- Page 1 8000 Series I/O Product Catalog Contact: T: 410.753.8300 NovaTech Process Solutions, LLC 11500 Cronridge Dr., Suite 110 Toll Free: 800.253.3842 Owings Mills, MD 21117 www.novatechweb.com ®...
- Page 2 8000 Series I/O Product Catalog This page intentionally left blank. Contact: NovaTech Process Solutions, LLC 11500 Cronridge Dr., Suite 110 Owings Mills, MD 21117 ® T: 410.753.8300 Toll Free: 800.253.3842 www.novatechweb.com...
- Page 3 Contents Family Overview Module Data Sheets Analog Input Modules • NT-80-HI-TX 8-channel AI, 4-0mA with HART for - or 4-wire • NT-80-AI-TX 8-channel AI, 4-0mA for - or 4-wire • NT-89-VI-05 8-channel Voltage Input, -5Vdc • NT-8-AI-UN 8-channel isolated AI, 4-0mA with HART, Thermocouple, RTD, Voltage •...
- Page 4 Overview The NovaTech 8000 Series I/O is the newest remote I/O family native to the D/3® Process Automation System (PAS). It is the preferred I/O for new installations and it can replace the older NovaTech 16000 series I/O in existing PCM cabinets, using existing field wiring connected to new termination panels with existing connectors.
- Page 5 Node Architecture An 8000 Series node comprises single or redundant Ethernet Bus Inter-face Modules, up to 64 I/O modules, field terminals, and associated power supplies. A schematic node architecture is shown below. In- formation from the I/O modules is transferred to and from the communication module (EBIM) via the Rail- bus.
- Page 6 NovaTech 8000 Series I/O Components Modules I/O modules transfer signals to and from field instru- ments. Input modules receive signals from transmit- ters and sensors and convert them into a digital form for presentation to the EBIM. Output modules receive commands from the EBIM and transfer them to actua- tors.
- Page 7 Ethernet Bus Interface Module (EBIM) NovaTech 8000 Series I/O uses the Ethernet Bus Inter- face Module (EBIM) to provide a high speed Ethernet data connection to the D/3®. The EBIMs communicate using a propri-etary protocol over Ethernet at speeds of 10/100MB to the D/3® PCMs. NovaTech 8000 Series I/O Support 8000 Series I/O offers a variety of I/O boards and signal conditioning termination panels suitable for virtually...
- Page 8 . 8 single-ended 4-20 mA input channels . Non-incendive field circuits . HART pass-through . HART variable and status reporting . 2- or 4-wire transmitters . open and short circuit detection . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...8, single-ended Nominal signal range (span) ...4 to 20 mA...
- Page 9 . 8 single-ended 4-20mA input channels . Non-incentive field circuits . 4-20mA . 2- or 4-wire transmitters . Open and short circuit detection . 24Vdc bussed field power required Module Specifications Inputs Number of channels ...8, single-ended Nominal signal range (span) ...4 to 20 mA Full signal range...1 to 23 mA Out of range alarm Lower threshold...>...
- Page 10 . 8 single-ended input channels . Non-incendive field circuits . 1–5 V inputs open circuit and short circuit detection . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...8, single-ended Nominal signal range (span) ...1 to 5 V Full signal range ...0.19 to 5.64 V Input impedance...2 MΩ...
- Page 11 • 8 isolated, universal, input channels • Configurable on a channel by channel basis: 4-20mA, THC, RTD, resistance & voltage • 250V ac rms channel to channel isolation • Thermocouple types B, E, J, K, N, R, S, T, W3, W5, Russian K, Russian L •...
- Page 12 Voltage Input Nominal signal range 1 (span) ...±120 mV, 0-1 V, ...0-5V, 1-5V, 0-10V, ±10V Resolution ...14 bits (typ.) Configurable Parameters Sensor type ...user selectable Input dead zone ...user defined value Channel status ...active/inactive Filter/sample rates ...user selectable General Specifications Common mode rejection (using 50/60Hz filter) ...
- Page 13 . 4 thermocouple or mV* input channels • Cold junction compensation Module Specifications Inputs Number of channels ...4 THCs types ...B,E,J,K,N,R,S, or T to EN 60584-2, IEC584-2, BS4937; ...W3 and W5 Input Ranges Input Type Range 0 to 120 mV Thermocouples: B 0 to 1820 °C –...
