Summary of Contents for BrandMotionotion ADAS+
- Page 1 ADAS+ ADAS+ instructions 10-30-15...
- Page 2 Features ADAS+ Main Features of OPTIAN!! FCW ( Forward Collision Warning ) LDW (Lane Departure Warning ) FCDA ( Front Car Departure Alert ) DVR ( Driving Recorder ) Full HD Clear Display Touch LCD Monitor Event/ Motion Detection CCTV Recording in Parking Mode Battery Discharge Prevention GPS Track Recording...
-
Page 3: Table Of Contents
Contents Safety Video Playback Warning & Caution Manual Guide Caution Configuration Program Installation Method Check Accessories Data Manager Screen Composition Accessories Main Body & Functions Button Explanation Rear Camera & Functions SD Card Format Forward Collision Warning Maintenance Troubleshooting Main Lane Departure Warning Functions Front Car Departure Alert... - Page 4 Accessories Micro SD Card Rear Camera SD Card Adapter Consumable Main Body Rear camera Cigar Jack or Connection Cable Power Supply Cable • Specifications of the above accessories are subject to change according to the components supply. • Above images are just to help user‟s understanding and actual components may look a little different .
- Page 5 Main Body Internal GPS Detachable Bracket DC power port (3.5 pi) Micro SD Card Security Socket Menu Button Touch Front Camera (Full HD) Volume Adjustment Button Manual Recording Camera Button (REC) Angle Adjuster Continuous Power Supply Connection Rear Camera Connection...
- Page 6 Rear Camera / Internal Camera the rear camera angle can be • Integral bracket adjusted by rotating the main body Rear Camera When attaching the rear camera to • (VGA) the rear window glass , please make Text sure the bracket is on the right side. Indication DC Power-supply Port...
-
Page 7: Main Functions
Main Functions FCW (Forward Collision Warning) FCW function generates a warning signal when there is a potential risk of collision to the vehicle ahead . 2. The collision risk is evaluated through TTC ( Time To Collision ) and it is classified by 3 phases. TTC : The calculated value of the distance and the relative speed between a front vehicle and the •... - Page 8 LDW (Lane Departure Warning) LDW function generates an audible signal if the vehicle departs from the lane while driving above the set speed in the menu. LDW function works when the vehicle speed rate from internal GPS signal is over the set speed value.
- Page 9 FCDA or Beep & Watch ( Front Car Departure Alert ) FCDA function is activated only when the vehicle is stationary on the road. FCDA can detect the movement of a vehicle in front while waiting for the traffic light to change and will inform the driver of any front movement through a warning tone.
- Page 10 DVR ( Driving Video Recorder ) DVR function can record data with the Full-HD front camera and the VGA rear ( if equipped ) camera. Types of Recording Continuous Recording: Records video in 30 second segments and saves as files in the micro •...
- Page 11 DVR ( Driving Video Recorder ) 3. Parking Mode Parking Mode is activated when the vehicle is turned off and will be deactivated while the • ignition is turned on. If an impact is detected when parked , OPTIAN will record the event into an <Event> folder •...
- Page 12 Start Process [Booting] When the ignition is turned on , the introduction image and the loading screen will appear followed by a <Welcome> voice message. Text Intro Screen Loading * The loading time depends on the age and amount of data on the Micro SD card After booting up , OPTIAN will start to record automatically by generating the ADAS + “start recording”...
- Page 13 [ Screen Type and Explanation] ∙ shows the video is being recorded Video Monitoring Screen Center If a front vehicle is detected, it will indicate TTC. (1.2) and Number generates the FCW signal ,the TTC will turn red . Left shows the vehicle speed rate from the GPS signal Number The horizon guideline...
-
Page 14: Manual Guide
Manual Guide [Basic Menu] User can enter into each function setting menu via the basic menu screen. Basic Menu screen will appear when the user presses the side M button or touches the <Home> button while viewing the video monitoring screen. When the user touches each icon in <... - Page 15 [Smart Car] Changing the settings of ADAS functions 1) Operation Settings Turn On/Off each function • Touch the button to change between On and Off • 2) FCW( Forward Collision Warning ) Operating Speed: press the left & right arrows to adjust •...
- Page 16 [DVR/Black Box] Changing the settings of DVR functions 1) Basic Setup It is possible to turn continuous recording On/Off. • (If it is turned Off, it will record only when an impact is detected ) It is possible to turn voice recording On/Off. •...
