CR-60 Cornerounder
Before operating this equipment, please read these
instructions completely and keep these operating
instructions for future reference.
485 Hague Street, Rochester, NY 14606 U.S.A.
Tel: 585-436-1934
www.lasscowizer.com
Serial Number:
Date of Purchase:
Dealer:
Address:
Telephone Number:
Fax: 585-464-8665
info@lasscowizer.com
ProSource Packaging, Inc.
14911 Stuebner Airline Suite A
Houston, TX 77069
800-203-0233
www.Machine-Solution.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR-60 Cornerounder and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lassco Wizer CR-60 Cornerounder

  • Page 1 CR-60 Cornerounder ProSource Packaging, Inc. 14911 Stuebner Airline Suite A Houston, TX 77069 800-203-0233 www.Machine-Solution.com Serial Number: Date of Purchase: Dealer: Address: Before operating this equipment, please read these instructions completely and keep these operating Telephone Number: instructions for future reference.
  • Page 2 Introduction Introduction Thank you for your purchase of the CR-60 Cornerounder . We ask that you take a moment to fill in the serial number and other information on the front cover of this manual. Please keep this manual as a reference for future use.
  • Page 3 Introduction Safety Instructions All operators must read and understand the Users Manual and all other safety instruc- tions before using this equipment. Failure to fully understand the safety instructions can result in personal injury. If after reading the manual you are still uncertain about use, please contact the dealer from whom you purchased the machine for assistance.
  • Page 4: Setting Up Your Machine

    Setting Up Your Machine Attaching the Press Handle Insert the Press Handle into the hub of the press and tighten the setscrew onto the Press Handle with a M4 Hex Key until the Press Handle is secure. Press Handle M4 Hex Key Page 03...
  • Page 5 Operating Instructions Rounding The Corners To put a Radius on the corner of your product: With the Press Handle in the up position as shown, slide the product to be cut along the guide until it comes to rest against the inside edge of the Outer Knife. Hold the product in place firmly with one hand.
  • Page 6 Operating Instructions Changing The Table Assembly To remove the Table Assembly... Rotate the Press Handle to its full upright position so that the Chrome Knob is disengaged from the Rack Support Plate. Using a 5/8” Wrench (not provided) loosen, but do not remove the 7/16”-20 x 1” Hex Head Table Mount Bolt.
  • Page 7: Maintenance

    Maintenance Adjusting the Outer Knife It is important to keep the Outer Knife in proper alignment or it Table Assembly Top View can be pressed down at an incorrect angle causing unneces- sary stress on the knife. This can cause the Outer Knife to dull quicker and/or break.
  • Page 8: Troubleshooting Guide

    Trouble Shooting Guide Problem Cause Correction Debris is wedged between the Remove obstruction. Excessive burrs appear on Outer Knife and the Disk Knife the edge of the product being cut. Outer Knife is out of adjusment. Adjust per the Maintenance portion of this manual.
  • Page 9: Parts Diagrams

    Parts Diagrams CR-60 Arbor Press Rack Shroud Top (60-05) Press Handle (60-08) Rack Shroud (60-04A) Arbor Press (60-01) Rack (60-06) Rack Support Plate (60-07) Wooden Base (60-02) 7/16” Flat Washer 7/16”-20 x 1” Hex Head Table Mount Bolt Page 08...
  • Page 10 Parts Diagrams Table Assembly *Please note your Table Assembly may look slightly different depending on the size. Front View Chrome Knob Outer Knife Safety Guard Side Guide Table Disk Knife Welded Wraparound Top View Table Side Guide 6/32 x 1/4 Button Head Screw 10/32 x 1/2 Flat Head Screw Disk Knife Cam Adjustment Screw...