- Page 14 . 4 RTD or resistance* source inputs . Function defined by configuration . 2-, 3- or 4-wire RTD types accommodated Module Specifications Inputs Number of channels ...4 RTD input (2,3, or 4 wire) ...Pt100 to BS1904/DIN43760/IEC 75 ...Ni120; jPt100 to JIS C1604: 1989 Input Ranges Input Type Range...
- Page 15 . 8 single-ended 4-20 mA output channels . Non-incendive field circuits . HART pass-through . HART variable and status reporting . Valve positioners and remote indicators, etc. . Open circuit detection on each channel . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...8, single-ended...
- Page 16 . 8 single-ended outputs . 4–20 mA . For I/P converters and remote indicators, etc . Open circuit detection is provided on each channel . 24 V dc bussed field power required Module Specifications Outputs Number of channels ...8, single-ended Nominal signal range (span) ...4 to 20 mA Full signal output range ...1 to 23 mA Open loop detection threshold ...0.7 ±...
- Page 17 . 8 discrete isolated inputs . 24 V dc field voltage sources . User definable input threshold . Pulse counting option Module Specifications Inputs Number of channels ...8 OFF voltage...< 3.2 V dc ON voltage ...> 11 V dc Wetting current ...6.3 mA (nom.) @ 24 V dc Minimum pulse width detected ...3 ms Maximum switching frequency (no-filtering)...200 Hz Maximum voltage...
- Page 18 . 8 discrete inputs for dry contact switches . 24 V dc provided on input high side . Returns commoned internally . Pulse counting option . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...8 OFF current ...<...
- Page 19 . 16 input channels for dry contact switches . 24 V dc provided on input high side . Returns commoned internally . Pulse counting option . 24 V dc bussed field power required Module Specifications Inputs Number of channels ...16 OFF current ...<...
- Page 20 . 16 input channels . 24 V dc field voltage sources . Individually isolated channels . User definable input threshold . Pulse counting option Module Specifications Inputs Number of channels ...16 OFF voltage...< 3.4 V dc ON voltage ...> 11 V dc Wetting current ...2.8 mA (nom.) @ 24 V dc Minimum pulse width detected ...5 ms Max input freq in pulse counting mode (no-debounce)100 Hz...
- Page 21 . 8 discrete inputs . 115 V ac field voltage sources . User definable input threshold . Pulse counting option Module Specifications Inputs Number of channels ...8 OFF voltage...< 34 V ac ON voltage ...> 84 V ac Wetting current ...2 mA (nom.) @ 115 V ac Max.
- Page 22 . 8 discrete inputs for dry contact switches . 115 V ac provided on input high side . Returns commoned internally . Pulse counting option . 115 V ac Bussed Field Power required Module Specifications Inputs Number of channels ...8 OFF current ...<...
- Page 23 . 8 discrete isolated inputs . 230 V ac field voltage sources . User definable input threshold . Pulse counting option Module Specifications Inputs Number of channels ...8 OFF voltage...< 68 V ac ON voltage ...> 168 V ac Wetting current ...1 mA (nom.) @ 230 V ac Max.
- Page 24 . 8 discrete inputs for dry contact switches . 230 V ac provided on input high side . Returns commoned internally . Pulse counting option . 230 V ac Bussed Field Power required Module Specifications (See also System Specification) Inputs Number of channels ...8 OFF current ...<...
- Page 25 . 8 powered outputs . Controls solenoids and relays . Common load supply of up to 60 V dc . Discrete or pulsed outputs . 1A per channel switched current . 2–60 V dc bussed field power required Module Specifications Outputs Number of channels ...8 Output voltage range...2–60 V dc...
- Page 26 . 8 fully isolated semiconductor switched outputs . Controls solenoids and relays . For load supplies of up to 60 V dc . Discrete or pulsed outputs . 1A per channel switched Module Specifications Outputs Number of channels ...8 Output voltage range...2–60 V dc ON voltage drop...0.25 V (max.) OFF leakage current ...1.0 mA (max.) Switched current per channel...
- Page 27 . 8 powered outputs . Controls solenoids and relays . Common load supply of up to 265 V ac . Discrete or pulsed outputs . 1A per channel maximum . 20–265 V ac bussed field power required Module Specifications Outputs Number of channels ...8 Output voltage range...20–265 V ac Frequency ...50 / 60 Hz...
- Page 28 . 8 fully isolated semiconductor switched outputs . Controls solenoids and relays . For load supplies of up to 250 V ac . Discrete or pulsed outputs . 1A per channel switched Module Specifications Outputs Number of channels ...8 Output voltage range...20–265 V ac Frequency ...50 / 60 Hz ON voltage drop...<...
