Summary of Contents for diluo K1500186-040
- Page 1 Baby meal brewer User manual Art.nr K1500186-040 www.mydiluo.se Rev. P02, 2015-06-03...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT INFORMATION DISPOSAL OVERVIEW OF THE APPLIANCE BEFORE USE USING THE APPLIANCE - Filling with water - Fitting the bottle - Filling with powdered formula - Signals MAKING THE FORMULA CLEANING - Daily cleaning - Cleaning as required - Descaling TROUBLESHOOTING TECHNICAL DATA CONTACT... - Page 3 Damage If the supply cable is damaged, do not operate the appliance. A damage cable must be replaced by a Diluo approved service center. The cable must not be folded, clamped or pulled along sharp edges, nor placed at hot surfaces or in contact with chemicals.
-
Page 4: Disposal
The appliance’s bottle holder is designed to hold the most common wide Bottle -neck type bottles on the market. Should your bottle not fit, do not force it into place. The appliance is fitted with a sensor which senses when the bottle is in place. -
Page 5: Overview Of The Appliance
OVERVIEW OF THE APPLIANCE... -
Page 8: Before Use
BEFORE USE - Place the appliance on a flat surface. - Insert the plug (17) into an earthed wall socket. - Switch the power on (16) on the back of the appliance. - Fill with water – see ‘Filling with water’ under ‘Using the appliance’. - Fill with powder –... -
Page 9: Fitting The Bottle
Fitting the bottle - Choose any wide-neck type bottle (7). - Push the bottle into the bottle holder (6). - Make sure that the bottle is straight and is pushed in all the way. Filling with powdered formula - Open the front cover (1). - Pull the powder container out (10) using the handle (19). - Page 10 - Lift the lid (18) of the powder container and move the leveller (28) to the mark in the powder container. See the picture below. - Check that the powder level indicator (24) is fully in its grooves on the powder container, and that it is pointing straight down.
-
Page 11: Signals
Signals The appliance has a signalling system for different kinds of faults. Light signals (15) behind the water container and in the buttons (see the illustration, right) indi- cate as described below. During use - A constant white light behind the water container and on the selected button indicates that the appliance is working. -
Page 12: Making The Formula
MAKING THE FORMULA - Choose a large enough bottle for the selected portion size. - Make sure the bottle is properly fitted in the bottle holder. - Press the button for the desired portion size to begin preparation, or - Select the desired portion size and start preparation via the app. - When the formula is ready there is a green light in the water contain- er and the bottle can be removed. - Page 13 - Disconnect the outlet hose (13) from the mixing funnel (12). - Remove the mixing funnel and impeller by pulling them straight out.
- Page 14 - Remove the mixing funnel attachment (22) by turning it to the right to detach, and then pull it straight out. - Remove the mixing funnel lid (21) by turning it counter clockwise and lifting it up. - Rinse and wipe clean all loose parts before replacing them.
-
Page 15: Cleaning As Required
Cleaning as required To access other parts for cleaning, they must be removed from the appli- ance. Do this following the instructions below. The parts should be replaced in reverse order. The overflow tray (9) is lifted straight up from the appliance. The tray cover (8) is loose and can simply be taken off. - Page 16 - If further cleaning and dismantling is needed, loosen the powder out- let locking nut (20) and carefully pull it out of the powder container. - Loosen the locking peg (26) which holds the stirrer (29) and leveller (28) in place by squeezing the sides together and pushing down.
- Page 17 - Once the locking peg has been loosened, the stirrer and leveller can be lifted upwards. - Loosen the dosage screw’s locking nut (25) by turning it counter clock- wise.
-
Page 18: Descaling
- Remove the loose parts from the powder container. Descaling - Mix 15 grams of citric acid or acetic acid with 1 litre of water in the wa- ter container. - Place a vessel that can take at least 1 litre under the appliance’s outlet. - Hold the Cleaning button in for 10 seconds to start the descaling pro- cess. -
Page 19: Troubleshooting
TROUBLESHOOTING Problem Cause Action Switch on the power on the back of the appli- The power switch is not on. The appliance does not ance react. nsert the plug into an The appliance is not plugged in. earthed wall socket. The appliance is indicating Check the water and that water or powder... -
Page 20: Technical Data
1.2 m 220-240 V, 50-60Hz, 1800 W All materials that come into contact with food meet European Parlia- ment and Council Regulation 1935/2004. CONTACT Diluo i Karlstad AB Tel: +46 (0)10-410 17 20 Pumpgatan 4 info@mydiluo.se SE-652 21 Karlstad, Sweden www.mydiluo.se...
