IPTV MEDIA PLAYER
USER'S GUIDE
How to use your AraabTV THD504L
THD504L
www.araabtv.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THD504L and is the answer not in the manual?

Questions and answers

Summary of Contents for AraabTV THD504L

  • Page 1 IPTV MEDIA PLAYER USER’S GUIDE How to use your AraabTV THD504L THD504L www.araabtv.com...
  • Page 2 IMPORTANT SAFETY CONSIDERATIONS The THD504L set-top box requires careful handling to avoid potential damage to its internal parts. Be sure to follow these requirements during transportation and installation. The plug is the main disconnect device. It shall remain readily accessible and operable.
  • Page 3 THD504L USER’S GUIDE During Transportation to the Subscriber Home Transport the THD504L in its shipping box or an equally padded container. Do not expose it to rain or moisture. During Installation  Do not place THD504L in an enclosed area where the cooling vents are blocked or impede the flow of air through the ventilation openings.
  • Page 4 Do not place anything on top of your THD504L set-top box, especially other home entertainment components. Be sure to provide adequate ventilation to prevent overheating.  Install THD504L on a hard flat surface not prone to vibration or impact and not on top of another electronic device ...
  • Page 5 THD504L USER’S GUIDE FCC COMPLIANCE Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 6 THD504L USER’S GUIDE CARING FOR THE ENVIRONMENT BY RECYCLING When you see this symbol on aAraab TV product, do not dispose of the product with residential or commercial waste. Recycling your Araab TV Equipment Please do not dispose of this product with your residential or commercial waste. Some countries or regions, such as the European Union, have set up systems to collect and recycle electrical and electronic waste items.
  • Page 7 THD504L USER’S GUIDE © 2014 Araab TV. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from Cloud Antenne Services Sárl.

  • Page 8: Table Of Contents

    Adjusting the Volume ........................... 113 Interactive Programming Guide ........................14 Video Output Format Option .......................... 14 CONNECTING YOUR THD504L SET TOP BOX TO YOUR HOME ............. 15 HOW TO MANUALLYCONFIGURE THE THD504LSET-TOP BOX ............. 19 TROUBLESHOOTING ..........................344 8/ 36...

  • Page 9: Introduction

    THD504L USER’S GUIDE 1. INTRODUCTION We congratulate you on receiving thisTHD504L Series High-Definition All-Digital set-top box, one of the most compact and advanced interactive digital IPTV set-top boxes available today. Araab TV has combined the extraordinary features of IPTV — the interactive programming guides, almost endless programming options, Video on Demand (VOD), the incredible sound and picture quality of High-Definition TV (HDTV), and so much more.
  • Page 10 THD504L USER’S GUIDE Features  Video format support: MPEG-1 MPEG-2 MP@HL, MPEG-4.2 ASP, MPEG 4.10 AVC (H.264 & H.263), MP & HP TO LEVEL 4.1, VC-1 AP@L3, WMV9, SD & HD, DIVX, AVI, AVS, XVID.  Audio format support: MPEG-1 LAYER 1,2. MP3, WMA, WMA PRO, AAC LC, AA LC+SBR L2, AAC+L2, AAC+L4, AAC 5.1.

  • Page 11: Front Panel

    THD504L USER’S GUIDE Front Panel * Availability of certain features is dependent upon application support. Power and Activity LED IR Receiver 11/ 36...

  • Page 12: Rear Panel

    THD504L USER’S GUIDE Rear Panel * Availability of certain features is dependent upon application support. HDMI 1.4 LAN/Ethernet/RJ-45 AV Output Power Reset Button USB 2.0 12/ 36...

  • Page 13: Operation

    Turning Power On and Off Plug in the supplied power adapter to the electrical outlet and to the back of THD504L set-top box or use a remote control to turn it on or off (standby). When using the remote control, pressing the POWER button once will put THD504L set-top box on a standby mode while pressing and holding the same button for approximately 3 seconds will turn it off.

  • Page 14: Interactive Programming Guide

    Video Output Format Option THD504L set-top box allows you to quickly change the video output format used by the Composite Video, and HDMI outputs. The THD504L set-top box is capable of providing the following video formats on the HDMI video outputs: ...

