Airglas, Inc.
®
Installation Instructions
MANUAL NO. LH4000-105
MODEL LH4000 Ski Kit
For
Cessna 180 and 185 Aircraft
Cage Code 17564
MANUAL REVISION C
December 3, 2012
Airglas, Inc.
THIS MANUAL INCLUDES INFORMATION PROPRIETARY TO
AND SHALL NOT BE USED TO MANUFACTURE OR REPRODUCE ANY PART OR
Airglas, Inc.
ASSEMBLY WITHOUT THE PRIOR WRITTEN PERMISSION OF
