Summary of Contents for RCBI Roadscan Pro DE Series

  • Page 3 My Driving Recorder! VEDR (Video Event Data Recorder) Continuous Recording DT (Digital Tachometer) [This product is the VEDR system for vehicles.] - We do not take responsibility for the malfunction and accident caused by inappropriate use, mounting and alteration. and keep it well to read if and when needed. Software provided by this product is designed to operate on the PC with Windows XP/Vista installed.

  • Page 4: Table Of Contents

    Table of contents *Product guide 1. Caution during use ---------------------------------------------------------------- 4 3. Names of each part --------------------------------------------------------------- 7 4. VEDR function ---------------------------------------------------------------------- 8 5. Continuous Recording Function ---------------------------------------------- 10 6. DT Function -------------------------------------------------------------------------11 7. Button’s function ------------------------------------------------------------------ 12 8. Guide on LED Display and Buzzer Sound ----------------------------------- 13 9.

  • Page 5: Product Guide

    Product guide 1. Caution during use This guide ensures user’s safety and helps to use the product properly. Read carefully and use carefully. operation, and user may not be entitled to free service if and when product malfunction is caused by user’s fault. 2) Do not spray water directly to clean up the vehicle’s interior.
  • Page 6 9) VEDR data may not be recorded during accident with lower than function) aware of this point. 11) Product may be upgraded after launch to add on more functions and to increase customer convenience. 12) Time is re-set automatically depending on the GPS time information.
  • Page 7 [Check to see whether all the components included in the following diagram are included.] 1) Main body 2) SD Card (Including User Manual and Software) 3) SD Card Reader 4) External Switch 5) Cable Mount SD Card SD Card Reader Main body External Switch Cable Mount...

  • Page 8: Names Of Each Part

    3. Names of each part Main body is comprised of the module that processes and assesses status on the camera, current image and situation with the internal CPU. >>Name of main body’s each part is shown on the following diagram.

  • Page 9: Vedr Function

    4. VEDR function NOTICE The VEDR mode is disabled during Continuous Recording mode. To enter the VEDR mode user must press the FN button once. VEDR mode starts. By pressing FN button again the VEDR mode stops and the Continuous Recording mode re-starts . If no SD-card is installed , the Roadscan enters automatically the VEDR mode, Continuous Recording mode is disabled.
  • Page 10 [Stable image storing function using back-up power] In the case of large accident, there is a potential that power will be severed. However, accident image is saved safely even when power is severed thanks to the built-in back-up power located in the main body. At this time, however, image is recorded up to the point when power is severed for safe image of accident storing, and does not record data afterwards.

  • Page 11: Continuous Recording Function

    [VEDR Impact Level] It is possible to set up impact level at which the product recognizes that it is an Event. Value that is applied to the vehicle. Recording upon Normal Impact Critical Impact Type REC button and External Switch Recording upon Recording upon When user presses...

  • Page 12: Dt Function

    6. DT Function DT function is to store route, time and speed during driving of the vehicle. DT data can be downloaded to SD Card by pressing FN button for 3seconds. [Recording Time] Total recording time of DT is about 30 days when driving for 24 hours a day.

  • Page 13: Button's Function

    7. Button’s function [REC button] It is possible to record image manually by using REC (Record) button. Press on the REC button to record image manually, and image and information is recorded in Flash Memory and move to SD Card automatically.

  • Page 14: Guide On Led Display And Buzzer Sound

    8. Guide on LED Display and Buzzer Sound [Description of LED Display] Status Status Abnormal state on the device. Blink Operating status with power or battery. Status with no SD Card or unrecognized SD Card. Blink Storing images or upgrading device. SD Card is normally operated.
  • Page 15 [Buzzer Sounds and LED Display upon Operation of Product] (Functions by pressing the FN button for 3 seconds)

  • Page 16: Product Upgrade

    9. Product Upgrade This product may be subject to change of software in the future for the purpose of performance improvement, etc. Upgrade can be supported through websites of manufacturer and seller and upgrade and installation should be executed by the user personally in principle.

  • Page 17: Software Guide

    Software guide 1. Software Installation (1) Connect provided SD Card to PC. (2) Open program folder within SD Card. (3) Run setup.exe within program folder. (4) When a screen is displayed as below, press “Next” button. (5) When a screen is displayed as below, press “Next” button.
  • Page 18 (6) When a screen is displayed as below, press “Next” button. (7) When a screen is displayed as below, press “Next” button.
  • Page 19 (8) When a screen is displayed as below, press “Install” button. (9) When program installation is completed, a screen is displayed as below. Press “Finish” button to end installation.

  • Page 20: Login

    2 . Login In order to use Google Map, it is required to enter provided ID and Password. Use 6 character ID code, not email address Use 6 character PW code. 3. Description of Software Screen (1) Menu Button It includes functions such as File View, Download, Device Setup, etc. (2) Display Window It displays images of Event data or DT data.

