8-Inch Realtime TV
(Transcript Viewer)
User Manual 2.0
Charging - Page 2
•
Turning On - Pages 3
•
Initiating Realtime - Pages 4
•
Ez Verify (Test Mode) - Page 5
•
Viewing / Reviewing Text - Pages 6 - 8
•
Search Feature - Pages 9 - 10
•
Export / Closing Transcript - Pages 11 - 12
•
Formatting Options - Page 13
•
Updating Software - Pages 14 - 15
•
Contents
Advertisement
Summary of Contents for StenoCast Realtime TV
-
Page 1: User Manual
8-Inch Realtime TV (Transcript Viewer) User Manual 2.0 Contents Charging - Page 2 • Turning On - Pages 3 • Initiating Realtime - Pages 4 • Ez Verify (Test Mode) - Page 5 • Viewing / Reviewing Text - Pages 6 - 8 •... -
Page 2: Things You Should Know
Page 2 Charging the 8-inch TV (Transcript Viewer): To charge the Realtime TV, plug the AC power cord (supplied) into the power port on the upper right edge of the Realtime TV. See picture 1 below. The power port is situated on the TV’s right edge, between the Search icon and the Back icon. - Page 3 THINGS YOU SHOULD KNOW Page 3 Turning on the 8-inch TV (Transcript Viewer): 1) Press and hold the On / Off button (approximately three to five seconds) until the display screen turns on and you hear the “buzz.” When facing the TV screen, the On / Off button is on the upper right-side edge, near the top.
- Page 4 Page Receiving Realtime 1) On the Homepage tap the Realtime TV icon one time. 2) The TV will automatically establish contact with your transmitter. If you do not hit any steno strokes, your transmitter (X7, RED or Ez Send) will automatically send a test signal to your TV: “Wireless Connection Successful.”...
- Page 5 TV are functioning properly. If the realtime transcript is thereafter not received on the Realtime TV and/or other computers, that is an indication that the buad rate, protocol or com port settings on the reporter’s computer may be the...
-
Page 6: Pause Button
FEATURES Page To View Text The text will automatically scroll across the TV screen. • To Review Text (Scroll back) Tap the Pause button one time • To scroll back, towards the beginning of the realtime transcript, place one finger •... - Page 7 FEATURES Page 7 To Review Text (Scroll back) Tap the Pause button one time • You may either tap the arrow buttons at the bottom of the display screen to move • backwards or forwards through the transcript, or you may place one finger on the top portion of the screen and quickly slide your finger downwards (to move backwards through the transcript) or place one finger at the bottom of the screen and slide your finger quickly upwards (to move forwards through the transcript).
- Page 8 • Play button one time (if you had tapped the Pause button before highlighting). The realtime transcript is being received/stored on your Realtime TV during the periods when the transcript has been paused. Note: You are not required to pause the proceedings in order to highlight text.
- Page 9 Page 9 Searching for Text With the 8-inch Realtime TV, you have two options when searching for a word or words within the realtime transcript. You may either tap the Search icon (see Picture 1 below) or tap the Pause icon on the lower right portion of the screen (see Picture 2 below) and then tap the Search icon that appears in the lower left corner of the screen (see Picture 3 below).
- Page 10 THINGS YOU SHOULD KNOW Page 10 Searching for Text cont’d 1) Tap screen here to activate the touch screen keyboard. 2) Type in the word(s) to search on touch screen keypad and tap the Search button. 3) Search results appear in shaded area.
- Page 11 TV’s USB port. Note: If you export (save) a transcript and a flash/thumb drive is not plugged into the Realtime TV USB port, then the transcript is saved on the Realtime TV’s internal storage.
- Page 12 Note: If the Home or Back buttons are depressed inadvertently during a realtime session, simply tap the Realtime TV icon on the Homepage to return to the realtime transcript. The Realtime TV will continue to receive the transcript even if you have navigated away from the...
- Page 13 FEATURES Page 13 Changing the Background Font Size & Colors & Time Stamps & Page/Line Numbers You may select font size, background colors, and you decide whether to display page/line numbers and time codes. To make any changes, simply press the Format button, then tap the desired tab.
- Page 14 Updating Realtime TV Software Copy the TV software update onto a USB flash/thumb drive. Plug the flash/thumb drive into the USB port on the Realtime TV (using the provided adapter). 1) Tap the Menu Button 2) Tap ES File Explorer...
- Page 15 FEATURES Page 15 Updating Realtime TV Software (cont’d) 4) Tap the StenoCast icon 4) Tap “OK” to replace 4) Tap “Install” Install...
- Page 16 Page 16 Extra Capabilities—Warning! There are several features and capabilities built into this Realtime TV device that may in the future be utilized, along with several apps that come standard with Android devices. It is strongly recommended that this Realtime TV be utilized exclusively for providing realtime services to your clients.
- Page 17 THINGS YOU SHOULD KNOW Page 17 Manufacturer’s Warranty This device is covered by the Manufacturer’s Warranty for a period of one (1) year from date of initial purchase. This warranty covers both workmanship and materials. If this product fails during the warranty period due to a defect in manufacture or materials, the device will be repaired or replaced, at the Manufacturer’s discretion.
- Page 18 Phone: 858.578.4600 Fax: 888.496.3206 E-mail: support@stenocast.com...