- Page 17 [Video Playback] Playback of recorded video files from Continuous , Event and Parking modes. 1) Continuous/ Event /Parking Continuous (Normal) : Select and play continuously recorded files • Event : Select and play recorded event files • Parking( CCTV ): Select and play the files recorded while parked •...
-
Page 18: Manual Guide
Manual Guide [Configuration] Configure operating functions. 1) Volume Control • Speaker Volume Control: controls speaker output volume (0~15) • MIC Volume Control: controls input MIC volume (0~15) 2) Voice Alarm • Event Recording: If on , OPTIAN will alarm with the voice announcement – start ADAS+ event recording. - Page 19 4) System Setup • LCD Setting : Changes the settings of the screen view and the power saving mode. • LCD Display: Turns On/Off the signs of speed, speed unit ,smart UI and the horizon line screen data. • Language Setting : Changes LCD Text and voices to different languages. ( In the B2B Model, only a certain language will be provided ) •...
- Page 20 OPTIAN Data Manager Installation of Data Manager Program Through the data manager program , users can view FHD videos in a wider screen. In addition, users can check information such as vehicle GPS data and acceleration data. 1) Install the exclusive OPTIAN viewer in PC ( Ask ADAS+ manufacturer for the data manager program ) 2) When the installation completes, the OPTIAN...
-
Page 21: Video Playback
Screen Composition ⑭ ② ① ⑥ ⑬ ③ ⑦ ⑧ ⑨ ⑩ ⑪ ④ ⑫ ⑤ ⑮ 1) Main Screen 6) Video Play Bar 11) Recording Date & GPS co-ordinates 2) Sub Screen 7) Video Play Time 12)Acceleration sensor data; impact level & speed graph 3) GPS Location on the map 8) Video Volume 13) File List window Open/Close button... -
Page 22: Configuration
OPTIAN Data Manager Open file Stop Open SD card Play Previous File Zoom in on the video playing screen Play Button Zoom out of the video playing screen Pause Switch between the main screen video and sub screen video Play Next File Format SD card Normal playing speed Configuration... -
Page 23: Maintenance
Maintenance SD Card Maintenance SD card is a consumable product. If it is not maintained well, errors may occur and it may not be able to record videos properly . SD Card Insert/Remove When inserting or removing the SD card , make sure the power is turned off . Regular Data Formatting SD card is a consumable product. -
Page 24: Troubleshooting
Maintenance Troubleshooting Q. There is No power on the product Q. ADAS functions do not work Check the power state of vehicle battery Check whether it is turned off in the setting • • Start the vehicle , check the fuses menu •... - Page 25 Setup Main body camera angle adjustment To perform stable ADAS functions, it is necessary to match the green guide line of LCD with the horizon. Please adjust the angle while vehicle is parked on flat ground . In order to match with the horizon correctly, it is recommended adjusting the angle when the driver has a good view of horizon Open the camera angle adjuster cover Turn gear inside the adjuster and match the horizon guide line of LCD with the actual horizon...
- Page 26 Vehicle Type Setting It is necessary to set „Vehicle Type ‟ for stable performance of ADAS functions. ( 1 ) After booting up, press the side M button or the <Home> button in the Video Monitoring Mode to enter into the menu screen.
- Page 27 Installation 4)Press 「Attached Pos」menu button (5) Choose installation position of OPTIAN in menu. ADAS+ * Attached position is based on the driver‟s view inside the vehicle. * If the product is attached to the right or left side of the windscreen, please select the applicable position and input the measured distance from the center of the windscreen.
- Page 29 Installation Method Vehicle Wire Connection Method Basic components are for connection to the continuous power-supply cable and turn signals, and should be professionally installed. Clean installation Rear Camera: Avoid surface of windscreen heat wires in glass when attaching , the bracket should be on the right side .
- Page 30 Install near the rear vision mirror if the vehicle type is RV or Passenger car • Install near bottom area of windscreen if the vehicle type is Bus ( Not mandatory) • Install to near top of windscreen if the vehicle type is Truck . •...
- Page 31 Installation Method In order to match with the horizon accurately, it is recommended to reset camera after installation. Reset Camera When OPTIAN is re-installed to a different • ADAS+ vehicle type, it is important to reset camera first for more accurate warning functions. When OPTIAN has a delay in warning functions, •...
- Page 32 Specification The specification of OPTIAN may change without prior notice for product improvements. ADAS+ OPTIAN Name ADAS+ Full HD(1920 x 1080) Operating Front Camera 12V, 24V 100 x 82 x 42 (mm) Voltage Minimum VGA(640 x 480) Rear Camera Operating 54 x 31 x 25 (mm) Voltage Maximum...
