Summary of Contents for Yupi mobile HARMONY IIHBS-770
- Page 1 WIRELESS STEREO HEADSET USER MANUAL...
- Page 2 Note: For the best performance and to prevent any damage to or misuse of the HBS-770, please read all of the information carefully prior to using the HBS-770.
-
Page 3: Description Of Parts
DEScRIpTION OF pARTS Ear Rubbers (one pair) Memory Flex Neck Band Volume +/ (Track Forward, Rewind Button) LED Indicator call Buttonplay pause Button Magnetic Earbud Storage... -
Page 4: Specification
SPECIFICATION: Item Description Wireless specification v4.0 compliant cSR Bc8645 Wireless profile Supported HSp v1.2, HFp v1.6, A2Dp v1.2, AVRcp v1.4 Output power class class 2, up to 10- meter range connection Function Multipoint support for A2Dp connection to 2 A2Dp sources for music playback Bluetooth Technology cSR’s latest cVc technology for narrowband and wideband voice connections... - Page 5 Standby Time Up to 500 Hrs charging Time <2 Hrs Operation Temperature -14°F- 140°F(-10°c- 60°F) Dimension/Weight 170 mm(W) X 170mm(L) X 22mm(L)/35g Other features - Antena pcB Antenna - 5- band fully configurable EQ - Surface Mount packcage for Embedded applications - 3 LED outputs - Security simple pairing...
-
Page 6: How To Use
HOW TO USE Charging - When the charger is connected with the power on or off, the headset will turn off. - W czasie ładowania wskaźnik LED zacznie świecić na czerwono - While charging, the LED indicator will show a solid red light. - When charging is complete, the LED indicator will turn blue. - Page 7 PAIrINg - Before using the headset for the first time. You must pair it with a Bluetooth-enabled device. - To pair your headset with additional headset, the headset must be placed in pairing Mode. - There are 2 pairing mode methods with the HBS-770. EASy PAIrINg (FIrST TImE PArINg) 1 Slide the power switch to the ‘ON’...
-
Page 8: Manual Pairing
mANUAL PAIrINg (PAIrINg WITH ANOTHEr PHONE Or rE-PAIrINg) With the power off, slide the power the switch to the ‘ON’ position at the same time for 1 second. When the headset enters pairing Mode, the LED indicator will show a solid blue light. After the procedure repeat Easy pairing steps 2 through 3 AdvANCEd mULTIPOINT The HBS-770 is capable of having two devices connected to the... -
Page 9: Auto Reconnect
- With the power off, press the cALL button and slide the power switch to the ‘ON’ position at the same time for 2 seconds to enter Manual pairing mode. - Now, pair and connect the headset with your other Bluetooth -enabled handset (this will be you primary handset). - Page 10 and HBS-770 will vibrate to alert. - If the headset and handset do not automatically reconnect when they are back within the required range. Briefly press the cALL button on the HBS-770 to reconnect manually. - It is possible to use these functions only when your handset supports them.
-
Page 11: Volume Control
CONTrOLS Power On / Power Off - Move the power switch to the “ON” or “OFF” side. volume Control - Long press the VOLUME button Charging - While charging, the LED indicator will show a solid red light. Low battery - An announcement will be made once every 2 minutes. - Page 12 Answering a Call/Ending a call - When there is an incoming call, the headset will ring and vibrate and report the phone number - Briefly press the cALL button to answer the incoming call. Last Number redial - Double click the cALL button for 1 second to activate ‘Last Number Redial’.
-
Page 13: Call Waiting
If the call is not automatically transferred, you can manually transfer the call to. Call Waiting - Answer a second call without hanging up the first call by double click cALL button. press the cALL button to terminate the one you are calling. - Page 14 gUArANTEE Model No. User Name Address Telephone Date guarantee ITEm 1 3 months upon date of purchase if there is function problem, we should offer the same item subject to goods and packing maintain perfect 2 1year upon date of purchase, we will guarantee to keep the goods in repair.
