Ryobishi p125 Operator's Manual

18 volt nickel-cadmium/lithium-ion 6 port supercharger
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
18 VOLT NICKEL-CADMIUM/LITHIUM-ION
6 PORT SUPERCHARGER
6 PORTS SUPERCHARGER
DE 18 VOLT À NICKEL-CADMIUM ET LITHIUM-ION
6 PUERTOS SUPERCHARGER
DE NÍQUEL-CADMIO/IONES DE LITIO
P125
ACCEPTS ALL RYOBI 18 VOLT ONE+ BATTERY PACKS
COMPATIBLE AVEC TOUS LE BLOC-PILES ONE+ DE 18 V
ACEPTA TODOS LOS PAQUETES DE BATERÍAS DE 18 V ONE+
Your charger has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Cette chargeur a été conçue et fabriquée conformément à
nos strictes normes de fiabilité, simplicité d'emploi et sécurité
d'utilisation. Correctement entretenue, elle vous donnera des années
de fonctionnement robuste et sans problème.
AVERTISSEMENT :
blessures, l'utilisateur doit lire et veiller à bien comprendre le
manuel d'utilisation avant d'employer ce produit.
Merci de votre achat.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
DE 18 V
Pour réduire les risques de
Su cargador ha sido diseñada y fabricada de conformidad con las
estrictas normas para brindar fiabilidad, facilidad de uso y seguridad
para el operador. Con el debido cuidado, le brindará muchos años
de sólido y eficiente funcionamiento.
ADVERTENCIA:
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
Para reducir el riesgo de lesiones,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the p125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ryobishi p125

  • Page 1 6 PUERTOS SUPERCHARGER DE 18 V ™ DE NÍQUEL-CADMIO/IONES DE LITIO P125 ACCEPTS ALL RYOBI 18 VOLT ONE+ BATTERY PACKS COMPATIBLE AVEC TOUS LE BLOC-PILES ONE+ DE 18 V ACEPTA TODOS LOS PAQUETES DE BATERÍAS DE 18 V ONE+ Your charger has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety.
