zSpace 300 User Manual

Hide thumbs Also See for 300:
Table of Contents

Advertisement

Quick Links

See also: Configuration Manual
zSpace for
Education
Model 300 User's Guide
zspace.com
zSpace 300 User's Guide
770-00014-01 Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 and is the answer not in the manual?

Questions and answers

Related Manuals for zSpace 300

Summary of Contents for zSpace 300

  • Page 1 Education Model 300 User’s Guide zspace.com zSpace 300 User’s Guide 770-00014-01 Rev B...
  • Page 2 Inc. All other trademarks are the property of their respective owners. © zSpace, Inc. 2015...

  • Page 3: Table Of Contents

    Contents The zSpace System Contents of the zSpace Box Parts of Your zSpace Side Panel Rear Panel Power How zSpace Works Head-Tracked Stereoscopic Display Stylus Interaction Using 3D in zSpace Adjustable Angle Setting Up your zSpace 9 Hardware System Software...

  • Page 4: The Zspace System

    The zSpace System Congratulations on your purchase of the zSpace, which is an all-in-one system including the monitor and computer in a single unit. This guide reviews the features, setup process, and basic usage information. Contents of the zSpace Box ...

  • Page 5: Parts Of Your Zspace

    System Components Eyewear In order to use your zSpace in stereoscopic mode (3D), you need to wear the 3D eyewear. This eyewear includes small reflectors, which the tracking cameras use to identify your head position. 3D Glasses with Reflectors...
  • Page 6 Your zSpace also includes a pair of 2D glasses without the tracking reflectors. A secondary observer can wear these and share your experience in 2D without interfering with the tracking. Stylus You can use the stylus to interact with 3D applications using six degrees of freedom of motion. Six degrees of freedom refers to the stylus’s full range of motion in three-dimensional space.

  • Page 7: Side Panel

    For best results, we suggest an angle between 30 and 65 degrees. Warning: Be careful to set the angle so the zSpace is stable and does not fall over. This could damage the zSpace or cause injury.

  • Page 8: Rear Panel

    The rear panel has a port for the stylus, the power supply, an HDMI port, a USB 2.0 port, and an Ethernet connection. The Back of the zSpace Power The power button is on the top of the zSpace. Power Button...
  • Page 9 The zSpace uses Windows Power Management Tools. By default, the display will turn off after 15 minutes and the computer will enter sleep mode after 30 minutes. To resume from sleep mode, press the Enter key or the power button.

  • Page 10: How Zspace Works

    Head-Tracked Stereoscopic Display The head-tracked display enables the zSpace to display the left and right images for a stereoscopic display. The images adjust as your eyes move within the tracking zone. This capability ensures a comfortable virtual experience.

  • Page 11: Using 3D In Zspace

    We recommend angles between 30 and 60 degrees. Adjustable Angle With the stand closed, the zSpace is 25” (64 cm) wide, 18” (45 cm) tall, and 3” (8 cm) deep, at its widest, tallest, and deepest. The following table gives the zSpace’s “footprint,” or space on the desktop, at 30, 45, and 60 degrees.

  • Page 12: Setting Up Your Zspace

    Plug in the power cord and the stylus into the ports on the back panel. Press the power button on the top of the zSpace. Refer to the illustrated Quickstart Guide that comes in the box with your zSpace. You can also download a copy from http://zspace.com/setup.

  • Page 13: System Software

    300 System Software link. If the latest version is newer than the one on your zSpace Control Panel, click on the download link. Before you install the new version, uninstall the current version of the System Software.

  • Page 14: Firmware

    Click on the green check mark to begin. If necessary, a new version will download. Start Firmware Check Wait for the System Check to complete. It will restart the zSpace and show a checkmark when the check is complete. Firmware Check Complete Congratulations! You are ready to begin using your zSpace.

  • Page 15: Customizing Your Zspace

    Right button: A secondary button that may bring up a pop-up menu. If you prefer, you can switch the use of the center, right, and left buttons. To do so, open the zSpace Control Panel and click on Stylus Configuration.