  • Page 21: Function And Description Of Button

    4. Function and Description of Button (1) Mode Change : It allows displaying VEDR data and DT data alternately. When you press the button, display mode changes to VEDR display mode and DT display mode alternatively. At the moment, shape of button is also changed.
  • Page 22 Notice !! When OK button is pressed while only folder is designated as shown on the database screen on the right. (Possible to search up to 10,000) 1) To search by date, designate the start and ending date on the date dialog box, and check on the box on the left side and then press on the OK button.
  • Page 23 (3) SD Card Open : It lists all of images within SD Card. (4) File Open (maximum of 10,000)
  • Page 24 (5) Download : This is the function that downloads main body’s SD Card’s data to a PC. Use Card reader to download main body’s data to a PC. To download, press on the download button while SD Card is connected to a PC, and the following Dialog box appears.
  • Page 25 (7) Device Setup It stores settings of the device into SD Card. It allows setting up Impact Level, resolution, audio storage, etc. [Impact Level] If the product receives impact value larger than the impact level setting, it stores data automatically. If you want to record the image data less frequently, select higher value of G.
  • Page 26 (8) User Setup Environment Settings that enable Management Settings and environment setup that makes it possible to manage with vehicle number, driver’s name and management number when it comes to each serial number. After vehicle number is registered, it is downloaded to the vehicle number folder when it comes to the setup serial number, and it is downloaded to the serial number folder when it comes to the serial number that is not setup.
  • Page 27 [Management Settings] *How to input Management Settings (1) Click on the Add button after inputting Serial No., Car No., Driver Name and Management No. At this time, at least one value among serial number, vehicle number, driver’s name and management number must be input. onto the list.
  • Page 28 (9) Graph Display Displays the acceleration data and the impact data, speed data in detail. Graph indication can be converted to Acceleration, Impact and Velocity sequentially. Click button => The button will be changed to and displays the impact data. Click button =>...
  • Page 29 (10) About Software Shows the version of software and your registered serial number. (11) Play Buttons Play the video display continuously. Pause the video display and initialize the video display. Pause the video display. Show previous frame. Show next frame. (12) Auxiliary Buttons Graph indication conversion button This is the function that can convert Graph indication, and it is possible...
  • Page 30 Driving Record Playing Speed Setup DT playing speed setup This is the function that sets up the speed to increase/decrease speed of play on the DT mode. Increases speed up to 4 compact disk access time to x 1 x 4 when is pressed on Decreases speed up to 4 compact disk access time to x 1 x 1/2...

  • Page 31: Description Of Data Information Display

    5. Description of Data Information Display To display recording time of the current image frame display mode) To display latitude out of location information for the current image frame To display longitude out of location information for the current image frame registered with user setup) with user setup) registered with user setup)

  • Page 32: How To Download And Play Data

    6. How to download and play data 1) Connect SD Card having device data to PC. 2) After executing software, click Download button. 4) When download is completed, click File Open button. 6) Click Play button. 7) It is possible to display downloaded data as shown on a window below.
  • Page 33 8) In order to display DT data, click “Mode Change” button. 9) As the button changes to , it is switched over to DT display window. 10) Click File Open button. 12) Click Play button. 13) It is possible to display downloaded DT data as shown on a window below.

  • Page 34: Acceleration Data Interpretation Method

    7. Acceleration data interpretation method The following includes various data interpretation examples. analyze the type of accident. Time [Stop State] Time Time [Acceleration] [Brake State] Time Time [Right Turn State] [Left Turn State]...

  • Page 35: Impact Assessment Graph

    8. Impact assessment graph If the IMPACT value of one record is greater than the trigger G value, then the system is triggered, and an image-and-data set is recorded into memory. IMPACT 0 .5 G Trigger G Value [sensitivity of trigger condition] Time [IMPACT data graph]...

  • Page 36: Installation Guide

    Installation guide 1. Caution during installation Prior to installation, check whether contents of the product are included, and mount according to the set procedure after understanding the contents of the installation guide. 1) During product installation, even when the lever of transmission is set for the N level, it is necessary to mount on the ground surface on a perpendicular 2) Select location for mounting that does not block driver’s view at the mirror located in front of the vehicle.

  • Page 37: Mounting

    2. Mounting When vehicle is moving or stopped or when contact accident or collision results, this product records the before and after of the accident into image. At the same time, this product records vehicle’s acceleration Basic mounting location of the product is top or bottom of front window of the vehicle.

  • Page 38: Mounting Sequence

    3. Mounting sequence Product’s basic mounting location is located at the upper part of the center of the vehicle’s front mirror. This location is the front part of the room mirror in the case of the passenger car. Attach the part with the tape attached onto the mirror, and adjust the angle so that it becomes perpendicular to the ground surface to complete the mounting.
  • Page 39 Notice!! User can connect “ Secret emergency button” with Roadscan Pro by cabling as below.

  • Page 40: Wiring Guide

    4. Wiring Guide This product supplies power by connecting to the vehicle with power cable. To arrange power cable, it is possible to use the mount that is provided to arrange the power cable. How to use the mount 1. Eliminate the sticker located at the rear of the mount, and attach onto desired location.

  • Page 41: Before Suspecting Malfunction

    Before suspecting malfunction 1) When image cannot be recorded, 1-1) Check whether there is SD Card in the main body. 1-2) Check whether it is SD Card provided by our company. Ordinary SD Card may not record. 1-3) recording may have failed due to the failed impact detection depending on the acceleration impact level.

  • Page 42: Product Specs And Operation Environment

    Product specs and operation environment Normal operation voltage 12V, 24V Minimum operation voltage Maximum operation voltage Maximum power consumption amount Operating temperature -20 degrees ~70 degrees Preserving temperature -40 degrees ~85 degrees Camera Type Color CMOS Camera Maximum Camera Pixel 350K Actual Camera Pixel 320K...

  • Page 43: Warranty Policy

    Warranty policy Warranty regulation was used normally within the warranty period (for one year from the day of purchase). where you purchased the product. 3. The following cases require you to pay for repair even during warranty period. (a) When malfunction is caused by user’s mistake. (b) Malfunction and damage caused during transport, movement and fall after product is purchased abnormal voltage, and use of power besides the designated (voltage...
  • Page 44 Importeur / Distributeur BENELUX RCBI BV Spoorstraat 7 - U705 4702VV Roosendaal Nederland GSM NL : 06-32031740 GSM B : 0495-518486 Tel/Fax NL : 0164-602928 Email : info@roadscan.nl www.roadscan.nl www.roadscan.be...
