Summary of Contents for Lorex VS6428
- Page 1 2.4 GHZ WIRELESS VIDEO SENDER Instruction Manual English Version1.0 MODEL: VS6428 www.lorexcctv.com Copyright © 2007 Lorex Technology Inc.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage“...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the system is operated, and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2. -
Page 4: Table Of Contents
TABLE OF CONTENTS PAGE INTRODUCTION & FEATURES……………………………………… SYSTEM INCLUDES………………………………………………….. CONTROLS AND FUNCTIONS Wireless Transmitter…....….……………………..……... Wireless Receiver...……......……….……...…… INSTALLATION OF WIRELESS TRANSMITTER…………………. INSTALLATION OF WIRELESS RECEIVER Operation with TV (Using RCA Cables)..……………….…..Operation with TV (Using Coaxial Cable) ....…..……..Operation with TV and VCR……………………………………… SYSTEM OPERATION Multiple Devices / Manual Options ………………………………... -
Page 5: Introduction & Features
INTRODUCTION: Thank you for purchasing the 2.4 GHz 4 Channel Wireless Video Sender. This system easily connects to any TV, allowing you to v iew your satellite, DVD or security Camera from another room, up to a distance of 300 ft away (open space). Avoiding the hassle of running wires, this system is easy to install and operate for immediate applications. -
Page 6: System Includes
SYSTEM INCLUDES: 1 - 2.4 GHz Wireless Receiver 1 - 2.4 GHz Wireless Transmitter Also includes: 2 – 9V DC 500mA Adapters 2 – RCA Audio/Video Cables 1 – Coaxial Cable Owner’s Manual... -
Page 7: Controls And Functions
CONTROLS & FUNCTIONS WIRELESS TRANSMITTER TOP VIEW REAR VIEW BOTTOM VIEW Location of Transmitter controls 1. Channel Selector Button – Used to select between channels 1-4 2. LED Channel Indicators – Indicator light shows selected channel 3. 2.4 GHz Antenna – High gain dipole antenna transmits audio and video signal to the wireless receiver 4. -
Page 8: Wireless Receiver
CONTROLS & FUNCTIONS WIRELESS RECEIVER TOP VIEW REAR VIEW BOTTOM VIEW Location of Receiver controls 1. Channel Selector Button – Used to manually switch channels from 1-4 2. LED Channel Indicators – Indicator light shows selected channel 3. 2.4 GHz Antenna – High gain dipole antenna receives audio and video signal from the wireless transmitter 4. -
Page 9: Installation Of Wireless Transmitter
INSTALLATION OF TRANSMITTER CONNECTING A TRANSMITTER SIGNAL FROM YOUR VCR/ SATELLITE/DVD STEP 1: Back of Transmitter Rear of Electrical Outlet RCA Cable (Supplied) Ensure the Power Switch on the Transmitter is turned OFF prior to NOTE proceeding with the following steps. 1. - Page 10 INSTALLATION OF RECEIVER CONNECTING A RECEIVER TO A REMOTE TV USING RCA CABLES STEP 2: You have two options to connect the Receiver: A) Using RCA Cables (see below), or B) Coaxial Cables, please refer to page 7 of this manual. Television Back of Receiver Electrical Outlet...
- Page 11 INSTALLATION OF RECEIVER CONNECTING A RECEIVER TO A T.V. USING COAXIAL CABLES Television Back of Receiver Electrical Outlet Audio Video Coaxial Cable (75 ohm) Ensure the Power Switch on the Receiver is turned OFF prior to NOTE proceeding with the following steps. 1.
- Page 12 INSTALLATION OF RECEIVER CONNECTING A RECEIVER TO A REMOTE TV THROUGH A VCR RCA Cable (Supplied) Rear of Back of Receiver RCA Cable (Not supplied) Television Electrical Outlet Audio Video Ensure the Power Switch on the Receiver is turned OFF before NOTE proceeding with the following steps.
-
Page 13: System Operation
SYSTEM OPERATION CONNECTING MORE VIDEO DEVICES TO YOUR SYSTEM (MAX. OF 4) The Video Sender system allows you to connect more than 1 transmitter and receiver. Connecting more than one transmitter to the system is normally utilized when viewing multiple Video sources on a television or monitor. You also have the option to connect multiple receivers to this system for viewing your Satellite/DVD picture from multiple rooms. -
Page 14: Troubleshooting
TROUBLESHOOTING If the system does not function properly, check the following points before contacting the service center. Causes & Remedies Problems Video Source Receiver/Transmitter No power - Video source/ device not -AC adapter not plugged in (no picture/sound) connected to transmitter - Power switch not turned on - AC adapter not plugged in - TV or Monitor not turned on... -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS WIRELESS TRANSMITTER Power supply AC adapter 9V DC 500mA output Current consumption 150 mA TYP. Channel frequency 2.411 – 2.473 GHz Channel selection 4 channel Modulation system FM modulation Video channel Video input level 1 Vpp @ 75 Ohm Audio channel Audio input level 1 Vpp @ 600 Ohm... -
Page 16: Care & Maintenance
CARE AND MAINTENANCE: Please follow these instructions to ensure proper care and maintenance of this system Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices. - Page 17 It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades VISIT www.lorexcctv.com www.lorexcctv.com Lorex Technology Inc.
