Summary of Contents for MINICAM mc50 Duo
- Page 1 MINCAM PUSH CAMERA OPERATION MANUAL Applicable for the mc50 Duo FEBRUARY 1, 2015 RAUSCH USA 4757 Innovation Way, Chambersburg, PA 17201...
-
Page 2: Table Of Contents
Push System Manual 1. Table of Contents Table of Contents ........................ 1 minCam System Definition ....................2 mC50 Duo ........................2 minCam Setup ........................2 Positioning of the system ..................... 3 Power on ........................3 minCam Control Unit ......................4 Battery Indicator ...................... -
Page 3: Mincam System Definition
2. minCam System Definition 2.1 mC50 Duo The mC50 Duo dual-reel system comes with two cameras attached to two separate cable reels built into one complete maintenance free CCTV push system. Outer cable reel connects with 9.2mm push cable connected to self-leveling color push camera KK55SL. Inner cable reel connects with 6.7mm push cable connected to self-leveling color push camera KK29SL. -
Page 4: Mincam Setup
2. Turn the light regulator to the middle position (upright – Figure 3.1.d) 3. Press the “On/Off” switch. The minCam system is ready to use. Figure 3.1.d – light regulator is in the upright position. Version 3.0.0.1.5 mc50 Duo Manual... -
Page 5: Mincam Control Unit
The black dial enables continuous LED brightness regulation. Turn Left (counter-clockwise): turn lights off Figure 4.a – mC50 Duo Control Unit Turn Right (clockwise): turn lights on, up to 100% brightness Set Middle: before turning on the system, the light regulator should always be set to the middle. -
Page 6: Mincam Recording Unit / Monitor
As soon as you press pause, the red square changes to the pause symbol. See Figure 5.2.1.b 5.2.3 Stop Recording Video Figure 5.2.2.a – Red pause emblem Press the “Video” button again to stop recording. designates recording paused Version 3.0.0.1.5 mc50 Duo Manual... -
Page 7: Screen Adjustment
Search by date and time (see figure 5.4.a) View All, to open all files (see figure 5.4.b) 3. Press this button to “SELECT”: 4. Press this button to “GO BACK”: Figure 5.4.b – File Menu Figure 5.4.a – Search Function Version 3.0.0.1.5 mc50 Duo Manual... -
Page 8: Preview Videos
1. Use to choose a file. 2. Press the “Menu Button” to open the shell menu: to select “Delete” in the menu. 3. Use Figure 5.4.3.a – Deleting a file 4. Hit “SELECT” and “YES”: Version 3.0.0.1.5 mc50 Duo Manual... -
Page 9: Settings Menu
All of the KK29SL centering accessories have a two-step installation procedure: 1. Slide the KK29 camera into the back of the guide. 2. Spin in the screws to hold the camera in place. Figure 6.1.a – KK29 centering brushes Version 3.0.0.1.5 mc50 Duo Manual... -
Page 10: Kk55Sl Center Guide (Greater Than 3")
5” rolls. 3. Slide the KK55 camera into the back of the skid. Figure 6.3.1.a – KK55 8” Roller Skid 4. Spin the screws to hold the camera in place on the bottom of the skid. Version 3.0.0.1.5 mc50 Duo Manual... -
Page 11: Warnings & Care
Avoid extreme mechanical strain for the camera head. Do not use the inspection system if the camera cable is broken Should there be any need of repair, please contact Rausch Electronics USA. Version 3.0.0.1.5 mc50 Duo Manual... -
Page 12: Mincam System Specifications
Push System Manual 8. minCam System Specifications mC50 Duo Cable Reel Outer reel: 200 ft. (60m) of 9.2mm fiberglass push cable. Inner reel: 65 ft. (20m) of 6.7mm fiberglass push cable. 512 Hz sonde standard (33 kHz special order) ...
