Old Town Canoe Co. 01.1332.2406 Installation Instructions

For descriptive purposes, the "front" clamp refers to the clamp nearest the end, regardless if
installed on the bow or the stern.

Adjust Front Clamp

Loosen the wing nut on the L-shaped wooden clamp and remove the clamp, bolt, and
•
the washer.
Position outrigger so that the end overhangs the canoe by about 8 inches.
•
Replace the bolt, in another hole, if necessary, so that the clamp will grab under the
•
deck (not the grab handle—except for Stillwater Canoes).
Tighten wing nut.
•

Back Clamps

Loosen wing nut to end of carriage bolt, or remove bolt altogether.
•
Turn wooden crosspieces so that ends flare to match the hull shape, and position as
•
close to the deck as possible. Move to another hole if necessary.
Position one piece above the gunwale and one piece below.
•
Tighten wing nut.
•

Anchor Line

Thread anchor line (1/4" LINE IS RECOMMENDED AND IS NOT PROVIDED)
•
through the pulley, then swing locking cleat out and thread line through the hole. The
weight of the anchor will lock down the line on the cleat.
Tie a stopper knot near the end of the line to prevent it from pulling completely
•
through the cleat.

Extra Step

For permanent installation, drill a hole into the deck of the canoe and secure front clamp through the deck.
Old Town Canoe
35 Middle Street
Old Town, Maine 04468
207-827-5513
www.oldtowncanoe.com

Kit Contents:

Quantity
1
(The anchor and line shown are not included.)
Canoe Anchor Outrigger
Kit# 01.1332.2406 Revision 3/03
Description
Outrigger set
Page 1 of 1
Part Number
01.1332.2406
Instruction part # 01.1400.0000
