Table of Contents Introduction Capacities and Specific- ations About This Supplement.........3 Motorcraft Parts..........26 Product History..........4 Technical Specifications......26 At a Glance Warranty Terms and At a Glance............5 Conditions Base Warranty..........28 Instrument Cluster Warning Lamps and Indicators....9 Fuel and Refueling Fuel Quality - Gasoline.........10 Transmission Manual Transmission........11 Stability Control...
Page 5
Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
We are confident that our dedication to performance, Congratulations on your decision to quality, craftsmanship and customer purchase or lease the latest from Ford service will provide many miles of Performance the Fiesta ST. If you have...
The Ford Special Vehicle Team (SVT) was TeamRS subsequently created the 2004 established in 1991 to polish the Ford Oval Fiesta ST, 2005 Focus ST and 2009 Focus by creating low-volume, factory-produced vehicles designed for those select few...
17 inch x 7.0 inch wheels with 47.5 • ST-tuned 55 millimeters (2.17 inches) millimeter offset exhaust system with dual tips • P205/40-R17 Bridgestone RE050A • Ford B6 6-speed manual transaxle summer-only tires • Sound symposer • Optional P205/40-R17 Michelin Pilot • ST-tuned electric power assisted...
At a Glance Vehicle Specifications E163960 Item Description Transmission Ford B6 6-speed manual with 228 millimeter clutch and dual mass flywheel Gear ratios Gear Ratio Final drive 3.727 3.82 2.098 3.82 1.357 3.82 1.030 3.82 0.821 3.82 0.690 3.82 Reverse 3.818...
Page 10
At a Glance Engine Specifications Item Description Configuration Transversely mounted I4, cast aluminum cylinder block and cylinder heads Bore x stroke 79.0 mm bore x 81.4 mm stroke (3.11 in. x 3.20 in.) Displacement 1597 cubic centimeters (97 cubic inches) Compression ratio 10.0:1 Horsepower...
Page 11
At a Glance Item Description Rear spring rate 25 N/mm (143 lb/in) Front stabilizer bar 19 mm (0.75 in) diameter Rear stabilizer bar Not applicable Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
Instrument Cluster WARNING LAMPS AND INDICATORS Gauges E162329 Tachometer Information display Speedometer Fuel gauge Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
Fuel and Refueling • Fuels containing the octane booster FUEL QUALITY - GASOLINE additive, methylcyclopentadienyl manganese tricarbonyl (MMT). Choosing the Right Fuel • Leaded fuel (using leaded fuel is prohibited by law). The use of fuels with metallic compounds such as methylcyclopentadienyl manganese tricarbonyl (commonly known as MMT), which is a manganese-based fuel additive, will impair engine...
Transmission 3. Press the brake pedal and shift the MANUAL TRANSMISSION gearshift lever to first or reverse gear. Using the Clutch 4. Release the parking brake and slowly release the clutch pedal while slowly Note: Failure to fully depress the clutch pressing on the accelerator.
Page 15
Transmission E99067 If reverse gear is not fully engaged, press the clutch pedal down and shift the gearshift lever to the neutral position. Release the clutch pedal for a moment, then raise the collar and shift the gearshift lever to reverse again. Parking Your Vehicle WARNING Do not park your vehicle with the...
Stability Control (If Equipped) USING STABILITY CONTROL The AdvanceTrac system includes traction control and electronic stability control. See the Traction Control and Stability Control chapters of the Owner's Manual for more information. AdvanceTrac provides three modes of operation specially calibrated for your vehicle.
Page 17
Stability Control (If Equipped) Enhanced Torque Vectoring Control Enhanced torque vectoring control is comprised of two elements: • Torque vectoring control which applies brake torque on the inner wheel in a curve for better traction and less understeer • Cornering understeer control which controls the yaw response of the vehicle under braking and acceleration on high and low friction surfaces.
Driving Hints care if using automated commercial car BREAKING-IN washes. Do not drive through car washes with the vehicle heavily loaded (multiple Your vehicle does not need an extensive passengers or luggage). Use only break–in. Try not to drive continuously at commercial car washes without the same speed for the first 1000 miles mechanical tracks or hand wash to avoid...
Page 19
Driving Hints Note: The overboost feature controls a variety of engine parameters to deliver additional torque. Overboost is built into the engine calibration on your ST vehicle and no action is required by the driver to engage. Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
When towing with a flatbed, 4x4 blocks may help prevent damage when loading or unloading your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Note: If the vehicle is towed by other means or incorrectly, vehicle damage may occur.
Wheels and Tires • When installing wheels, always torque WHEELS lug nuts to specification with a torque wrench. Your ST vehicle is equipped with unique wheels matched to the tires. These wheels • Inspect your wheels for damage on a are more susceptible to damage due to regular basis.
Always maintain your tire pressures designed for winter use on ice or snow and according to the tire information cannot be used with snow chains. Ford placard on the driver door jamb, using does not recommend using the original an accurate gauge.
Required wheel 205/40 R17 Original equipment ST wheel or equivalent 195/45 R16* Owner supplied. See your Ford dealer for suitable wheels from the Fiesta lineup. * Required size to prevent vehicle damage if snow chain use is required System reset tips:...
Wheels and Tires 4. Turn the hazard flashers on then off Turn the ignition off. If you hear the three times. You must accomplish this horn sound twice, the reset procedure within 10 seconds. If you have entered was unsuccessful and you must the reset mode successfully, the horn repeat it.
Page 27
Wheels and Tires The following table lists the specifications should match those of the originally for the full size spare tire and wheel equipped tires as closely as possible. assembly. Tire speed and load ratings Spare tire Size 185/60 R15 Speed rating Load rating Usage...
Make sure that any Torque specifications are for nut and bolt fasteners that attach the rotor to the hub threads free of dirt and rust. Use only Ford are secured so they do not interfere with recommended replacement fasteners.
CYFS12Y2 (100000 mile service) If a Motorcraft oil filter is not available, use We recommend Motorcraft replacement an oil filter that meets industry parts available at your Ford dealer or at performance specification fordparts.com for scheduled maintenance. SAE/USCAR-36. These parts meet or exceed Ford Motor Company’s specifications and are...
Page 30
Do not use supplemental engine oil additives because they are unnecessary and could lead to engine damage that may not be covered by your vehicle warranty. Add the coolant type originally equipped in your vehicle. Description Code Ford B6 6-speed manual transaxle Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
Ford Fiesta models. This information is covered in its entirety in the warranty information. You can obtain warranty service for your ST vehicle or any ST vehicle at any Ford dealer nationwide. Ford Global Performance does not recommend modifying or racing ST, SVT...
Page 32
Reverse...............11 Using the Clutch.............11 Motorcraft Parts..........26 Capacities and Specifications....26 Technical Specifications........26 Changing a Road Wheel......23 Product History..........4 Full Size Spare............23 FORD PERFORMANCE.........4 Wheel Lug Nut Torque Specifications..25 TEAM RS HISTORY..........4 Driving Hints............15 Roadside Assistance........17 Roadside Emergencies........17 Running-In See: Breaking-In.............15 Engine Oil Dipstick..........19 Engine Overboost...........15...
Page 33
Index Under Hood Overview........18 Using Stability Control........13 Enhanced Torque Vectoring Control....14 Using Winter Tires...........21 Warning Lamps and Indicators....9 Gauges................9 Warranty Terms and Conditions....28 Wheel Nuts See: Changing a Road Wheel......23 Wheels and Tires...........20 Technical Specifications........25 Wheels...............20 Winter Tires See: Using Winter Tires........21 Fiesta (CCT) Canada/United States of America, enUSA, First Printing...
