Summary of Contents for Technika 50F22B-FHD
- Page 1 LED TV with Freeview HD, Saorview & USB PVR User Guide Model No 50F22B-FHD...
-
Page 2: Important Safety Instructions
• Ensure the television is not placed on top of the power cable as the weight of the television may Important safety instruction damage the cable and cause a safety hazard. • Never place mobile phones, speakers or any other device which may cause magnetic or radio interference, near the television. - Page 3 Important information regarding use of video Batteries games, computers, captions or other fi xed image • Do not expose batteries to high temperatures, displays excessive heat, prolonged sunshine or fi re as this may cause leakage, explosion or ignition. Observe the correct polarity when inserting batteries. The extended use of fi xed image program material can cause •...
-
Page 4: Table Of Contents
CONTENTS Manufacturers Guarantee Information ........3 Important Safety Instructions . -
Page 5: What Is Included In The Box
What is Included in the Box WHAT IS INCLUDED IN THE BOX Accessories Included with this TV are the following accessories 1 x User Guide 1 x Remote Control User Guide 2 x AAA Batteries 1 x Quick Start Guide Quick Start Guide 1 x Mini Composite / AV... -
Page 6: Attaching/Detaching The Stand
Attaching/Detaching the stand ATTACHING THE STAND Attaching the stand To complete the stand installation you will require a cross head screw driver Screws that are included. 4 x M(4x16) Used for attaching the stand to the TV set (fi g.2) (fi... -
Page 7: Securing The Tv To A Wall/Wall Mounting
Securing the TV to a Wall/Wall Mounting SECURING THE TV TO A WALL Securing the TV to a Wall For maximum security in the home when using a TV with its stand anti-tip straps should be fi tted. These are available from supermarket websites and other websites and are an easy, inexpensive and an effective way of ensuring your TV stays safely upright. -
Page 8: Remote Control
Remote Control REMOTE CONTROL STANDBY - Switch on TV when in standby or vice versa MUTE - Mute the sound or vice versa DTV - Switch to digital source RADIO - Switch to radio whilst in digital source USB - Switch to USB source DVD - Switch to DVD source NUMBER BUTTONS - 0 –... -
Page 9: Tv Buttons And Input Source Menu
TV Buttons and Input Source Menu TV BUTTONS AND INPUT SOURCE MENU Volume up and menu right Volume down and menu left Programme/Channel up and menu up Programme/Channel down and menu down Displays Menu/OSD Displays the input source menu Standby Power On/Off Choosing Mode Input/Source To switch between the different input/ Freeview/Saorview TV... -
Page 10: Connections
Connections CONNECTIONS Digital Audio V G A /P C (A udio in) Output V G A /P C IN C I C A R D IN E A R P HO NE Y Pb Pr AV IN US B LAN* Network Connection Earphones Earphone Input... - Page 11 Connections CONNECTIONS Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is Included In The Box’ page. Connecting to a device with Composite AV/Video output TV Source should be set to Composite/AV L (white) R (red) Mini Video...
- Page 12 Connections CONNECTIONS Connecting to a device with Component/YPbPr output If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you must connect via Component (for picture) and by phono cable (for sound). TV Source should be set to Component/YPbPr Y (green) PB (blue)
-
Page 13: Tv Menu Operation
TV Menu Operation CHANNEL MENU To access this menu, press [MENU] button on the remote control. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button. Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and analogue devices... -
Page 14: Picture Menu
TV Menu Operation PICTURE MENU To access this menu, press [MENU] button on the remote control and scroll right. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. - Page 15 TV Menu Operation PICTURE MENU To access this menu, press [MENU] button on the remote control and scroll right. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons.
-
Page 16: Sound Menu
TV Menu Operation SOUND MENU Sound Mode - Choose from the following presets Tip: Equaliser settings can only be Standard Default settings adjusted when the sound mode ‘Personal’ Music Emphasises music over voices is selected. Movie Provides live and full sound for movies Sports Emphasises sound for sports Personal... -
Page 17: Time Menu
TV Menu Operation TIME MENU To access this menu, press [MENU] button on the remote control and scroll right. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. -
Page 18: Setup Menu
TV Menu Operation SETUP MENU To access this menu, press [MENU] button on the remote control and scroll right. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. -
Page 19: Lock Menu
TV Menu Operation LOCK MENU To access this menu, press [MENU] button on the remote control and scroll right. To select a sub menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. -
Page 20: Network Confi Guration
Network Confi guration NETWORK CONFIGURATION For the network confi guration to work the TV will need to be connected to your home network via an Ethernet cable, with these requirements in place the TV will connect to the network automatically. If you are looking to change the confi... - Page 21 7 Day TV Guide and Channel List 7 DAY TV GUIDE TV Guide is available in Saorview/Freeview TV mode. It provides information about forthcoming programmes (where supported by the Saorview/Freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders. 1) Press [TV GUIDE].
- Page 22 USB Record - Freeview/Saorview USB RECORD - FREEVIEW/SAORVIEW MODE USB RECORD – FREEVIEW/SAORVIEW MODE Built into this television is a USB record facility. This function is available in Freeview/Saorview mode when used in conjunction with a compatible USB memory stick or USB hard drive. The benefi ts of this are as follows: •...
- Page 23 USB Mode/Media Player USB MODE/MEDIA PLAYER USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the below menu screen will appear. The content will be divided into Photo, Music, Movie and Text based on fi...
-
Page 24: General Information
General Information USING YOUR TV WITH A SKY DIGITAL SET TOP BOX Option 1) Connecting your TV to your Sky box (when both the TV and Sky Box are located in the same room) Depending on your Sky Box & TV model, connect either by SCART or HDMI cables (available separately) . -
Page 25: Frequently Asked Questions
General Information FREQUENTLY ASKED QUESTIONS General I would like to have louder 1) Use the 3.5mm headphone output and a 3.5mm to phono cable (available separately) to (For TV models with sound by connecting additional connect to an amplifi er/surround sound system. Please note this will deactivate the TV’s built digital optical audio speakers. - Page 26 General Information FREQUENTLY ASKED QUESTIONS USB Record I cannot change the channel, During time shift you cannot change the channel, access the menu or use the red button. access the menu or use the red button. USB Record When using the USB to record Check the USB memory stick meets the minimum read speed requirements.
-
Page 27: Technical Specification
General Information TECHNICAL SPECIFICATION Product fi che Trademark Technika Model ID 50F22B-FHD Energy effi ciency class Visible screen size (diagonal) 127 cm / 50inches On mode power consumption 65.0 W Annual energy consumption *1 95 kWh Standby power consumption *2 <0.50 W... - Page 28 General Information TECHNICAL SPECIFICATION Compatible fi les in USB Mode Video Decoder Media File Ext. Remark Video Audio .mpg/.mpeg MPEG-1, MPEG-2 /.dat .ts/.trp/.tp/. MPEG-2, H.264,VC1,AVS m2ts .vob MPEG-2 1920×1080 Max Solution: .mp4 MPEG-4, Xvid, H.264 MP3, WMA,AAC, 40 Mbps Max Data Rate: .rm/.rmvb Rm codec LPCM,DTS(DMP)，...
- Page 29 TEC/MAN/0092...
