- Page 1 Rear View Camera for BMW 5 Series (F10) Manual www.car-solutions.com support@car-solutions.com...
- Page 2 Contents 1. Features & specification------------------------------------------------------------------------------------------ 3 2. Components---------------------------------------------------------------------------------------------------------- 4 3. Connection diagram----------------------------------------------------------------------------------------------- 5 Remark support@car-solutions.com Design or specification of the product can change for better performance without an advance notice. www.car-solutions.com...
- Page 3 1. Features & specification Specification Features DESCRIPTION Qcam1 • High End Quality Rear View Camera • 1089K 1/3’’ Image Sensor Pick-up Device 1089K 1/3’’ Image Sensor • Waterproof Camera IP68 Number of Image Pixels 410K 510(H) x 492(V) • World Best LENS F1.8...
- Page 4 2. Components Camera cable Output signal connection Extension connector Rear View Camera * 1ea Rear camera power Cable of power & output signal * 1ea support@car-solutions.com www.car-solutions.com...
- Page 5 3. Connection diagram VIDEO INTERFACE A/V(IN/OUT) REAR CAMERA Camera cable Connection Extension cable support@car-solutions.com www.car-solutions.com...
