- Page 1 DP-201 MKII digital piano user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 27.11.2015, ID: 358343...
-
Page 3: Table Of Contents
7.6.16 Chorus effects ratio....................25 Functions..........................26 8.1 Playing demo sequences................... 26 8.2 Reverb effect........................26 8.3 Chorus effect........................27 8.4 Selecting timbre......................27 8.5 Split mode........................27 8.6 Dual mode........................28 8.7 Twin mode........................28 8.8 Metronome........................28 DP-201 MKII... - Page 4 Table of contents 8.9 Tempo / Tap function....................29 8.10 Recording function....................30 Troubleshooting........................31 MIDI implementation chart..................... 32 Technical specifications....................34 Protecting the environment................... 35 digital piano...
-
Page 5: General Information
The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . DP-201 MKII... -
Page 6: Symbols And Signal Words
General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Cross-references References to other locations in this manual are identified by an arrow and the speci‐... -
Page 7: Safety Instructions
With loudspeakers or headphones connected, the device can produce volume levels that may cause temporary or permanent hearing impair‐ ment. Do not operate the device permanently at a high volume level. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment. DP-201 MKII... - Page 8 Safety instructions CAUTION! Risk of injury due to heavy weight Due to the heavy weight of the device, at least two persons are required for transport and installation. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture.
-
Page 9: Features
Polyphony: 64-voice Recording capacity: 50.000 notes Reverb and Chorus effects Integrated metronome Dual and Split mode Connections: Sustain pedal, headphones, line OUT, line IN, USB to Host Music stand, Sustain pedal and 12 V power adapter included Automatic shutoff DP-201 MKII... -
Page 10: Assembly Instructions
Assembly instructions Assembly instructions You need a Phillips screwdriver (not supplied) for the assembly of the digital piano. Open the package and please make sure before assembling that the entire scope of delivery is present, as posted here. Digital piano housing with music stand Left side panel Right side panel Back panel... - Page 11 Screw the rear cover to both side panels as shown using the four barrel nuts and the four Phillips screws M6 ´ 55. DP-201 MKII...
- Page 12 Assembly instructions Place the digital piano case on the frame and secure it with the four Phillips screws M6 ´ 16. Attach the headphones holder using the four Phillips screws M4 × 12 on the bottom side of the digital piano housing. Move the digital piano to its designated location. digital piano...
- Page 13 Now you can turn on the device. If the piano is not in use or when a thunderstorm with danger of lightning threatens, disconnect the device from its mains power for safety. DP-201 MKII...
-
Page 14: Connectivity Options
Connectivity options Connectivity options Headphones The headphones output is located on the rear side of the housing. Connecting headphones (not supplied) to this output socket mutes the internal sound system. Pedal Connect the supplied Sustain pedal to the provided connector on the bottom side of the housing. -
Page 15: Control Panel And Connections
Button to engage the Chorus effect. 7 [TOUCH] Key to adjust the touch sensitivity. 8 [TEMPO / TAP] Button to set the playback speed (along with the arrow buttons [TRANS]). 9 [METRONOME] Button to turn the metronome on and off. DP-201 MKII... - Page 16 Control panel and connections 10 [TRANS] Keys to increase or decrease the currently displayed value. 11 [FUNCTION] Button to call the function menu. 12 [ENTER] Button to confirm changes and input values as well as to open the various submenus. 13 Display.
- Page 17 Input socket for connecting an external audio device. 25 [LINE OUT] Output socket for connecting the digital piano to an amplifier, stereo system, mixer or recording device. 26 [PHONES] Headphones jack (1/4" phone socket). 27 12 V connector for voltage supply. DP-201 MKII...
