Ivation WIRELESS PORTABLE SPEAKER User Manual

Welcome
We thank you very much for choosing to purchase the Ivation wireless
portable speaker. We think you're going to be completely satisfied with
the sound it creates and with its versatility as a power amplifier for mp3
players, digital video recorders and MicroSD cards. In addition, you'll
use the speaker as a hands-free telephone as it works flawlessly with
Bluetooth technology.
Familiarize Yourself with the Controls
The IVA-S10 consists of two switches (each with multiple purposes), an
LED indicator light, a microphone port, a MicroSD slot, and a mini
USB port.
Multi-function
Button
Input Selector
Switch
What the Controls Do
The Mult-function Button in MP3 Mode
1 Push left quickly to play the previous song.
2 Push left for 3-sec to lower the volume
3 Push right quickly to play the next song.
4 Push right for 3-sec to increase the volume.
5 Push in quickly to play or pause music from a MicroSD card.
The Multi-function Button in Bluetooth Mode
1 Press in quickly for the following actions: Play/Pause, Answer,
Call/End, Call/Cancel, Dial/Enter, Pairing Mode.
2 Double-press in quickly performs a Call Redial.
3 Press in for 2-sec to perform Call Reject.
The Multi-function Button in Aux or MicroSD Mode
1 Press in for 2-sec to switch between these two inputs.
Bluetooth Pairing
1 Put the speaker's Input Selection Switch in the "Off" position.
2 Slide the Input Selection Switch in the Bluetooth position. The blue
Indicator Light will flash six times.
3 Quickly press in the Multi-function switch to begin pairing. The Indicator
Light will blink red then blue indicating that pairing is in progress.
4 Refer to the operating instructions of your cell phone or other Bluetooth
device to allow that device to search for a Bluetooth signal.
5 When your Bluetooth device asks if you wish to connect with the
speaker, select "Yes" or "Allow Connection."
6 If prompted for a pass code or PIN. enter "0000."
Note: If the connection is successful, the Indicator Light will continue
blinking red and blue.
WIRELESS PORTABLE SPEAKER

USER MANUAL

Indicator Light
The Indicator Light
1 Flashes Green: The speaker is in the MicroSD/MP3 Mode.
2 Steady Green: The MicroSD/MP3 source is functioning.
3 Flashing Blue: Bluetooth Mode has been chosen.
4 Blinking Blue+Red: Speaker is pairing with a Bluetooth device.
5 Steady Red: The speaker's battery is being charged.
6 Red Turns Off: Charging is complete.
7 Flashes Red: Low battery
Attaching the USB Patch Cord/Inserting Card
1 Insert the mini-USB plug into the speaker's mini-USB port.
2 Insert the standard-size USB plug into a USB charging port to recharge
the speaker's battery.
3 The audio mini-plug is inserted into an audio device with a matching
jack, such as a portable MP3 player.
Mini USB Plug
From
USB
Charger
Audio Mini Plug
From MP3 Player
Specification:
Battery Voltage 3.7-volts
Charging Voltage 5-volts
Battery Capacity 520-mAh
Speaker Size 1.77-in
Signal to Noise Ratio ≥95db
Distortion ≤0.5%
Dimensions 2.36-in x 2.36-in x 1.97-in
Weight 8.11-oz
Mini USB Port
MicroSD Slot
Distributed by
C&A Marketing, Inc.
2 Bergen Turnpike
Ridgefield Park, NJ 07660
info@myivation.com
MADE IN CHINA
IVATION is a trademark of
C&A IP Holdings, LLC
©2014 All Rights Reserved
