Ivation 20MP Waterproof/ Shockproof Digital Camera User Manual

20MP Waterproof/
Shockproof Digital Camera
User Manual
6. Camera Layout Diagram
Refer to this diagram and associated tables to familiarize yourself with your camera
and learn its functions.
Item # Name Description
1 Shutter Press the shutter button to:
• Take photographs
• Start/stop recording a video clip
• Confirm changes in menu mode
2 Power on/off button • Press the power button for at least
2 seconds to switch the camera on or off.
• Press the power button to display or hide the
status icon on the LCD.
3 Monitor switching button Press this button to switch between the front
and back monitor.
4 Front monitor Use the front monitor when taking self-portraits.
5 Flash Use the built-in flash to supply extra lighting
when shooting in the dark (the best shooting
distance is within 1.5m).
6 Lens Capture the image.
Note: Keep the lens clean. Dirt and fingerprints
adversely affect image quality.
7 Busy indicator Blinks when the camera is busy; do not take
pictures when busy.
8 Macro/normal switch • Macro mode: Select this mode to take close-
up photographs (distance 11cm - 18cm).
• Normal mode: Select this mode to take
photographs from.
1. Introduction
IVATION™ isn't about products, it's about passions and the people driven by them. In
our world, trite is non-existent because we believe our customers are insightful and will
recognize and appreciate the authenticity of our talent displayed in our products. We're
not about technical jargon or phrases, rather we're about the products and ideas which
inspired people to create them. We take innovation into all of our designs; no existing word
or phrase can communicate the uniqueness of our products.
Congratulations on purchasing the Ivation Waterproof Camera, the best friend of
adventurers who travel the world or the neighborhood! This rugged, waterproof camera
is perfect for all your adventures on land or in the water. Everyone in the family can take
memorable photographs and video with the ease of a pro using the default settings;
advanced photographers can take advantage of the available precision settings to
achieve any artistic touches they can imagine. The duel monitors of this lightweight
camera eliminate fussy camera flipping so you can take 'selfies' and standard images
without wasting a minute.
Thank you for choosing Ivation. We hope you and your camera enjoy many adventures
together. Get to know all the exciting features of your new camera by reviewing this
User Guide.
2. Safety Information
Your Ivation Waterproof camera will serve you well for years to come, particularly if you
follow these simple safety instructions:
• Don't open the battery door under water! The camera itself is watertight as is the
battery case when sealed closed, but if opened under water irreptable camera
damage may result.
• Close the battery door properly for best water sealing.
• Rinse the camera with clean water after use and store it dry.
Item # Name Description
9 Main screen Use to display photographs, video clips, camera
setting and menu.
10 Up/Tele • In Preview mode: press to zoom in.
• In Menu mode: press to move up the
selection bar.
• In Image Playback mode: press to enlarge
the image.
• In Video Playback mode: press it to start/
pause the video.
11 Down/Wide • In Shooting mode: press to zoom out.
• In Menu mode: press to move down the
selection bar.
• In Image Playback mode: press to reduce the
photo size.
• In Video Playback mode: press to enter
thumbnail mode.
12 Left / Flash light • In Menu mode: press to select the option
displayed on the left.
• In Playback mode: press to return to the
previous item.
• In Photo Infinite Preview mode: press to
switch to flash mode.
• When zooming in under Image Playback
mode: press to move to the left portion of
the photo.
• In Video Playback mode: press for fast rewind.
3. Product Features
• 20 Megapixels Resolution
• Digital Still Camera
• Digital Video Camcorder
• Built-in Flash
• 4x Digital Zoom
• 2.7+1.8 " Dual Color LCD Displays
• Supports MicroSD cards up to 32GB
4. Product Highlights
This versatile and durable camera is filled with features that will make your pictures as
attractive as the memories you have of your trips to distant shores or to the backyard!
• Dual Monitors make selfies a snap! No more flipping the camera to capture that
priceless moment. Dual monitors mean you can photograph yourself with your friends
or capture that breathless sunset without turning the camera.
• Still Photos or Video at your fingertips. Whether you are at the pool or out on the town,
you can record that memory in video or photo at the touch of a button. Take photos and
videos in multiple resolution options, all of which are conveniently available to the
novice or journeyman shutterbug.
• Built-in Flash takes the guesswork out of lighting. Set and forget automatic flash to
allow the camera to decide when to flash or manually set when you want to control
the flash yourself.
• 4x Zoom - To take a close-up of that butterfly or birthday cake, the 4x zoom is at
your command!
• Self-Timer Setting gives you an audible ten second countdown so you can position
yourself and your entire crew for the shot!
Item # Name Description
13 Right / Playback • Press to enter Playback mode.
- In Playback mode: press to advance to the
next item.
• In Menu mode: press to select the option
displayed on the right.
• When zooming in when under Image
Playback mode: press to move to the right
portion of the photo.
• In Video Playback mode: press it for fast forward.
14 Mode switch • Press to switch between video and still
capture mode;
• In Playback mode: press this button to exit.
• When zooming in under Image Playback
mode: press to move to the upper portion of
the photo.
• In Video Playback mode: press to stop the video.
15 Menu / Delete • In Preview mode: press to enter the settings
Menu.
• In Playback mode:
- Press for a short time to enter "Delete single/ all
files" mode.
- Press for a long time to display the file compiling
and system setting menu.
- In Photo (zoom in) Playback mode: press to
move to the lower area of the photo.
• Playback lets you see the photos and video you just shot; delete what you don't like
and save the rest.
• Photo and Video Protection – Passing the camera so everyone can take pictures but
want to be be sure your favorites are not deleted? Protect them using this handy
feature. Even 'delete all' does not delete images saved in protection mode. If you
change you mind, unprotect the images as easily as you protected them!
• 7 Language Display Options enables you and your friends to see prompts in any of the
seven langues: English, French, German, Italian, Japanese, Portuguese or Spanish.
5. Box Contents
This box contains:
• Digital Camera
• USB Cable
• Protective Case
• Wrist strap
• User Guide
Item # Name Description
16 Tripod connector For attaching the camera to a tripod.
17 USB interface Provided to enable downloading photographs
and video clips to a computer using a USB cable
(not included).
18 MicroSD card slot Place a MicroSD card here (not included).
19 Battery compartment Compartment for 2 x AAA alkaline batteries
(not included).
20 Strap hook Attach the wrist strap to the camera with
this hook.
