Polaroid PL150D User Manual

Studio Series TTL
Bounce DUA Flash
User Guide
PL150D
Questions? If you still have questions
Need some help? call our support line:
1-800-226-6534
These instructions will help you
enjoy your new product
Distributed by: Polaroid and Polaroid & Pixel are trademarks of PLR IP Holdings, LLC, used under license. All other
C&A Licensing LLC trademarks are the property of the respective owner, who has not sponsored, endorsed or approved
2 Bergen Turnpike this product. PLR IP Holdings, LLC does not manufacture this product or provide any Manufacturer's
Ridgefield Park, NJ 07660 Warranty or support.
© 2011 All Rights Reserved
MADE IN CHINA
For warranty information and technical support please call
Product features, specifications and appearances
1-800-226-6534 or visit www.polaroid.com
are subject to change without notice.
INTRODUCTION
Thank you for purchasing the Polaroid studio series TTL
bounce DUA flash. This is an innovative electronic flash
designed for both digital cameras and film cameras. The
features are leading photography into the digital era.
Advanced technology is used in the flash to control the
correct amount of light output. Please kindly take a few
minutes to read the instruction manual before using.
CAUTIONS
• The flash unit does not function on camcorders.
• Misfiring sometimes occurs when the power switch is
turned on and off continuously. If it happens, power off the
flash unit for a few seconds before switching it on again.
The flash unit will then work as normal.
• Do not leave or store the flash unit in temperatures exceeding
40°C/104°F . This might adversely affect the internal structure or
performance of the flash unit. Particularly, do not leave the flash
unit in automobiles during summer.
• Remove the batteries if you do not intend to use the flash
unit for a long period of time.
• The flash unit is not water-resistant. Rain and humid
weather may cause irreparable damages to the flash.
• The flash unit is composed of very delicate electronic
parts. It should be protected against shocks, falls or other
improper handling.
• The flash unit contains a high voltage condenser. Do not
try to open the housing or repair the flash.
• Do not clean the surface of the flash unit by any petrol,
detergent solution or strong solvents. These solvents may
cause damages to the flash.
Getting to Know
Your Flash
LED Video Light
or visit us at
www.polaroid.com
Lock Ring
Compatibility
C Canon Digital E-TTL, E-TTL II cameras & E-TTL
film cameras
N Nikon Digital TTL, i-TTL cameras & TTL, i-TTL
film cameras
OP Olympus & Panasonic Digital TTL cameras
P Pentax Digital P-TTL & film cameras
S Sony & Minolta Digital ADI, D Lenses cameras &
TTL film cameras
Mounting Foot
Type C, N, P
Type S
Type OP
Reflecting Plate
(Optional)
Zoom Head
ON/OFF Switch
(Main Power /
Ready Lamp
Test Button
Mounting Foot
Difference in the position of
indicators and switch at the
rear of C, N, OP, P & S flash
Type C, N, OP, S
Type P
Flash)
ON/OFF Switch
(LED)
Characteristics
• TTL metering
• Automatic shutter speed setting
• Flash readiness indication
• Red-eye reduction (Type N, OP and P)
• Front and rear curtain synchronization
• Integrated LED video light
• Power saving function
Specifications*
Flash
42(m) at 85mm position
Guide No. (ISO 100)
Flash Head 28-35-50-85mm
Bounce Angle 0°, 45°, 60°, 75°, 90°
Right 0° - 90°; Left 0° -180°
Swivel Angle
Power source Four 1.5V AA size batteries (R6, LR6)
Recycling time 0.5-8 sec.
Approx. 72 (W) x 102 (D) x 130 (H) mm
Dimensions
Weight w/o battery Approx. 260g
LED Light
Power 1W X 3
*Specifications and design are subject to change without prior notice.
Bounce Angle
Indication
Battery
Compartment
Cover
OK light