  • Page 15: Connecting Your Thd504L Set Top Box To Your Home

    THD504L USER’S GUIDE 3. CONNECTING YOUR THD504L SET TOP BOX TO YOUR HOME Instructions and diagrams are included for the following connections:  High-Definition Television (HDTV)  Standard-Definition TV (SDTV)  WiFi Router  Before you move or change components on your entertainment system, review the following: ...
  • Page 16 If your TV has an HDMI input, this is for both audio and video if you are using the TV speakers. Connect the provided HDMI cable to the TV and to the HDMI connector on your THD504L set-top box. 16/ 36...
  • Page 17 Make sure you’re connected to the Internet without any problem (either with a router or a modem). Plug in the power adapter of the THD504L set-top box to the nearby power outlet. Connect the network cable from the set-top box to the router.
  • Page 18 Make sure you’re connected to the Internet without any problem (either with a router or a modem). Plug in the power adapter of the THD504L set-top box to the nearby power outlet. Connect the network cable from the set-top box to the router.

  • Page 19: How To Manuallyconfigure The Thd504Lset-Top Box

    THD504L USER’S GUIDE 4. HOW TO MANUALLYCONFIGURE THE THD504LSET-TOP BOX  On the Main Menu page, use the remote control buttons to navigate and select Settings tab.  Press Enter on the remote control to enter the Settings page. 19/ 36...
  • Page 20 THD504L USER’S GUIDE  On the Settings page, use the remote control buttons to navigate up and down selection. Select General tab and press right arrow button to enter the page. At any point of the operation if you wish to go back to the left side menu selection, you can either press the left arrow button or the Back button on the remote control.
  • Page 21 THD504L USER’S GUIDE  There are 3 different languages supported by THD504L: English, Russian, and German. Use the remote control to navigate up and down selecting your desired language. Once you have made a selection, press Enter on the remote control.
  • Page 22 THD504L USER’S GUIDE  On the Location page, select your location and press Enter. THD504L will then set itself to the location of your selection.  On the Settings page, use the remote control buttons to navigate to Skins tab, and press right arrow button on the remote control to select it.
  • Page 23 Network tab, and press right arrow button on the remote control.  If you want to connect the THD504L to your home network by means of a network cable, then select LAN (Local Area Network) tab and press Enter.
  • Page 24  Select Static tab and press right arrow button only if you have the necessary information about your network and want to manually configure the network connection of THD504L into your home network.  Press any numeric button on the remote control, and it will bring up the soft keyboard onto the screen.
  • Page 25  Select DHCP if you don’t want or need to manually configure the IP address for your THD504L. Press right arrow button to select it. 25/ 36...
  • Page 26 THD504L USER’S GUIDE  You will then be asked to confirm if you want the DHCP mode to be enabled or not.  Once you have selected yes, and press Enter on the remote control, then the DHCP mode is enabled from then...
  • Page 27 THD504L USER’S GUIDE  On the Network settings page, use the navigation buttons on the remote control to move up and down to select between tabs. Select PPPoE and press right arrow button on the remote control to enter. ...
  • Page 28 THD504L USER’S GUIDE  Please wait while THD504L is trying to establish the network connection for you.  When it has successfully established the connection you will see the check mark next to the PPPoE tab. 28/ 36...
  • Page 29 THD504L USER’S GUIDE  If you want to connect THD504L to your home network by means of wireless connection, then on the Network page select WIFI and press the right arrow button on the remote control to enter the WIFI page.
  • Page 30 THD504L USER’S GUIDE  Once you have made your selection, and press Enter on the remote control you will then be asked for the password. Here you can press any numeric button on the remote control to bring up the soft keyboard for ease of entering information into the required field.
  • Page 31 THD504L USER’S GUIDE  The next time you enter the Network page you will see that you’re connected to your home network by WiFi when you see the check mark next to the WIFI tab.  On the Settings page, use the navigation buttons on the remote control to select Video, and press right arrow button to enter the display mode page.
  • Page 32 THD504L USER’S GUIDE  On the Display Mode tab, press right arrow button to select it.  Select the display mode that you want by pressing Enter on the remote control. Please base your selection on what your television unit can support. Once you have made the right display mode selection, you will see a check mark next to the display mode of your selection.
  • Page 33 On the Settings page, use the navigation buttons on the remote control and select About tab and press right arrow button to know more information about your THD504L. You might need to provide this information to your service provider or for some customer assistance.

  • Page 34: Troubleshooting

    If your problem still exists, contact your service provider. Problem Possible Solution The THD504L The THD504L set-top box may have received a software update and may not power on set-top box will while the new software is being installed. Try again in a few minutes. ...
  • Page 35 Verify that there are no obstructions between the remote control and the THD504L set-top box. Also check to see if there’s any plastic cover on the front panel of THD504L. If so, please remove it as it might affect the remote control reception.
  • Page 36 THD504L USER’S GUIDE No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Cloud Antenne Services Sárl. Under the law, reproducing includes translating into another language or format.
