Sirius-3 Navtex 3-Frequency

Compass Safe Distance

Distance to compass must be at least 70 cm.
Do not install the Navtex receiver closer to magnetic compasses.

Power Connection

Please use the included 1.5 m power cable with plug. Connect the
Sirius-3 to 12 or 24 V DC (10-32 V DC). Red wire to + and black to -.
It is recommended to include a fuse in the power supply.
The male power plug can be mounted in the right female connector
only.
PWR Connector pin-out
Pin Number
1
2
3
4
5
6
7
8
9

Ground Connection

Connect ground plane to the Sirius-3 Navtex receiver for optimum
receiving conditions.
Connection
V+
V+
NC
V-
V-
V+
NC
NC
V-
Notes
Ship's Supply 12/24 V DC
Ship's Supply 12/24 V DC
No Connection
Ship's Supply - V
Ship's Supply - V
Ship's Supply 12/24 V DC
No Connection
No Connection
Ship's Supply - V
- 19
