SERVICE MANUAL
Ver 1.2 2004.12
Revision History
Revision History
How to use
How to use
Acrobat Reader
Acrobat Reader
Link
Link
SPECIFICATIONS
SPECIFICATIONS
SERVICE NOTE
SERVICE NOTE
DISASSEMBLY
DISASSEMBLY
• For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (9-876-760-51).
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (9-876-760-41).
• Reference No. search on printed wiring boards is available.
• The Cautions at the Time of Lens Block Handling
• The Method of Attachment of LC-084 Flexible Board
• The Method of Attachment of USB and DC IN Jacks on the JK-276 Flexible Board
• HELP: Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
On the CH-147 and SY-110 boards
This service manual procides the information that is premised the
circuit board replacement service and not intended repair inside the
CH-147 and SY-110 boards.
Therefore, schematic diagram, printed wiring board and electrical
parts list of the CH-147 and SY-110 boards are not shown.
The following pages are not shown.
Schematic diagram ................... Pages 4-9 to 4-28
Printed wiring board .................. Pages 4-37 to 4-40
Waveforms ................................ Pages 4-49 and 4-50
Mounted parts location .............. Page 4-51
Electrical parts list ..................... Pages 5-7 and 5-10 to 5-13
The above-described information is shown in service manual Level 3.
DSC-L1
9-876-760-31
Photo: Silver
BLOCK DIAGRAMS
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAM
FRAME SCHEMATIC DIAGRAM
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
Sony EMCS Co.
DSC-L1
Canadian Model
AEP Model
Hong Kong Model
Australian Model
Chinese Model
Korea Model
Brazilian Model
Tourist Model
Japanese Model
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
REPAIR PARTS LIST
DIGITAL STILL CAMERA
Published by DI Technical Support Section
2
LEVEL
US Model
UK Model
E Model
2004L0500-1
©2004.12
