(These instructions are intended for use by a technician familiar with electronic products)
2000VAC
I /O
i solation
•
DC
i nput
a ctive
s urge
c urrent
l imiting
•
Thermostat
c ontrol
f orced
a ir
c ooling
•
Short
c ircuit
/
o ver
l oad
/
o ver
t emperature
p rotection
•
3
y ear
w arranty
•
DESCRIPTION
The DCDC-500-48-12 is a DC-to-DC converter that is capable for 500 watts of power. It has isolated inputs and outputs, so it
can be used in positive ground installations. The fan is thermostat controlled to protect against heat damage. The input voltage range
has a minimum of 19 VDC and a max VDC of 72. All of the DCDC-500 models come equipped with three layers of protection short
circuit, over load, and over temperature protection.
SPECIFICATIONS
Input Voltage Range .................................................................................................................................................................... 19-72 VDC
Input Current ................................................................................................................................................................................. 24.0 Amps
Output Voltage to Load .................................................................................................................................................................. 12.0 VDC
Output Current ......................................................................................................................................................................... 40 Amps Max
Line Regulation .................................................................................................................................................................................+/- 0.5%
Max inrush current, single cycle ...................................................................................................................................................... 60 Amps
Efficiency ................................................................................................................................................................................................ 89%
Working Temperature range ...................................................................................................................................................-20 C to +60 C
Storage Temperature.............................................................................................................................................. -40 - 185 F (-40 - +85 C)
Size ......................................................................................................................................................................... 4.75" D x 19" W x 3.5" H
Weight................................................................................................................................................................................................ 4.5 Lbs
INSTALLATION WARNING
The individual user should take care to determine, prior to use or installation, whether this device is suitable, adequate or safe for the
use intended. Since individual applications are subject to great variation, DuraComm makes no representation or warranty as to the
merchantability, suitability or fitness of these units for any specific application.
DO NOT block any of the cooling vents on the sides and always allow adequate ventilation by not installing the unit inside tightly closed
spaces. Physical mounting position is not critical but the cooling vents must not be blocked. Make certain the input voltage is the
correct voltage BEFORE applying DC power.
DCDC-‐500-‐48-‐12
Rack
M ount
D CDC
C onverter
Owners
G uide
1
