Ivation Waterproof Solar-Dynamo hand crank Flashlight User Manual

Working Principle:

This product adopts the principle of cranking for power by three phase alternator and solar - energy for
power generation. The power stored is used to charge the built-in 80 mAh/3.6V Ni-MH chargeable battery
after commutating and filtering as the power source of the LED light.

Functions:

1. Cranking for power generation.
2. Charged in direct sunlight.
3. 1 LED lighting/ 3 LEDs lighting /3LEDs flashing for a circle.
4. Waterproof under 5 meters water.

Features:

1. Low noise and high efficiency.
2. Charged by direct sunlight.
3. Convenient to use, no external batteries.
4. Controlled by electric switch, long life-span.
5. Unique design,novel and fashionable.
6. It can work normally under 5 meters water.

Main Technical Parameters

Max. Luminous flux of 3 LEDs
Max. Luminous flux of 1 LED
Lighting time of 3 LEDs after being charged fully
Lighting time of 3 LEDs after 1 minute cranking
Lighting time of 1 LED after 1 minute cranking
Flashing time after 1 minute cranking
Lighting time of 3 LEDs after being charged by direct sunlight for 1 hour
Lighting time of 1 LED after being charged by direct sunlight for 1 hour
Flashing time after being charged by direct sunlight for 1 hour
Fully charged time by sunlight
Flash frequency

Main parts life-span:

LED light 50000 hours
Switch lifetime 100 000 times
The whole unit
lifetime 5 years
Plastic part lifetime 5 years

Operation Method:

1. Unlock the handle and crank it at the speed of 3 circles per second for 1 minute, press the switch, the light
will be on.
2. Place the flashlight in the direct sunlight to charge it.
3. Lighting modes: press the switch once, one LED in middle lights up; press again, three LEDs on, press for
the third time, 3 LEDs Flashing, press once more, the flashlight is off.
Cautions:
1. Do not aim at anyone's eyes in case of hurting the eyes.
2. Crank it as even as possible (keep rotating steadily). Too slowly cranking would make the current weak
and prolong the charging time, and too violent cranking will possibly damage the power transferring system.
3. Pay attention to the holding gesture when cranking, so as not to hurt your fingers and fingernails.
4. To ensure the using life of the inside battery, cranking no more than 3 minutes continuously when the the
flashlight can light normally and less than 10 minutes when it can't light.
5. Cranking the handle at least 1 minute once a month to prolong the life of product.
Distributed by C&A Marketing, Inc.
2 Bergen Turnpike
Ridgefield Park, NJ 07660
info@myivation.com
MADE IN CHINA
IVATION is a trademark of C&A IP Holdings, LLC
©2014 All Rights Reserved
WATERPROOF SOLAR/
DYNAMO HAND CRANK
FLASHLIGHT

User Guide

Power
Switch
Solar
Panel
Others:
The built-in battery specification
Solar panel

Size and Weight:

Size of this unit
Weight of this unit
3 LEDs
Handle
8Lm
3Lm
4 hours
60 minutes
80 minutes
110 minutes
90 minutes
120 minutes
140 minutes
8 hours
About 2 Hz
80 mAh, 3.6V, NI-MH battery
5.5V, 20mA
About 147.5*61.5*45mm
About 176g
