Portable Spray Washer
User Guide
Thank you for purchasing the Ivation 12V Portable Spray Washer. This User Guide is
intended to provide you with guidelines to ensure that operation of this product is safe and
does not pose risk to the user. Any use that does not conform to the guidelines described in
this User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference. This
product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and
exclusions. See warranty for details.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ivation Portable Spray Washer
Summary of Contents for Ivation Portable Spray Washer
-
Page 1: User Guide
Portable Spray Washer User Guide Thank you for purchasing the Ivation 12V Portable Spray Washer. This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any use that does not conform to the guidelines described in this User Guide may void the limited warranty. -
Page 2: Table Of Contents
CONTENTS Safety Instructions.........................3 Parts ..............................5 How to Assemble ..........................6 How to Operate..........................7 Automatic Shutoff...........................8 General Maintenance........................9 Troubleshooting ..........................10 Specifications..........................11... -
Page 3: Safety Instructions
Safety Instructions Please read these instructions and warnings carefully before using your Portable Car Washer. WARNING: Cleaner assembly may include small parts. Small parts can present a choking hazard. IMPORTANT SAFETY INSTRUCTIONS When using this appliance, basic precautions should always be followed, including the following: 1. - Page 4 8. Do not use without water filter in place. 9. Turn off all controls before unplugging. 10. Do not use to spray at flammable or combustible liquids such as gasoline, or use in areas where they may be present. 11. Use only the supplied power cord. 12.
-
Page 5: Parts
Parts 1. ON/OFF Switch 12. Power Cord Inlet 2. Carrying Handle 13. Hose Inlet 3. Cap 14. Air Vent 4. Tank 15. Inlet Hose 5. Mesh Storage Compartment 16. Wheels 6. Hose 17. Switch Lock Power Cord 18. Shower Head 8. -
Page 6: How To Assemble
How to Assemble Turn cap counterclockwise Fill tank with fresh water. Replace cap and turn and remove. clockwise to secure. IMPORTANT: Water temperature must be between 50° and 122°F. Attach hose to tank by turning Connect hose to spray nozzle Attach power cord to unit the joint from left to right. -
Page 7: How To Operate
How to Operate IMPORTANT: READ ALL OPERATING INSTRUCTIONS PRIOR TO FIRST USE. IMPORTANT: DISCONNECT THE POWER CABLE WHENEVER ENGINE IS TURNED OFF FOR EXTENDED PERIODS OF TIME. THE POWER DOES NOT TURN OFF AFTER SWITCHING OFF THE ENGINE IN SOME CARS. IF THE POWER PLUG IS LEFT CONNECTED, THE BATTERY MAY BECOME RUN DOWN OR SUSTAIN DAMAGE. -
Page 8: Automatic Shutoff
Spray gun Operation: (1) Intermittence flow The intermittence flow is performed by pulling and releasing the trigger repeatedly. (2) Continuous flow Position 1 Position 2 Water will flow continuously when the trigger is pulled forward as in Position 1 or Position 2. Automatic Shutoff THE AUTOMATIC SHUTOFF FEATURE When the trigger is released, the dynamic pressure shuts the motor off automatically. -
Page 9: General Maintenance
General Maintenance WARNING: ALWAYS DISCONNECT THE PLUG FROM THE POWER SUPPLY BEFORE ANY MAINTENANCE IS APPLIED. 1. WATER FILTER: Inspect the water filter before filling with water. Clean water filter if dirty. 2. NOZZLE CLOGGED: A clogged nozzle will cause the operating pressure to be too high causing the portable washer to surge. -
Page 10: Troubleshooting
DRAINING WATER FORM SYSTEM 1. Turn off portable cleaner, squeeze nozzle lever to release pressure. Remove nozzle, squeeze level and drain water from nozzle. Empty water from tank. Turn unit on and run for approximately 30 seconds without nozzle. 2. Detach high-pressure hose. Elevate one end to allow water to drain from hose. 3. -
Page 11: Specifications
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions. See warranty for details. Customer Service: info@myivation.com 866-849-3049 Distributed by C & A Marketing 2 Bergen Turnpike Ridgefield Park, NJ 07660 info@myivation.com Made in China Ivation is a trademark of C&A IP Holdings, LLC ©2015 All rights reserved...
