THORMA FIKO 70 Installation And Operation Manual

_________________________________________________________________________________________
GB
________________________________________________________________________________________________________
1. GENERAL
The solid fuel cooker has been designed for home cooking and baking. It has been conceived to burn wood and lignite briquettes.
The cooker can be installed in common premises defined by the Slovak national standard STN 33 0300.
Make sure that all local regulations, including those concerning national and European standards, are respected during installation.
Inform your chimney-sweep prior to cooker installation to have an expert check of the cooker connection to your chimney made.
Make sure that the floor where the cooker will be installed has adequate bearing capacity. When installing, make sure there will be easy access for
cleaning the cooker, the flue way, and the chimney.
The cooker must be closed whether in use or out of use, otherwise operation of other equipments connected to the chimney may be affected.
CAUTION: For commands of spare parts or complaints, please give the designation, model, and reference number mentioned in the data
card!
2. TECHNICAL DATA AND FEATURES
The cooker can be connected to the chimney from the side and the models FIKO 70 Ratio, FIKO 70 Plus and FIKO Nostalgia B from the top.
Versions:
- right and left hand side,
- legs mounted (FIKO 70)
and unmounted (FIKO 70 A, FIKO 70 Nostalgia, FIKO 70 Nostalgia B, FIKO 70 Ratio, FIKO 70 Plus)
- with protective frame of the cook-top (FIKO 70 Nostalgia, FIKO 70 Nostalgia B)
Nominal capacity:
Nominal heating capacity efficiency:
Operating chimney draft:
Worktop height
Cooker width
Cooker depth
Draught shaft diameter:
Dimension up to the lower edge of the draught shaft:
Weight
Dimensions of the oven:
Area of the cook-top:
Recommended fuel:
- dry hard wood - approximate heating value 15 MJ.kg
lignite briquettes - approximate heating capacity 20 ÷ 23 MJkg
-
Approximate consumption of recommended fuel at nominal capacity:
- -1
wood: 2.2 kg.hod.
- lignite briquettes: 1.7 kg.hod.
Applicable standards: STN 06 1201, EN 12815, STN 73 4201, STN 73 4210, STN 92 0300
3. INSTALLING THE COOKER
Pursuing to the regulation Nr. 401/2007, all related drawing, security, and hygiene directives must be respected during installation.
For cookers with unmounted legs (to be found in the ash box in such case) legs are to be mounted with screws, bolts and washers supplied with them
in the ash box. Each leg should be mounted on the cooker with:
a) one screw and two elastic washers: applies to versions FIKO 70, FIKO 70 A, FIKO 70 Nostalgia and FIKO 70 Nostalgia B
b) three bolts: applies to version FIKO Ratio and FIKO 70 Plus
Prior to connecting the cooker, make sure that the chimney draught is adequate. The flame of a burning paper or candle shall be draught towards the
chimney opening. The cooker connection to the chimney flue must be as short as possible.
According to Slovak national standards STN 73 4210 and STN 73 4201, the connection of the cooker to the draught hole must be approved by a
chimney-sweep company concerned.
Shall the direct connection of the cooker to the chimney flue be impossible, the respective flue pipes should be as short as possible and rise towards
the chimney. Maximum flue pipes length is 1.5 m. In any case the bend pipe or the pipe connected to the draught shaft must be secured against
loosening with a dowel. Smoke pipes and bend pipes connections must be firm and tight, the pipes being stuffed one into another at minimum 40
mm draught-wards. The chimney opening must be furnished with metal sleeve with a diameter corresponding to the one of the smoke pipes. See
correct and incorrect connection of the cooker to the chimney in the picture no. 1. 1.
Installation and Operation Manual solid fuel cooker
tested according to the standard EN 12815
-1
-1
FIKO 70
6.5 kW
wood = 75.2 %, lignite briquettes = 80.8 %
12 Pa
800 mm
750 mm,
Nostalgia, Nostalgia B = 860 mm
600 mm,
Nostalgia, Nostalgia B = 655 mm
Ø120 mm
635 mm,
Ratio, Plus and Nostalgia B with outlet on the cook-top
FIKO 70, FIKO 70A = 71 kg,
FIKO 70 Nostalgia, FIKO 70 Nostalgia B = 74 kg,
FIKO 70 Ratio, FIKO 70 Plus = 70 kg
Width: 334 mm
Depth: 455 mm
Height: 234 mm
, models Nostalgia B, Ratio,Plus and Nostalgia = 0,30 m²
2
0.34 m
-1
FIKO 70
