: Solid: Idle with >20% signal Connected Fast Flash: Slow Flash: Fast Flash: Unit is booting Data or voice call in progress Network Traffic Fast Flash:... -
Page 8: Analog Port
: gsa t .us Analog Port You can connect a standard analog telephone to the MCG-101 to make and recieve calls, or dial other extensions. The built in IP PBX manages the call routing and features which can be customized via the web management console. -
Page 9: Adding Additional Phones
: gsa t .us Adding Additional Phones (Extra) MCG-101 will also work with one or two analog phones by using an MCG101 analog phone adapter (sold separately). 2-Port Analog Adapter This adapter provides an interface between the MCG-101 unit and two analog telephones to allow you to set up a PBX system with multiple analog telephones. -
Page 10: Wifi Setup
sa les@gsa t.us : gsa t .us WiFi Setup Use your computer or device to connect via wifi. SSID wxa-102-xxxx Password none GSat.us • sales@gsat.us • 954-459-4000... -
Page 11: Antenna Setup
sa les@gsa t.us : gsa t .us Antenna Setup Recommended Antenna Installation Vehicle Mounting When mounting the antenna on a vehicle, make sure there is no large obstruction blocking its view of the sky. Ship Mounting The antenna can be installed in many different locations on board. Make sure that the antenna has a clear view of the sky and there is no large obstruction blocking its view of the sky. -
Page 12: Sim Card Setup
If you did not purchase airtime or a SIM card at the time you purchased the MCG-101, you will need to choose airtime and receive a SIM card. Please follow instructions under “Insert or Switch out SIM Card” to insert the SIM card into the MCG-101 unit yourself. -
Page 13: Reset
sa les@gsa t.us : gsa t .us Reset Standard Reset Press and release quickly Factory Reset Press and hold for 5 seconds Reset Button GSat.us • sales@gsat.us • 954-459-4000... -
Page 14: Voice And Pbx Software
XGate Satellite Phone App will allow you to make phone calls through the MCG-101 using your smartphone. You will be able to access all your contacts just as you would normally be able to do. The MCG-101 comes pre-programmed with four SIP voice extensions. By default, these extensions are 201 through 204. The SIP password for all 4 extensions is 1234. -
Page 15: Installation
System Initialization The entire system will require three (3) minutes to initialize. The system International is ready for operation when the front panel of the MCG-101 displays green 011 (country code)(phone number) lights. (see LED behavior charts Pg 6) 001 (phone number) -
Page 16: System Functions/Extensions
GPS chip built directly into the satellite terminal. The MCG-101 works with the Iridium network and offers tracking. Tracking service with the MCG-101 is a premium service with a monthly fee. If you don’t have tracking enabled, please contact your service provider for more information. -
Page 17: Test Your Configuration
Test Your Con guration 1. Power ON the MCG-101. 2. From your computer, tablet, etc. connect to the wireless network created by the MCG-101. The name of the wireless network will be something like wxa-112-xxxx. 3. Open XGate and click the <Start> button. -
Page 18: Dimensions And Weight
: gsa t .us Dimensions and Weight MCG-101 (without mounting tabs) Height 2 in. (5.08 cm) Width 8 in. (20.32cm) Depth 8 in. (20.32cm) Weight 4 lb (1.8kg) Telephone Jack Ringing REN RMS Ringing Voltage 60 V DC RMS... -
Page 19: Troubleshooting
What is the error message that appears in the session log? To expedite your support request, please submit of copy of the entire transaction log. Please note that you are using a MCG-101 and submit your answers in an email to your satellite dealer. GSat.us • sales@gsat.us • 954-459-4000...
