taiyo RX-802AS Operation Manual

Temperature controlled lead-free soldering station
Hide thumbs
Table of Contents

Advertisement

Quick Links

KEEP THIS MANUAL FOR FUTURE REFERENCE
WARNING
Before using the soldering station, read the Operation Manual.
Failure to follow the safety precautions and instructions in this
manual could result in serious injury and property damage.
Thank you for buying a goot soldering station. Your new soldering station has been
engineered and manufactured to the goot high standards for dependability, ease of
operation, and operator safety. If you follow the instructions and safety precautions in this
manual and use the soldering station properly and only for what it is intended, you will enjoy
years of safe, reliable service. Thank you again for buying a goot soldering station.
TAIYO ELECTRIC IND.CO.,LTD.
TEMPERATURE CONTROLLED
LEAD-FREE SOLDERING STATION
RX-802AS
TAIYO ELECTRIC IND.CO.,LTD.
OPERATION MANUAL
Tips not included
Tips sold separately
1
4
ver.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RX-802AS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for taiyo RX-802AS

Summary of Contents for taiyo RX-802AS

  • Page 1 TAIYO ELECTRIC IND.CO.,LTD. ver. OPERATION MANUAL TEMPERATURE CONTROLLED LEAD-FREE SOLDERING STATION RX-802AS KEEP THIS MANUAL FOR FUTURE REFERENCE Tips not included Tips sold separately WARNING Before using the soldering station, read the Operation Manual. Failure to follow the safety precautions and instructions in this manual could result in serious injury and property damage.
  • Page 2 TAIYO ELECTRIC IND.CO.,LTD. Safety Mark Definitions Following the WARNINGS and CAUTIONS in this manual will allow for the safe and proper use of the soldering station, and should protect the operator from injury and operators' property against damage. WARNING Failure to obey a safety warning could result in serious injury or death to yourself or to others.

  • Page 3: Table Of Contents

    TAIYO ELECTRIC IND.CO.,LTD. 1 Table of Contents Table of Contents / Specifications ..............3 Introduction ................... 4 2.1 Unpacking ................... 4 2.2 Name of Parts ................... 5 2.3 Soldering Iron Stand ST-21 Instructions ..............7 3. Rules for Safe Operation ..................8 4. Operation Instructions ..................10 4.1 Changing the Set Temperature ..............

  • Page 4: Introduction

    TAIYO ELECTRIC IND.CO.,LTD. 2 Introduction Unpacking Please make sure that all the items listed below are included, and that the soldering station (control unit and soldering unit) function properly. If any items are missing or damaged, please contact your goot distributor. Please store the packaging for future shipment or repair.

  • Page 5: Name Of Parts

    TAIYO ELECTRIC IND.CO.,LTD. Name of Parts Operation Panel TEMP. ˚C RX-802 HEAT SLEEP LOCK Operation Panel TEMP. ˚C RX-802 HEAT Output Terminal for SLEEP Operation Panel Soldering Unit TEMP. ˚C LOCK RX-802 Cover HEAT SLEEP Output Terminal for LOCK Soldering Unit...
  • Page 6 TAIYO ELECTRIC IND.CO.,LTD. ■ Operation Panel ③ ① TEMP. ˚C RX-802 HEAT ④ SLEEP ② ⑤ LOCK ⑥ ⑦ ⑧ ⑨ 1. HEAT lamp Lights up when the heater is ON. 2. SLEEP lamp Flashes while setting the SLEEP function. The flashing of the sleep lamp will increase 30seconds before entering SLEEP mode.

  • Page 7: Soldering Iron Stand St-21 Instructions

    TAIYO ELECTRIC IND.CO.,LTD. Soldering Iron Stand ST-21 Instructions WARNING lHigh temperatures. Handle with care. lTo avoid injury, do not touch the metal part of the stand. lTo prevent fire, do not use the ST-21 near flammable substances. CAUTION lAlways place the stand on a stable worktable, or other stable location, to prevent injury or accident from dropping it.

  • Page 8: Rules For Safe Operation

    TAIYO ELECTRIC IND.CO.,LTD. 3 Rules for Safe Operation WARNING The RX-802AS is an anti-static model. Be sure to properly ground the soldering station using a grounded receptacle to prevent electric shocks and anti-static. If it is not properly grounded, electric shocks will occur. As...
  • Page 9 TAIYO ELECTRIC IND.CO.,LTD. 7. USE STAND PROVIDED. Be sure to use the ST-21 soldering iron stand included with the soldering station. If this stand is not used, the plastic parts (adapter ring and/or handpiece) of the soldering iron unit could be damaged. Position the soldering iron stand on a flat work-surface or bench.

  • Page 10: Operation Instructions

    TAIYO ELECTRIC IND.CO.,LTD. Changing the Set Temperature When the station is shipped the temperature is set at 250°C (482°F). The temperature can be set from 50°C (122°F) to 450°C (842°F). *For the steps given in the operation instructions, only °C is used.

  • Page 11: Calibration Of The Tip Temperature

    TAIYO ELECTRIC IND.CO.,LTD. Calibration of the Tip Temperature RX-80HRT-B is mounted in the standard unit. When changing to a different type of tip, the calibration of the tip temperature is required before starting soldering work. Otherwise, there may be a difference between the actual tip temperature and the set temperature of the unit.