-
Page 18: Operating
Operating Operating 7.1 Turning on / off Press the [STANDBY/ON] main switch to the left on the operating panel to turn the device on and off. If the display does not light up after switching on the digital piano, check the power supply. -
Page 19: Setting The Touch Sensitivity
PAN effect first voice M.Pan –64 … 63 PAN effect second voice, Split mode L.Pan –64 … 63 PAN effect second voice, Dual mode S.Pan –64 … 63 Activating sound system Local ON/OFF Pedal function Pedal Pedal/Pedals Pedal DP-201 MKII... -
Page 20: Transposing
Operating Function Display Range Standard Volume first voice M.Vol 0 … 127 Volume second voice, Split mode S.Vol 0 … 127 Volume second voice, Dual mode D.Vol 0 … 127 Metronome volume MetroVol 0 … 127 Reverb effects ratio R.Lvl 0 …... -
Page 21: Octaving First Voice
Confirm with [ENTER] and use the arrow buttons [TRANS] to mark the item ‘D.Oct’ . Confirm with [ENTER] and shift the octave with the arrow buttons [TRANS] in a range of –2 … 2. Press both arrow buttons [TRANS] simultaneously to reset the value to the preset ‘000’ . DP-201 MKII... -
Page 22: Pan Effect First Voice
Operating 7.6.6 PAN effect first voice With this function you can adjust the PAN effect of the first voice. Use [FUNCTION] to open the functions menu. Use the arrow buttons [TRANS] to proceed to submenu ‘Performa’ . Confirm with [ENTER] and use the arrow buttons [TRANS] to mark the item ‘M.Pan’... -
Page 23: Activating Sound System
With this function you can adjust the volume of the second voice in Split mode. Use [FUNCTION] to open the functions menu. Use the arrow buttons [TRANS] to proceed to submenu ‘MIXTER’ . Confirm with [ENTER] and use the arrow buttons [TRANS] to mark the item ‘S.Vol’ . DP-201 MKII... -
Page 24: Volume Second Voice, Dual Mode
Operating Confirm with [ENTER] and adjust the setting with the arrow buttons [TRANS] in a range of 0 … 127. Press both arrow buttons [TRANS] simultaneously to reset the value to the preset ‘127’ . 7.6.13 Volume second voice, Dual mode With this function you can adjust the volume of the second voice in Dual mode. -
Page 25: Chorus Effects Ratio
[TRANS] in a range of 0 … 127. Press both arrow buttons [TRANS] simultaneously to reset the value to the preset ‘036’ . If you don't make a selection within five minutes, the open menu will be closed. DP-201 MKII... -
Page 26: Functions
Functions Functions 8.1 Playing demo sequences 16 demo sequences are stored in the memory of the digital piano. Press [DEMO] to enter the DEMO mode. The first demo song is shown and played. During playback, you can use the arrow buttons [TRANS] to switch between the demo songs at will. Press [DEMO] again to stop playback. -
Page 27: Chorus Effect
Use the one-touch timbre buttons to select the voice you want to assign to the right hand. Press [SPLIT] to activate the Split mode. ð The display shows the number and name of the preset second voice. Use the arrow keys [TRANS] to select the left hand voice. DP-201 MKII... -
Page 28: Dual Mode
Functions Split point setting Using this function you can select a point to split the whole claviature into two areas. Keep the [SPLIT] button pressed. Press that key of the claviature where you want to set the split point to. The new split point is instantly applied. -
Page 29: Tempo / Tap Function
4/4 time. Press [TEMPO/TAP] three times in the desired tempo. This tempo is then applied as playback speed in 3/4 time. Press both arrow buttons [TRANS] simultaneously to reset the value to the preset ‘120’ . DP-201 MKII... -
Page 30: Recording Function
Functions 8.10 Recording function Recording user tracks The digital piano offers two tracks for user recordings. Press [RECORD] and [TRACK 1] simultaneously for recording to track 1. ð The LEDs of the buttons light up. The recording starts when you begin playing. Press [RECORD] again to stop recording. -
Page 31: Troubleshooting
On activating, the display shows ‘Local On’ . Malfunction occurs when using a mobile phone. Using a mobile phone near the digital piano can cause inter‐ ference. To prevent this, turn off the mobile phone or use it only at a safe distance. DP-201 MKII... -
Page 32: Midi Implementation Chart
MIDI implementation chart MIDI implementation chart Function Sent Received Notes Basic Channel Default 1 – 16 1 – 16 Changed 1 – 16 1 – 16 Mode Default Mode 3 Mode 3 Messages Altered Note Number 0 – 127 0 – 127 True voice 0 –... - Page 33 All Notes Off Active Sensing System Reset Notes: Registered parameter number: #0: Pitch sensitivity #1: Fine tuning cents #2: Coarse tuning in half-tones MIDI channel modes POLY MONO OMNI ON Mode 1 Mode 2 OMNI OFF Mode 3 Mode 4 DP-201 MKII...
-
Page 34: Technical Specifications
Technical specifications Technical specifications Display Blue backlit LCD Keyboard 88 weighted keys with hammer action and adjustable touch response Polyphony 64-voice Sound settings Recording tracks Pedal Sustain (1/4") Connections Power supply via 12 V adapter , headphones (1/4"), USB to Host, audio out, audio in Speaker 2 ×... -
Page 35: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. DP-201 MKII... - Page 36 Notes digital piano...
- Page 37 Notes DP-201 MKII...
- Page 38 Notes digital piano...
- Page 40 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
