  • Page 2 INTRODUCTION This User Manual will help you to operate your receiver in a safe manner while enjoying all the features and benefits it provides for your entertainment This User Manual must be read by every person that is: • Installing •...

  • Page 3: Table Of Contents

    Table of contents Safety Instructions Positioning Front Panel / Rear Panel Remote Control Unit Connecting your STB Main Menu 1. Installation 2. TV Channel 3. Radio Channel 4. Edit Program 5. System Setting 6. System Info Trouble Shooting Specification...

  • Page 4: Safety Instructions

    · Please make sure that the power supply (socket) is easily accessible. · Do not damage the mains cable. · If the mains cable is damaged, refer to a qualified DGTEC technician for repair before using the receiver again otherwise there is the risk of electric shock.

  • Page 5: Positioning

    Positioning Place the receiver on a stable, even surface. Avoid placing it near: Sources of heat Naked flames, like candles, Devices with strong electromagnetic fields, like speakers. Do not place objects filled with liquids (such as vases) on the receiver. ·...
  • Page 6 General Introduction UNPACKING Unpack the unit and check to make sure that all of the following items are included in the box: 1X Remote Control Unit (RCU) 1X User’s Manual 2X AAA batteries 1X Digital Terrestrial Receiver 1X Composite cable 1X Component Cable...

  • Page 7: Front Panel/ Rear Panel

    Front Panel/ Rear Panel Front Panel （1） STANDBY: Switches the STB between operation and standby modes. （2） DISPLAY: Display the channel number while operating and the time while in standby mode. （3） CH (-/+): Change channel or items from top to bottom on the menu. （4）...
  • Page 8 Y/Pb/Pr RCA A/V: Component connection (Y/Pb/Pr) Video RCA A/V: Composite connection Audio (white: left audio, red: right audio): Right & left audio for Component connection RS-232: To connect to your PC for software upgrade (only used by qualified DGTEC technician) (10) POWER: Power ON/OFF switch...

  • Page 9: Remote Control Unit

    Remote Control Unit...
  • Page 10 Remote Control Unit Switch between Operation and Standby mode STANDBY Changes channels or selects the menu NUMBERIC options. BUTTONS FORMAT Electronic Program Guide button displays the TV/Radio program guide broadcasting by the TV provider Turn to the main menu or return to previous MENU menu VOL (◄/►)

  • Page 11: Connecting Your Stb

    Connecting your STB Step 1: Connect to the antenna Connect the antenna lead coming from the wall plate to the AERIAL IN socket. Step 2: Choose your Connection There are a number of methods for connecting your STB to the television, depending on your preference and the connection types on your TV.
  • Page 12 Connecting you STB How do I connect to an external audio device? Connect the AUDIO R/L socket of the STB to the Audio System e.g. HI-FI, Amplifier, etc. Alternatively an optical cable can be used from the rear S/PDIF to a surround sound system.

  • Page 13: Main Menu

    Main Menu Plug in the STB. The Main Menu screen will appear as shown in the following picture. The Main Menu displays various functions of the STB. You can select menu options with the “CH” buttons and the numeric buttons on the remote control. To proceed to the next stage, press the “OK”...

  • Page 14: Tv Channel

    You can move the cursor to “manual search” by pressing “UP/DOWN” arrow keys then press “enter” when highlighted. Prior to manual scanning, you need relevant parameters including: 1. Channel No. 2. Frequency (KHz) If any program is detected when scanning process is finished, system will exit the scanning page and save the program.

  • Page 15: System Setting

    Deleting Channels: Press the RED button to tag channels you would like to delete. When exiting, changes will saved when requested. Setting Favorite Channels: Press the GREEN button to save channels as favorites. A love heart will appear when channel is tagged as a favorite.
  • Page 16 5.2 System Setting System setting menu provides the Menu Language, PG block level, time region and transparency. 1) PG block level (Parental Guidance): Under this menu, you can choose a Rating of your choice block: All/ Disable/R-Above/AV-Above/MA -Above/PG- and Above/G. Timer region Set the Time mode and GMT time etc.

  • Page 17: System Info

    5.4 Factory default The factory default enables you to reset your STB back to factory settings. WARNING: You will loose all settings and channels already saved. 6. System Info. System Info provides you current hardware and software information for your STB. EPG (Electronic Program Guide): Press EPG on the remote control and select the channel of your choice.
  • Page 18 Teletext Teletext is a text-based data service. It is available only on the Channel Seven Network broadcast. Press the TXT button to activate. Subtitle Closed captions are the spoken words typed onto the screen. Pressing the SUB button on the Remote Control Unit will activate this feature. Note: Closed captioning is not always available on all adverts and programs.

  • Page 19: Troubleshooting

    Troubleshooting If a problem does occur with this STB, please check the table below to begin troubleshooting. Alternatively you can contact the DGTEC Technical support hotline on 1800 189 941. Problem Probable reasons Resolution Power on, but no Please carefully check the...

  • Page 20: Specification

    Specification Tuner Demodulator Input Frequency Range 176MHz–860MHz Input socket IEC 169-2 Female Output socket IEC 162-2 Male Demodulator Coding COFDM Mode 2K or 8K Code rate 1/2,2/3,3/4,5/6,7/8 Guard 1/4,1/8,1/6,1/32 Video decoder Profile Lever MPEG-2 MP@ML Bit rate Max 15Mbps Aspect Ratio 4:3, 16:9, Auto Output PAL/NTSC...
