TX-33AK10P Service Manual Service Support Specifications Parts List Service and repair of this product is supported by Panasonic's LUCI interface. This interface provides Block Safety a link between the TV and Diagrams a standard PC to allow a number of diagnostic and...
CONTENTS SAFETY PRECAUTIONS................................2 SERVICE HINTS ..................................3 SERVICE POSITION.................................4 ADJUSTMENT PROCEDURE AND SELF CHECK........................5 WAVEFORM PATTERN TABLE ...............................6 ALIGNMENT SETTINGS................................7 BLOCK DIAGRAMS ..................................8 PARTS LOCATION .................................12 REPLACEMENT PARTS LIST ..............................13 SCHEMATIC DIAGRAMS ...............................33 CONDUCTOR VIEWS................................41 SAFETY PRECAUTIONS GENERAL GUIDE LINES It is advisable to insert an isolation transformer in the Check each exposed metallic part and check the a.c.
SERVICE HINTS How to remove the rear cover 1. Remove the 10 screws as shown in Fig.2. SCREWS SCREWS Fig.2. LOCATION OF CONTROLS Y-Board K-Board F-Board G-Board Focus Concentration Z-Board Screen H-Board E-Board D-Board V-Board N-Board M-Board Q-Board...
HOW TO MOVE THE CHASSIS INTO SERVICE POSITION Remove the bead clamper from the mains lead and affix, using back cover screw, into top right-hand cabinet rib (A), shown in Fig.3. Remove 2 screws (B), as shown in Fig.4, and remove speaker assembly. Hold and lift the rear of the chassis and gently pull the chassis toward you, as shown in Fig.3.
ADJUSTMENT PROCEDURE Item / Preparation Adjustments +B SET-UP Set the +B voltage up as follows:- Receive a Greyscale signal. Adjust R811 so that B2 shows 148V±1V. Set the controls :- Confirm the following voltages. PIN5 147V ± 3V E19-PIN8 ± 0,5V Brightness Minimum PIN5 5V...
WAVEFORM PATTERN TABLE NOTE: All waveforms have been taken using a standard colour bar pattern. Vert Drive VFLB Vert Out IC451 Pin 2 IC451 Pin 5 IC601 Pin 1 8.6mS 8.6mS H - Out HFLB Video In IC601 Pin 8 IC601 Pin 13 IC1101 Pin 68 64µS...
ALIGNMENT SETTINGS: (The figures below are nominal and used for representative purposes only.) Set the Bass to maximum position, set the Treble to minimum position, press the down button (- / v) on the customer controls at the front of the TV and at the same time press the INDEX button on the remote control, this will place the TV into the Service Mode.
Page 27
Cct Ref Parts Number Description Cct Ref Parts Number Description 220nF 82pF C372 ECUV1H224ZFX S.M. CAP C624 ECUV1H820JCX S.M. CAP 100nF 47pF C373 ECUV1H104KBX S.M. CAP C625 ECUV1H470JCX S.M. CAP 100nF 47pF C374 ECQM2104KZ FILM 250V C626 ECUV1H470JCX S.M. CAP 47pF C375 ECKC2H102J...
Page 28
Cct Ref Parts Number Description Cct Ref Parts Number Description 2.2nF 100nF C872 ECA1CM222E ELECT C1522 ECUV1H104ZFX S.M. CAP 30pF 100nF C901 ECUV1H030CCX S.M. CAP C1523 ECUV1H104ZFX S.M. CAP 100µF 47µF C902 ECA1VM101GB ELECT C1524 ECA1VM470B ELECT 10nF 100nF C904 ECJ2VF1H103Z ELECT 350V...
Page 29
Cct Ref Parts Number Description Cct Ref Parts Number Description 100nF 100nF C1591 ECUV1H104ZFX S.M. CAP C1664 ECUV1H104ZFX S.M. CAP 220µF 39pF C1592 ECA1CM221GB ELECT C1666 ECUV1H390JCX S.M. CAP 220µF 82pF C1593 ECA1CM221GB ELECT C1667 ECUV1H820JCX S.M. CAP 100nF 68pF C1594 ECUV1H104ZFX S.M.
Page 30
Cct Ref Parts Number Description Cct Ref Parts Number Description C2135 ECUV1H070DCX S.M. CAP C2401 ECUV1H102KBX S.M. CAP 100nF C2137 ECUV1H104ZFX S.M. CAP C2402 ECUV1H102KBX S.M. CAP 3.3nF C2138 ECUV1H010CCX S.M. CAP C2403 ECUV1H332KBX S.M. CAP 3.3nF C2139 ECUV1H010CCX S.M. CAP C2404 ECUV1H332KBX S.M.
Page 31
Cct Ref Parts Number Description Cct Ref Parts Number Description 330nF 1µF C2523 ECJ2VF1C334Z ELECT 350V C2664 ECA1HM010GB ELECT 330nF 2.2nF C2524 ECJ2VF1C334Z ELECT 350V C2665 ECUV1H222KBX S.M. CAP 10µF 1µF C2526 ECA1CM100GB ELECT C2666 ECA1HM010GB ELECT 330nF 10nF C2527 ECJ2VF1C334Z ELECT 350V...
SCHEMATIC DIAGRAMS FOR MODEL TX-33AK10P (EURO-5 CHASSIS) IMPORTANT SAFETY NOTICE Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturers' specified parts. NOTE RESISTOR All resistors are carbon ¼W resistor, unless marked otherwise.
