- Page 1 X360 | Dual Lens VR Camera USER GUIDE...
- Page 4 Join the social movement and follow us on Share your footage with us on our social media #ChallengeYourself Need help? www.kaiserbaas.com/support To view the entire Kaiser Baas product range and accessories visit: www.kaiserbaas.com X360 | User Guide...
- Page 5 Languages English 4 - 31 Français 32-59 Espaná 60-87 X360 | User Guide...
-
Page 6: Table Of Contents
Table of Contents Safety Precautions What’s in the Box 9-10 Product Diagram Set Up Your X360 Camera Using Your X360 Camera Charging the battery Video Mode Picture Mode Menu Settings Connecting X360 to a Smartphone/Tablet App Interface Diagram Using with VR-X Headset Playback 360°... -
Page 7: Safety Precautions
Before using the X360 Camera please ensure you read and understand the safety precautions. • Do not attempt to open the case of the X360 or modify it in any way. If the X360 has been opened the warranty will be void. -
Page 8: What's In The Box
What’s in the Box Please ensure the product package has the following contents: Flat and Curved Mount with 3M X360 Dual Lens VR Camera Pads and Lock Bolt Gorilla Tripod Quick Release Mount USB Cable Carry Bag GoPro™ Tripod Adaptor... -
Page 9: Product Diagram
Product Diagram Power Button (Mode) Wi-Fi Button (Menu, Scroll) Power Indicator Wi-Fi Indicator Lens Display Record Button (OK Button) Top View X360 | User Guide... -
Page 10: Product Diagram
Product Diagram Micro USB Micro SD card Reset Button Right View Front View X360 | User Guide... -
Page 11: Set Up Your X360 Camera
Micro SD Card into the slot. Do not force the card into the card slot, as it may damage both the X360 and the Micro SD Card. It is recommended that you format new cards or cards that have been previously used in other devices. - Page 12 To turn the X360 ON, press and HOLD the Power button for 3 seconds. Hold the power button When the X360 is turned ON, “Initializing” will appear on the screen and the Red LED will flash. The X360 is now in Video Mode.
-
Page 13: Using Your X360 Camera
Using Your X360 Camera Charging the battery Before using the X360 for the first time it is recommended that you fully charge the battery. Procedure: 1. Connect the X360 to an electronic device using the USB cable provided. 2. If using a wall charger, ensure that it is a certified product for your region. -
Page 14: Video Mode
When recording commences, you will see the red light on the X360 start flashing. To end recording, press the Record Button again. Note: To watch the preview, you will need to connect the X360 Camera to a smartphone/tablet device. Please refer to page 17 “Connecting the X360 to a Smartphone”... -
Page 15: Picture Mode
This mode will allow you to take snapshots. To activate this mode: Turn the X360 ON. Once it is ON, press and release the Power button. This will switch the camera from Video Mode to Picture Mode. Note: Do not hold the power button as it will turn the camera off. -
Page 16: Menu Settings
To exit any menu item, press and hold the Wi-Fi Button for 3 seconds. Power Save This will set the X360 to automatically power off after 1 minute, 3 minutes or 5 minutes. Select OFF to keep the X360 ON during periods of inactivity. -
Page 17: Connecting X360 To A Smartphone/Tablet
Camera unit, once the WiFi is turned ON (the default password is 1234567890). Note: Wi-Fi will be turned off automatically if the X360 is not connected to a device within 2 minutes. 6. Once your device is connected to the X360, launch the ‘Kaiser Baas X360’... - Page 18 After the first setup of the camera you must click the camera icon on the top right [See Diagram] to connect the camera to your device. Click To Connect X360 | User Guide...
-
Page 19: App Interface Diagram
App Interface Diagram Record Duration X360 Battery Status Invert View Gyro Mode Reset Video Explore Mode Dome Mode VR Mode Settings Gallery Capture Mode Record Button X360 | User Guide... -
Page 20: Using With Vr-X Headset
Using with VR-X Headset The X360 Camera is designed to work seamlessly with a Kaiser Baas VR-X Headset or Google Cardboard VR Viewers. To watch your footage using a VR-X Headset or Google Cardboard VR Viewer, simply tap this icon on the Kaiser Baas X360 app screen. -
Page 21: Playback
Playback 360° Video Footage The X360 records footage from both lenses onto one video file. This means you must use Playback software on your smartphone/tablet to view the footage interactively or use a PC/Mac playback software. Playback using X360 App To watch recorded videos, you need to connect the X360 to a Smartphone via Wi-Fi. -
Page 22: Downloading Video File To Smartphone/Tablet
Format This will format the Micro SD card and permanently erase all data on the card. Use wisely. Change Wi-Fi Password This will allow you to change the Wi-Fi password of the X360 Camera. X360 | User Guide... -
Page 23: Transferring Files To Pc
Transferring files to PC Once you have captured videos on your X360, you are able to transfer them onto the computer for playback. Using the Micro USB cable supplied, connect the X360 to your computer. Mass Storage Mode (MSDC) will appear on the X360 screen and the computer will detect the X360 as an external storage device. - Page 24 YouTube and Facebook support uploading and playback of 360° interactive videos. In order to upload a 360° video file, you’ll need to convert the spherical video file to panoramic video through the X360 Video Processing Tool application. X360 | User Guide...
-
Page 25: Converting Spherical 360 Video To Panoramic Video
Converting Spherical 360 Video to Panoramic Video 1. Download the X360 Video Processing Tool application from http://kaiserbaas.com/apps/x360-app/ 2. Install it on your PC and launch the X360 Video Processing Tool application. 3. Import the 360° Video file that is saved on your computer. - Page 26 HD may take significantly longer to appear in HD quality. Tip: You can also watch 360° videos on YouTube apps for Android and iOS. You can watch 360° videos in VR mode directly from YouTube with the Kaiser Baas VR-X Headset or Google Cardboard viewer.
- Page 27 360° format. This will allow your video to have the interactive 360° controls available. 4. Click the 360 Controls tab to be able to set the initial camera orientation and field of view for your video. 5. Click Publish. X360 | User Guide...
-
Page 28: Camera Reset
Camera Reset X360 Camera has a hard Reset button. This allows you to reset the camera to the factory default settings. If the camera becomes non responsive or frozen. Please reset using this button. Use a small pin to push the reset button whilst the camera is ON. -
Page 29: Faq
Q. What is the range of Wi-Fi? Up to 32 meters. Q. My phone/tablet will not connect to the X360 via WIFI? Ensure the 360 camera WIFI has not been disabled. You will see the Wi-Fi indicator on the camera screen if the Wi-Fi is active. -
Page 30: Specifications
Micro SD card up to 32GB (not included) Microphone In-Built Connectivity Wi-Fi Interface Micro USB Display 1” LCD Battery Built-in 3.8V/1500mAh Li-Battery Battery Life 80 minutes recording Language English, French, Spanish, Chinese Dimensions 60 x 48 x 50 mm Weight 106g X360 | User Guide... -
Page 31: Contact Us
Contact Us Need further assistance? Please visit: www.kaiserbaas.com/support Or email: helpdesk@kaiserbaas.com To view the entire Kaiser Baas product range and accessories visit: www.kaiserbaas.com X360 | User Guide... - Page 32 CHALLENGE YOURSELF...