  • Page 16: Applications For Your Zspace

    Other third-party STEM applications are available for purchase from zSpace. Installing and Updating Applications To open the zSpace App Manager, click on its icon on the desktop or in the Windows Start menu. Desktop Icon The App Manager displays applications and content that you can install. It also shows updates for installed applications, if any are available.

  • Page 17: Launching Applications

    Launching Applications zSpace Zone provides a 3D interface for launching both 3D and 2D applications. It is already set up to launch the zSpace applications pre-installed on your zSpace. Tip: In a multi-user environment, we recommend you lock Zone to prevent users from adding and deleting applications.

  • Page 18: Safety Instructions

     If the zSpace screen is damaged for any reason, do not touch any liquid emanating from the unit. In case of contact with skin, rinse or flush any affected surfaces immediately with running water. Please consult a physician in all cases.

  • Page 19: Basic Operation

    Avoid bright lights for best results.  The power button is on the top of the zSpace. It controls the power to the system. You cannot turn off the display separately.

  • Page 20: Replacing The Battery

    When cleaning, disconnect the zSpace from the power source. Replacing the Battery The zSpace includes a 3-volt lithium coin cell battery, which provides power to the real-time clock. When you replace the battery, use an equivalent battery designated for this product.

  • Page 21: Troubleshooting

    Click on the Question Mark to see zSpace Support articles. Problem: The stylus does not seem to work correctly.  Make sure the stylus is plugged into the correct socket in the back of the zSpace. Be careful not to insert it into the Ethernet port. ...

  • Page 22: Recycling (Weee) And Rohs

    Recycling (WEEE) and RoHS We request you recycle your zSpace when replacing it with a newer product or when any hardware component reaches the end of its useful life. Please bring all materials to appropriate recycle centers in your community or region.

  • Page 23: Appendix A: Specifications

    Appendix A: Specifications Intel i3-4370 500 GB HDD 8 GB RAM AMD FirePro W5170M Network Wired: RTL8106E-CG, 10/100M Wireless: NAC-BT Resolution 1920*1080 Full HD Display Area 20.5” H * 11.5” V, 23.6” D (52.07 cm * 29.21 cm * 59.94 cm) Rise Time/Fall Time Tr: 1.3 ms...

  • Page 24: Appendix B: Certifications

    Appendix B: Certifications zSpace has the following certifications: U.S. Certifications  FCC Class B (Federal Communications Commission) Declaration of Conformity  USA Energy Star6.1 Multi-National Certifications  CB (IECEE Certification Bodies’ Scheme)  CE Marking – Declaration of Conformity ...
  • Page 25 BSMI (Bureau of Standards, Metrology and Inspection) certification Thailand  NTC (National Telecommunication Commission) Supplier Declaration of Conformity United Arab Emirates  TRA (Telecommunications Regulatory Authority) For the complete compliance statements, refer to the zSpace Documentation section of the zSpace Support site, https://support.zspace.com/hc/en-us.

  • Page 26: Appendix C: Limited Warranty

    Dead- or Defective-on-Arrival. In the event a product completely fails to function or exhibits a defect in materials or workmanship within the first forty-eight (48) hours of installation but no later than thirty (30) days after the date of purchase, and this is verified by zSpace, it will be considered dead- or defective-on-arrival (DOA) and a replacement shall be provided prior to zSpace receiving the defective product (“Advance Exchange”), but only if Customer provides a purchase order number, credit card number, or other method of...
  • Page 27 MAINTENANCE OR USE OF ITS PRODUCTS. zSpace shall not be liable under this warranty if its testing and examination disclose that the alleged defect or malfunction in the product does not exist or was caused by Customer’s or any third person’s misuse, neglect, improper installation or testing, unauthorized attempts to open, repair, or modify the product, or any other cause beyond the range of the intended use, or by accident, fire, lightning, POWER CUTS or outages, other hazards, or acts of God.
