- Page 1 ’ WNER ANUAL STREAMER ST100 ST200...
- Page 2 You have just bought a product with exceptional audiophile performances. We really thank you for your confidence in our products. To get the best part of your streamer, please read carefully this manual. INDEX : • Index, cautions & advises ................p2 •...
-
Page 3: General Informations
GENERAL INFORMATIONS AND DVISES Your ATOLL Streamer is DLNA and UPnP compatible, it can run in a network with other devices. Take the time to read carefully the section « getting started » of this manual (page 7) before putting your unit under voltage. - Page 4 ONNECTING Rear view of Appliance: 10 11 1- Optical digital Input 7- Optical digital Output 2- Coaxial digital Input 8- Coaxial digital Output 3- USB B type Input (computer) 9- Trigger Output 4- Wifi Antenna 10- Ethernet link Input (RJ45) 5- Analog Outputs 11- USB A type Input (Hard disk, USB key) 6- Analog Inputs (x2)
-
Page 5: Remote Control
30- Input selection button: USB-B ; Coaxial ; Optical ; By-Pass (press during 2 seconds) ; Line1 ; Line2 ; Streamer. 31- IN/PR keys: keys allowing to control the integrated and Preamps Atoll devices. 32- BACK: Key return back in menus. 33- Backwards through track 34- OK: key validation in menu choices. -
Page 6: Trigger Link
Line Outputs to a By-pass Input of an Integrated. TRIGGER LINK This appliance is equipped with a Trigger that allows the switch ON/OFF of any amplifier equipped with the same kind of trigger inputs (amplifier ATOLL AM200se). Appliances must be linked as shown below: Streamer Amplifier AM200se In order that the system is operating, the ON/OFF button of your AM200se must remain in position OFF (position (0)). -
Page 7: Network Settings
3 - USES I - SETTINGS Starting: Before switching on your device, connect the cable network (type RJ45) to the connector (10). For reasons of stability of the network, the wired connection is preferred to Wifi binding when possible. Press the standby key: the led (21) flashes about 8 seconds before the display appears. Wait for the first page on display before handling. - Page 8 2/ Theme: the theme matches the background image of the screen. You can choose the theme 1 (choice of the Atoll blue background) theme 2 (white writes black), or theme 3 (zoom effect). 3/ Display Timeout: Select the time after which the display will switch off. By default, the delay is off but you can select a period of 10, 30 sec.
-
Page 9: Media Server
II - FAVORITES: This device allows you to select your favorite music or internet radio of your choice. Select a track (present on the network or on any support connected to the front or rear USB inputs) or internet radio. Press the key on the remote control ADD FAV (28) to add it to the list of favorites. - Page 10 5 - APP: A free application for iPod Touch, iPad, iPhone, and Android is available to drive your Streamer named ATOLL HD. You can download it freely on line. As a first step, make sure that your Smartphone is well connected in WIFI on the same network as your Streamer.
-
Page 11: Additional Apps
1. In Windows Media Player, right-click on the library, and then click sharing of media files. Click share my media files, and then click OK. 2. Windows Media Player looks for devices on your network. ATOLL STREAMER should appear with a green check mark. - Page 12 This device was made to give you complete satisfaction. Atoll electronics warranty is two years from the date of purchase of the equipment, date and stamp of the seller being authentic. We recommend you to keep your proof of purchase (invoice) with this coupon properly filled.
