ChannelPlus DA-8200BID User Manual

Specifications: typical @ 25°C ± 5°C
Gain:
CATV/Antenna port to output
Modulator input to output
Output to CATV (reverse)
(5-42MHz)
Isolation
Modulator input to CATV/Ant
Max CATV/Antenna input
Power Supply (included)
General
Width x height x depth (cm)
Shipping weight
Multiplex Technology, Inc. warrants this product to be free from defects in
materials and workmanship for a period of one year from the date of purchase
or MTI will repair, or at its option, replace the defective product. To obtain
warranty service, call MTI for a return material authorization (RMA) number and
return the product prepaid to Multiplex Technology, Inc., 3001 Enterprise Street,
Brea, CA 92821, Attention: Customer Service. Please put the RMA number on
the outside of the carton.
Any implied warranty arising from the sale of the product including implied
warranties of merchantability and fitness for purpose are limited to the warranty
stated above. MTI shall not be responsible for losses or damages or expenses,
whether direct, consequential or incidental arising from the use of or the inability
to use this product. Some states do not allow limitations on how long the implied
warranty lasts or the exclusion or limitation or incidental or consequential
damages, so the above limitations and exclusions may not apply to you. This
warranty gives you specific legal rights, and you may have other rights which
may vary from state to state.
© 2001 Multiplex T echnology, Inc., Brea, CA
600-237 rev B
DA-8200HHR DA-8200BID
3dB 3dB
-10dB
-10dB
n/a -15dB
>80dB >35dB
5-1000MHz 54-1000MHz fwd
20dBmV(+85dBuV)
20dBmV(+85dBuV)
15 VDC @ 300mA 15 VDC @ 300mA
6.5" x 1.25" x 4.5"
4 lbs.
Warranty
PERFORMANCE MUL TI-ROOM VIDEO
3 x 8 Coax Cable Panel
DA-8200BID
DA-8200HHR
bi-directional 3 X 8 coax panel for cable systems
B
(pwr)
mod input tv output
A
5v, multi-room ir remote control
B
(pwr)
mod input
A
5v, multi-room ir remote control
