DESCRIPTION
1
1. camera
2. housing
3. power supply / video harness
COMPONENTS
DESCRIPTION
CMOS Camera
2.5 mm Lens
Power/Video Harness
Housing
Housing Screws
Camera Screws
User's Guide
Mounting Template
75.5779.01 JAMB CAM 20131115
2
3
PART NUMBER
12.1000
50.5277
20.5316
70.5528
50.1818
50.5276
75.5779
75.5780
JAMB CAM
Low Profile, Door Jamb,
Color Video Camera
(US version)

REQUIRED TOOLS

TOOL
Power Drill
Tape Measurer
Magnetic Phillips #0
Phillips #2
1/8" Drill Bit
1 1/4" Drill Bit
Multimeter
Caulk & Caulking Gun
Page 1 of 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the JAMB CAM and is the answer not in the manual?

Questions and answers

Summary of Contents for BEA JAMB CAM

  • Page 1: Required Tools

    20.5316 Magnetic Phillips #0 Housing 70.5528 Phillips #2 Housing Screws 50.1818 1/8” Drill Bit Camera Screws 50.5276 1 1/4” Drill Bit User’s Guide 75.5779 Multimeter Mounting Template 75.5780 Caulk & Caulking Gun 75.5779.01 JAMB CAM 20131115 Page 1 of 4...
  • Page 2 The jamb cam focus is preset and is not adjustable. The jamb cam must remain powered on when the door system is powered off. Therefore, the jamb cam power supply must be wired to an external transformer which is wired to the 120 VAC main power.
  • Page 3 7) Wire nut red and black power wires to external transformer 8) Fasten housing onto jamb with supplied screws NOTE: If mounting in exterior application, apply a bead of silicone caulk to back of housing 75.5779.01 JAMB CAM 20131115 Page 3 of 4...
  • Page 4: Technical Specifications

    If you are not an AAADM certified inspector, BEA strongly recommends you have an AAADM certified inspector perform an AAADM inspection and place a valid inspection sticker below the safety information label prior to putting the equipment into operation.
