OMEZ TitanBeam 10R User Manual

280w moving head beam
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Introduction
Thank you for purchasing the OMEZ TitanBeam™ 10R. This moving head
fixture, characterized by its exceptional bright light beam, is a new product
in the Titan Line. This fixture is CE compliant and has a perfect
combination of advanced electronic controlling technology with standard
TitanBeam™ 10R
DMX 512 control. Programing is a breeze on the fixture's LED touch
screen menu display panel.
OMEZ TitanBeam™ 10R has a 280 watt discharge lamp with reflector
User Manual
that projects a high quality long range beam of light. With 5 high quality
step motors you can pan, tilt, and focus with fast, smooth precision.
OMEZ TitanBeam™ 10R features one color wheel with 13 colors plus
open and two gobo wheels with 14 static and 9 rotating gobos. Added to
the 10R is the pulse strobe feature; a steady, longer, and smoother
shutter effect. This fixture is designed for easy transport for mobile
Production companies.
The OMEZ TitanBeam™ 10R is the industry standard in T.V. reality
shows, arena's, concert halls, banquet halls, performing art centers,
theaters, nightclubs, and entertainment venues.
Omez Guarantee
This TitanBeam™ 10R has met all quality control requirements when tested
280W Moving Head
in our factory and is known to be in perfect condition when shipped to our
warehouse in El Monte, California. Final quality control inspections are
Beam
conducted upon arrival at our facility. In order to ensure the safe operation
of this TitanBeam™ 10R it is absolutely necessary for the end user to follow
the safety instructions and warnings notes written in this user manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TitanBeam 10R and is the answer not in the manual?

Questions and answers

Summary of Contents for OMEZ TitanBeam 10R

  • Page 1 Introduction Thank you for purchasing the OMEZ TitanBeam™ 10R. This moving head fixture, characterized by its exceptional bright light beam, is a new product in the Titan Line. This fixture is CE compliant and has a perfect combination of advanced electronic controlling technology with standard TitanBeam™...

  • Page 2: Table Of Contents

    Contents 2 Safety Information Introduction/Omez Guarantee ... ……….………………..1 …………………….………..2 Safety information ………………………………3 Included in package Features ..…………………….……….4 ……………………………….5 Control panel DMX Channels .………………………………6 Installation ...…………………………….7 .……………………………….8 Cleaning & maintenance (Before plugging in this fixture, Please read manual)

  • Page 3: Included In Package

    3. Included In Package This box includes items listed below Accessories UNIT User manual Warranty card Suspension fasteners DMX cable  4. Features   Modes: 13/16/20 Channels  Lamp Type: 280w Discharge Lamp  Color Temperature: 9300K  0-100% Linear Dimming ...

  • Page 4: Control Panel

    5.4 Manual Tab 5. Control panel Option Instruction 5.1 Panel Reset all working motors in the fixture Reset Auto or sound active mode Test Run This fixture has 4 corresponding buttons esc, up, down, and Add value to the dmx channel Simulate DMX menu/enter.

  • Page 5: Dmx Channels

    5.7 Lamp Setting Tab 6. DMX Channels Option Instruction Channel Defe 13ch. Small 16ch. Standard 20ch. Default On or Off Color Wheel Manuel On or Off Shutter/Strobe Tilt Pan Fine Electronic On or Off Dimmer Pan Tilt Speed Tilt Gobo Function Tilt Fine Prism...
  • Page 6 6.1 Colors ( 6.2 Strobe DEFE) (DEFE) Function Value Description Function Value Description 0-31 Shutter Close Open 32-63 Shutter Open 09-17 Deep Red 64-95 Strobe Slow To Fast 18-26 Deep Blue 96-127 Shutter Open 27-35 Yellow Strobe 128-143 Pules Fast To Slow 36-44 Green Strobe...
  • Page 7 6.4 Gobo’s 6.5 Prism (DEFE) (DEFE) Function Value Description Function Value Description 0-19 No Prism Open Prism Gobo 1 20-75 6 Linear Prism 10-15 Gobo 2 76-255 8 Facet Prism 16-21 Gobo 3 Prism Adjust 0-255 Adjust Position 22-27 Gobo 4 28-33 Gobo 5 Static Gobo...
  • Page 8 6.6 Frost & Focus (DEFE) Function Value Description Frost 65-255 Linear Frost Focus 0-255 Focus 6.7 Pan & Tilt (DEFE) Function Value Description 0-255 Pan Fine 0-255 Pan Fine Tilt 0-255 Tilt Tilt Fine 0-255 Tilt Fine...
  • Page 9 6.0 DMX Small & Standard Mode 6.3 Colors 6.1 Pan & Tilt 16 Ch. 24 Ch. Function Value Description 16 Ch. 24 Ch. Function Value Description Mode Mode Mode Mode Open 0-255 09-17 Deep Red Pan Fine 0-255 Pan Fine 18-26 Deep Blue Tilt...

  • Page 10: Gobo

    6.5 Glass Gobo’s 6.4 Static Gobo’s 16 Ch. 24 Ch. Function Value Function 16 Ch. 24 Ch. Function Value Description Mode Mode Mode Mode Open Open Gobo 1 Gobo 1 8-10 Gobo 2 10-15 Gobo 2 11-13 Gobo 3 16-21 Gobo 3 14-16 Gobo 4...

  • Page 11: Gobo

    6.6 Gobo Rotation 6.9 Frost Zoom Focus 16 Ch. 24 Ch. Value Description 16 Ch. 24 Ch. Value Description Mode Mode Mode Mode 0-64 No Action 0-127 Index 65-255 Linear Frost 128-177 Slow To Fast 0-255 Linear Zoom 178-203 Stop 0-255 Zoom Fine 204-255...
  • Page 12 6.3 Dimmer 16 Ch. 24 Ch. Value Description Mode Mode 0-255 0%-100% 0-255 No Action...

  • Page 13: Installation

    7. Installation When resetting fixture please allow an average of 20 sec. for the fixture to reset all Mounting the fixture in areas away from reach of unauthorized sensors and motors. Fixture will continue where it left off. The lamp will stay on so personnel is always recommended.
  • Page 14 • There appears to be any tampering, altering, or removal of the original serial number; • The product is modified or altered in any way, including the removal or covering of the Omez Branding; • Any modifications are made that affects the reliability of the product;...
