English version
English version
MO250/MO250UK Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A
Introduction
First of all, many thanks for purchasing the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A. The Sweex Wireless ADSL 2/2+
Modem/Router 54 Mbps Annex A enables you to share a fast ADSL 2 Internet connection and to set up your own network.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during
installation or operation of this product, go to www.sweex.com and look under the heading service & support.
In order to fully enjoy the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A, it is important to observe the following:
• Do not expose the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A to extreme temperatures. Do not place the device in direct
sunlight or in the direct vicinity of heating elements.
• Do not use the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A in extremely dusty or moist surroundings.
• Protect the device against powerful shocks or jolts – they may damage the internal electronics.
• Never attempt to open the device yourself – it will cause the warranty to lapse.
Contents of the box
Prior to using the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A, check if all required parts are present. The following parts must
be present in the box:
• Wireless ADSL 2/2+ Modem
• Antenna
• Power supply adaptor
• RJ45 UTP Ethernet network cable (length: 170 cm)
• RJ11 telephone cable (length: 185 cm)
• CD-ROM with manual and Panda antivirus trial software
If one of the above parts is missing, please contact the retail outlet where you purchased the device.
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MO250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWEEX MO250

Summary of Contents for SWEEX MO250

  • Page 1 In order to fully enjoy the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A, it is important to observe the following: • Do not expose the Sweex Wireless ADSL 2/2+ Modem/Router 54 Mbps Annex A to extreme temperatures. Do not place the device in direct sunlight or in the direct vicinity of heating elements.

  • Page 2: Additional Specifications

    English version English version Specifications • Suitable for ADSL via an analogue telephone line (Annex-A) • Supports: ADSL, ADSL 2 and ADSL 2+ • Supports: IEEE 802.11b and IEEE 802.11g • Supports: WEP/WPA./WPA2/802.1X data encryption • Wireless data speed 54Mbps • 4 x RJ-45 UTP port, 10/100 Mbps IEEE 802.3x standard •...

  • Page 3: Side View

    English version ADSL The connection with the ADSL line is ok ADSL Regular blinking The modem is busy setting up a proper connection or no ADSL is connected to the RJ11 port ADSL Lit and blinking fast Indicates activity between the computer (1-4) computer and the Internet Indicates the use of a PPP connection Rear view of the modem Starting on the left, the following connections can be found at the rear of the modem:...

  • Page 4: Connecting The Sweex Adsl 2 Modem

    English version Connecting the Sweex ADSL 2 Modem 1. Connect the power adaptor (included) to the rear of the modem and the mains socket. The LED under PWR is lit. In the event the LED is not lit, check the connections of the power adaptor to the ADSL modem and the mains socket.

  • Page 5: Windows 2000

    English version Select the options “Obtain an IP address automatically“ (Obtain an IP address automatically) and “Obtain DNS server address automatically” (Obtain DNS server address automatically). Confirm the settings by clicking “OK” (OK). The network settings for Windows XP have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual.
  • Page 6 English version Select the options “Obtain an IP address automatically” (Obtain an IP address automatically) and “Obtain DNS server address automatically” (Obtain DNS server address automatically). Click “OK” (OK) twice. The network settings for Windows 2000 have now been configured correctly. The correct settings for the Internet browser will be discussed later in this manual.
  • Page 7 English version Under the tab “Gateway”, the list of “Installed gateways” (Installed gateways) must be empty. If so required, select each gateway and click “Remove” (Remove). Under the tab “DNS Configuration”, select the option “Disable DNS” (Disable DNS). Click “OK” (OK) twice. The network settings for Windows 98SE have now been configured correctly.

  • Page 8: Setting The Wireless Network

    Always click “Refresh network list” (Refresh network list) top left in this window first, to obtain the most recent listing. Select the name (also referred to as SSID) “Sweex MO250” by clicking it once. Now click “Connect (Connect). If it has successfully connected to...

  • Page 9: Modem Access (Login)

    Type the modem IP address 192.168.250.1 in the browser address bar. You can now access the modem. The modem login screen appears. Fill out the login name and the corresponding password. The standard login is “sweex” and the corresponding password is “mysweex”.

  • Page 10: Setting The Internet Provider (Isp)

    This screen displays the current Internet connection and a variety of system information. Setting the Internet Provider (ISP) In order to facilitate the installation process, the Sweex ADSL 2/2+ Modem/Router Annex A disposes of a pre-programmed list of provider settings. To this end, go to the “Setup Wizard”. The following screen appears: Under “Country”...
  • Page 11 The standard SSID is “Sweex MO250”. You can change this under “Primary SSID”. We recommend not changing this so you can always recognise the modem. Here you can also find other options such as “Channel” and “802.11 Mode”. We again recommend maintaining the default values.

