NOTE: The following applies to CE marked products only.
Declaration of Conformance – Mercury MerCruiser
This sterndrive or inboard engine when installed in accordance to Mercury
MerCruisers' instructions complies with the requirements of the following directives
by meeting the associated standards, as amended:
Recreational Craft Directive 94/25/EC; 2003/44/EC
Owner's manual (A.2.5)
Openings in Hull, Deck and superstructure (A.3.4) ISO 9093‑1; ISO 9093‑2
Handling characteristics (A.4)
Inboard Engine (A.5.1.1)
Fuel System (A.5.2)
Electrical System (A.5.3)
Steering system (A.5.4)
Exhaust emission requirements (B.2)
Owner's manual (B.4)
Noise emission levels (C.1)
Ignition‑protected equipment (Annex II)
Mercury MerCruiser declares that our sterndrive or inboard engines without integral
exhaust, when installed in a recreational craft, in accordance with the manufacturers
supplied instructions, will meet the exhaust emissions requirements of the directive
mentioned above. This engine must not be put into service until the recreational craft
in which it is to be installed has been declared in conformity, if so required, with the
relevant provision of the directive.
Electromagnetic Compatibility Directive 89/336/EC, 92/31/EEC and 93/68/EEC
Generic emission standard
Generic immunity standard
Vehicles, boats and internal combustion engine
driven devices ‑ Radio disturbance characteristics
Electrostatic discharge testing
The notified body responsible for surveillance of the quality system under Full Quality Assurance
Module H of Directive 2003/44/EC is:
Det Norske Veritas
Norway
Notified Body Number: 0575
This declaration is issued under the sole responsibility of Mercury Marine and Mercury MerCruiser.
President ‑ Mercury Marine, Fond du Lac, WI USA
Applicable Requirement
Patrick C. Mackey
Standards Applied
ISO 10240
ISO 8665
ISO 15584; ISO 10088; ISO 7840; ISO 10133
ISO 10088; ISO 7840; ISO 8469
ISO 10133; ISO 8846
Applicable portions of: ISO 10592, ISO 8848 and
ABYC P‑17
ISO 8178
ISO 8665
ISO 14509
ISO 8846; SAE J1171; SAE J1191; SAE J 2031
EN 50081‑1
EN 50082‑1
SAE J551 (CISPR 12)
EN 61000‑6‑2; EN 61000‑4‑2; EN61000‑4‑3
