Lil' Jumbl Non Contact Forehead Thermometer User Manual

Non Contact
Forehead
Thermometer
USER MANUAL
Functions
Forehead Temperature
The thermometer has been designed for practical
use. It's not meant to replace a visit to the doctor.
Please also remember to compare the
measurement result to your regular body
temperature. Please consult with doctor if you
have health concerns.
Please see the "Use of the thermometer" section
to learn how to measure the body temperature.
Surface Temperature
The surface mode shows the actual and
unadjusted surface temperature which is different
from the body temperature. It can help you
monitor if the object temperature is suitable for the
baby or patient, for example the baby's milk.
Please see the "Use of the thermometer" section
to learn how to measure the object temperature.
Room Temperature
Suitable ambient temperature is important for the
baby and patient. The thermometer always helps
you recognize the room temperature.
After power off, the room temperature will be
shown on the screen with
Fever Alarm
If the thermometer detects a temperature ≥99.5°F
(or 37.5°C) under forehead mode, three short
beep sound will follow one long beep sound to
warn the user for potential fever.
Last Reading
When you get a new body temperature, the last
reading will be shown on the screen (at top right
corner) with the icon.
Temperature measurement range:
Operating temperature range:
Storage temperature range:
Transportation temperature
Atmospheric pressure:
Accuracy:
Fever alarm, memory and °F/°C switch function
Battery: one lithium cell battery (CR2032 *1pcs)
Battery life: around 3,000 continuous readings
Expected Service Life: 4 years
Dimensions: 80.1 x 46.4 x 37.7 mm
Weight: 46.3 grams including battery
• The device should not submerge into any liquids and
• There is no gender and age limitation for using the
• This is not an AP or APG product
°F / °C Switch
In "Power Off" mode, press and hold the "SCAN" button, then press
the
icon "°C". You can also use the same process to change the LCD
display from °C to °F.
icon.
Note: The device must stay in stable ambient (room)
temperature for 15 minutes before operating.
1. Always make sure the probe lens is clean without any
Warning: Choking from swallowing small parts and batteries
by children or pets is possible, please keep small parts and
batteries at places where children and pets can't reach.
2. Power on:
Specifications
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
50~104°F (10~40°C), 15%~85% RH
It should be stored at room temperature
between -4~122°F (-20~50°C) , RH≤85%
less than 70°C, RH≤95%
800~1013 hPa
Forehead mode: ±0.4°F (0.2°C) within 95~107.6°F
(35~42°C), ±0.5°F (0.3°C) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F
(22~42.2°C), others ±4% or ±4°F (2°C) whichever
is greater.
Warnings
expose it to direct moisture.
infrared thermometer.
Functions
Memory Locations
There are total 25 sets of measurement condition
for body temperature.
When power on, press the
see the temperature records with

ON/MEM button for 3 seconds, icon "°F" will be switched to
Use
damage and the forehead is clean.
For the first time, pull out the insulated strip from the
battery cover to activate the thermometer.
Press the ON/MEM button.
ON/MEM button to
icon.