  • Page 12: Securing The Wireless Network

    English version Securing the wireless network While in the “Wireless” window, click “Security”. Complete the following steps for setting WEP security: 1. Select WEP 2. Tick “Enable WEP Wireless Security” 3. Under “Select Encryption Key”, enter the network key. Note! Every two characters must be followed by a space (see illustration). In our example we use network key “10 20 30 40 50”.

  • Page 13: Opening Ports In The Modem (Port Forwarding And Dmz)

    “Port Forwarding” to change the port settings. Here too the Sweex ADSL 2/2+ Modem/Router Annex A offers a pre-programmed list with common programmes and games. Under “Category”, first select the type of programme. Now select the programme or the game from the list and click “Add >”.
  • Page 14 English version If the programme or game is not listed, ports can also be opened manually. To this end, go to “Custom Port Forwarding”. The following screen appears: Here enter the details which the programme or game requires. For “Source IP Address” and “Source Netmask” enter 0.0.0.0. At “Destination IP Address”, enter the IP address of the computer for which you want to open the ports.

  • Page 15: Lan Settings

    In order to store the settings click “Apply” and then “Save All”. Subsequently, in the next window, click “Apply” once more. Changing the password (User Management) The standard login of the Sweex ADSL 2/2+ Modem/Router Annex A can be changed; in the main window select “Tools” and go to “User Management”.

  • Page 16: Remote Modem Management (Web Access Control)

    Remote modem management (Web Access Control) The Sweex ADSL 2/2+ Modem/Router Annex A also offers a remote management feature. This means that the modem can be configured from another location, via the Internet. In the menu, click “Advanced” and then click “more ”. Now click “Web Access Control”.

  • Page 17: Upgrading The Firmware Of The Modem (Update Firmware)

    In order to provide the modem with updates, the so-called ‘firmware’ needs updating. In the menu, go to “Tools” and select “Update firmware”. Here the firmware of the modem can be updated. New firmware can be downloaded from the Sweex website under ”Service en support”. If the firmware file is zipped, make sure you select and extract the file first on a location in your computer where you can retrieve it easily.

  • Page 18: List Of Internet Providers And Corresponding Subscriptions

    English version List of Internet Providers and corresponding subscriptions Planet Economy ADSL KPN Mxstream Standard ADSL KPN Mxstream Comfort ADSL KPN Mxstream Advanced ADSL KPN Mxstream Hetnet Instap Surfen ADSL KPN Mxstream Voordeel Surfen ADSL KPN Mxstream Surfen ADSL KPN Mxstream XS4all ADSL Start ADSL KPN Mxstream ADSL Lite ADSL KPN Mxstream ADSL Basic...
  • Page 19 English version ADSL pro 1 Bbned Economy ADSL Pro 2 Bbned Economy ADSL pro 8 Bbned Economy Wanadoo Direct Bbned Economy ADSL KPN Mxstream Lite ADSL KPN Mxstream Basic ADSL KPN Mxstream Plus ADSL KPN Mxstream Family (Wanadoo) Zonnet/Versatel/Tele2 ADSL Budget PPP Versatel/Tele2 PPP ADSL Family PPP Versatel/Tele2 PPP...
  • Page 20 English version All-In 4096 BabyXL All-in 5120 BabyXL X-tra 256 Bbned Economy X-tra 1024 Bbned Economy X-tra 2048 Bbned Economy X-tra 4096 Bbned Economy X-tra 8192 Bbned Economy Comfort 800 ADSL KPN Mxstream Comfort 1600 ADSL KPN Mxstream Comfort 3200 ADSL KPN Mxstream Comfort 8000 ADSL KPN Mxstream Scarlet...
  • Page 21 English version Solcon Lite ADSL KPN Mxstream Basic ADSL KPN Mxstream Extra ADSL KPN Mxstream Connect 512/256 Bbned Economy Connect 1024/512 Bbned Economy Connect 2048/1024 Bbned Economy Connect 8192/1024 Bbned Economy Surfnet ADSL 512 Bbned Economy ADSL 1024 Bbned Economy ADSL 8192 Bbned Economy Tele2 Basis...

  • Page 22: Warranty

    Warranty All products under the Sweex brand are warranted for a period of three years. We do not grant support or warranties for any software and/or (rechargeable) batteries included. Settlement of guarantee only takes place via the dealer where you have purchased the product in question.
