- Page 1 ITEM:88173 4" ANGLE GRINDER Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference. For questions about this product, Please call 1-866-915-8626...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING : When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas can cause injuries. 2.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS 15. USE EYE PROTECTION. Use a full-face mask if the work you’re doing produces metal filings, dust or wood chips. Goggles are acceptable in other situations. Wear a clean dust mask if the work involves creating a lot of fine or coarse dust.
- Page 4 FUNCTION DESCRIPTION Functional description: 1. On-Off switch 2. Side Handle 3. Spindle lock 4. Wheel Guard 5. Wheel OPERATING PROCEDURES Grinding and Cut-off Wheels This angle grinder is designed to accept only 4 ” abrasive discs with a 5/8” bore. Check to ensure that any discs used on this machine are rated for the 11,500 /min speed of this grinder.
- Page 5 OPERATING PROCEDURES ADJUSTMENTS Guard This grinder comes with an adjustable wheel guard installed. This is to allow you to grind at various angles and still be protected to some extent from flying residue or debris. Unplug the grinder. Loosen the clamping screw on the collar and rotate the guard to give you protection and expose the disc on the appropriate side.
- Page 6 PARTS LIST ADJUSTMENTS Please refer to the schematic drawing on page 7. Oil bearing...
- Page 7 SCHEMATIC DRAWING...
