- Page 1 Installation and Operating Manual CTE 1000 Cellular Telephone Entry System CelAccess Systems, Inc. 13619 Inwood Rd., Suite 360 Dallas, TX 75244 972-231-1999 www.celaccess.com...
-
Page 2: Table Of Contents
Sub-Mode 8 (Enable/Disable 3 Strikes-You’re Out) ..............................14 Sub-Mode 9 (Program Event Input)................................... 15 Sub-Mode 0 (Erase all codes) ....................................16 Troubleshooting ..........................................16 Limited Warranty ........................................... 17 FCC Requirements ........................................18 Notes .............................................. 19 Page 2 © 2008 CelAccess Systems CTE 1000... -
Page 3: Parts Checklist
¼”-20 hex nuts Tools Needed For Basic Installation Wire nuts or appropriate terminals/connectors Wire strippers Wire cutters 3/8” drive ratchet, 6” extension, 7/16” socket Digital or Analog multi-meter Drill Technical/Customer Support 972-231-1999 info@celaccess.com Page 3 © 2008 CelAccess Systems CTE 1000... -
Page 4: Introduction
Limited use is provided for end to end testing by the installer prior to the account being created (see Installer Instructions under General Operating Instructions section below). In order to use the CTE 1000, the owner must first go to the CelAccess web site at www.celaccess.com create an account. -
Page 5: Important Tips
Installation Installation of the CTE is extremely simple. The only wires required are power and the relay to the gate or door. 1. Proper wire size is necessary for a good and trouble-free installation. Follow the tables below for your installation. -
Page 6: Mounting The Unit To A Pedestal Or Double Height Gooseneck
Wiring the Station 5. A 12VAC adapter is included to power the CTE 1000 unit. Use 12 AWG stranded wire between the 12VAC adapter and the POWER “pig tale” cables or directly to the terminal block on the CTE 1000 unit. - Page 7 CTE 1000 Keypad and Telephone Entry Circuit Board Layout Page 7 © 2008 CelAccess Systems CTE 1000...
- Page 8 CTE 1000 Cellular Interface Circuit Board Page 8 © 2008 CelAccess Systems CTE 1000...
-
Page 9: General Operating Instructions
When the CTE 1000 is powered on, it will beep three times and the LEDs on the front will light. On the Cellular Interface Board (inside the CTE 1000), the LED D6 will light indicating power. LED D2 will blink once, then go dark. -
Page 10: Receiving Calls - Allowing Access
KEYPAD USE Access and Function Codes The CTE 1000 can be programmed with up to 500 (4-digit) ACCESS codes. ALL CODE PROGRAMMING MUST BE PERFORMED AT THE KEYPAD. There are two different types of codes, Access Codes and Function Codes. -
Page 11: Good Tones And Error Tones
It simply resets the MASTER code to 1 2 5 1. A Unit Reset is provided should it ever become necessary to completely reset the CTE 1000 back to the initial factory defaults. Be careful … Unit RESET will DELETE ALL ACCESS & FUNCTION CODES and the MASTER code will be set back to 1 2 5 1. -
Page 12: Idle Mode
You will automatically be exited from the program mode if the memory reaches capacity. When memory is full, you will not be able to enter this Sub-Mode and will receive an ERROR if entry is attempted. Page 12 © 2008 CelAccess Systems CTE 1000... -
Page 13: Sub-Mode 2 (Delete Codes)
When the latch code is entered again, the RED Led will go off and the gate will close. NOTE: On gates with a timer to close the “TIMED DURATION” starts when the latch code is released. Page 13 © 2008 CelAccess Systems CTE 1000... -
Page 14: Sub-Mode 5 (Set One Shot Code)
The unit will then issue a GOOD TONE and wait for the MASTER code. If you wish to toggle the 3 Strikes You’re Out state, enter the MASTER code. If you do not wish to toggle the state, enter # to exit. Page 14 © 2008 CelAccess Systems CTE 1000... -
Page 15: Sub-Mode 9 (Program Event Input)
# to exit. If you are programming the event input as a Remote Open input, you will be prompted for which relay to activate on an event. Enter the correct relay as stated above ( + Relay to activate). Page 15 © 2008 CelAccess Systems CTE 1000... -
Page 16: Sub-Mode 0 (Erase All Codes)
Nothing happens when the call button is pressed If the external LEDs are not lit, check power to the unit. If the external LEDs are lit, then open the CT 1000. LED D6 should be lit indicating that the Cellular Interface module has power. -
Page 17: Limited Warranty
CAS; and Products that have been purchased from inventory clearance or liquidation sales or other sales in which CAS, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the Product, (collectively, “Excluded Products or Repairs”). Page 17 © 2008 CelAccess Systems CTE 1000... -
Page 18: Fcc Requirements
Governing Law: This Limited Warranty shall be governed by the laws of the Texas. FCC Requirements 1. THE CTE 1000 IS DESIGNED ONLY AS A WIRELESS SYSTEM. DO NOT CONNECT TO WIRED TELEPHONE SYSTEMS INCLUDING IN-BULDING EQUIPMENT OR TELEPHONE COMPANY SYSTEMS. IT HAS NOT BEEN CERTIFIED AS COMPLIANT WITH PART 68 OF THE FEDERAL COMMUNICATIONS COMMISSION RULES. -
Page 19: Notes
Notes Use this space to keep a record of Access Codes and the MASTER Code _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ Page 19 © 2008 CelAccess Systems CTE 1000...