  • Page 12: Calibration Function

    RX-802AS control unit display. This could be because the tip is not coming into contact properly with the sensor of the tip thermometer. It could also be...

  • Page 13: Sleep Function

    TAIYO ELECTRIC IND.CO.,LTD. Sleep Function The sleep start timer (CT) function automati- cally lowers the temperature of the tip after a DIF (Sensitivity) Set temperature preset period of inactivity. This function reduc- es power consumption and helps extend sol- dering tip life. This sleep function can be used Operation with the shutdown function (see 4-5) together.
  • Page 14 TAIYO ELECTRIC IND.CO.,LTD. Setting the Sleep start Set to 5 minutes before shipping. time (CT) Unit: mins. Example : Changing the sleep start time from 5 to 10 minutes. Key Operation TEMP Display Press and hold the key for over...
  • Page 15 TAIYO ELECTRIC IND.CO.,LTD. Setting the Sleep Example : Changing the Sleep Sensitivity value to 2 °C (3.6°F) Sensitivity (DIF) Unit : °C to 3.0°C (5.4°F). Key Operation TEMP Display Press and hold the key for over Displays 3 seconds continuously.

  • Page 16: Setting The Shutdown Function

    TAIYO ELECTRIC IND.CO.,LTD. 4-5 Setting the Shutdown Function When the unit is not operated during the preset time, the unit is automatically shutdown. Even if the user forgets to turn OFF the unit, this Shutdown function works to keep the unit inactive, and prevents accidents such as fire.

  • Page 17: Setting The Soldering-Time Alarm

    OFF and then ON again to operate the unit. 4-6 Setting the Soldering-time Alarm The RX-802AS sounds an alarm, when the soldering iron is left in contact with the component being soldered past the time set. This function prevents inexperienced operators from overheating the component.

  • Page 18: Setting The Temperature Range For The Alarm

    TAIYO ELECTRIC IND.CO.,LTD. Setting the Temperature Range for the Alarm This function indicates to the operator with the sound of the alarm, when Lower limit temp. Upper limit temp. the tip temperature goes past the set parameter. The illustration on the right...

  • Page 19: Setting The Alarm Sound

    TAIYO ELECTRIC IND.CO.,LTD. 4-8 Setting the Alarm Sound This setting switches the alarm ON and OFF. The initial setting is ON (the alarm sounds). Set to OFF for mute (no sound). Setting the alarm sound Key Operation TEMP Display Press and hold the Displays for over 3 seconds continuously.

  • Page 20: Setting The Temperature Display

    TAIYO ELECTRIC IND.CO.,LTD. Setting the Temperature Display The temperature can be viewed in Celsius or in Fahrenheit. The temperature display is set to Celsius (˚C) before shipping. Key Operation TEMP Display Press and hold the key for over Displays alternately 3 seconds continuously.

  • Page 21: Key Lock Function

    TAIYO ELECTRIC IND.CO.,LTD. 4-10 Key Lock Function The Key Lock function locks the temperature and parameter settings. Therefore the temperature and parameters cannot be changed by any unauthorized personnel. Authorized personnel may use a code number to set, or release the Key Lock function.
  • Page 22 TAIYO ELECTRIC IND.CO.,LTD. How to Change the Code Number Example : When changing the code number from 123 to 234. Key Operation TEMP Display Press the key. Displays alternately Press and hold the for over 3 seconds continuously. Displays alternately...
  • Page 23 TAIYO ELECTRIC IND.CO.,LTD. Resetting the Code Number If you forget the code number, follow the procedure below to delete the code number and reset the key lock. This procedure releases the key lock function which means that unauthorized persons can change temperature and/or parameter settings. Please keep this manual with authorized personnel only and in a safe place for future reference.

  • Page 24: How To Restore The Default Settings

    TAIYO ELECTRIC IND.CO.,LTD. 4-11 How to Restore Default Settings By doing the procedure shown below, all the parameters will be restored to the default settings set before the unit was shipped. The key-lock function is also unlocked using this procedure. This can allow a third party to alter the settings on the unit.
  • Page 25 TAIYO ELECTRIC IND.CO.,LTD.

  • Page 26: Maintenance

    TAIYO ELECTRIC IND.CO.,LTD. 5 Maintenance CAUTION The soldering unit is designed so the tip can be replaced without turning OFF the power. However, the tip is very hot. Do not touch the tip or serious burns may result. The removed tip should be placed in the hole in the iron stand tip end first and kept in there until it cools down.

  • Page 27: How To Change The Grip Rubber

    TAIYO ELECTRIC IND.CO.,LTD. How to Change the Grip Rubber 1. Remove the screw. Turn and pull the Grip adapter 2. Remove the old grip rubber and grip adapter to remove the grip rubber. replace with new one. Screw Screw ❶...

  • Page 28: Troubleshooting

    TAIYO ELECTRIC IND.CO.,LTD. What to do when the tip is blackened and not ‘wettable’ Using a clean sponge, repeat the process of ’tinning’ and ‘cleaning’ the tip several times. The tip surface of an iron that has been in use a short time, generally has a higher ‘wettability’...

  • Page 29: Replacement Tips

    TAIYO ELECTRIC IND.CO.,LTD. 7 Replacement Tips 34.5 RX-80HRT-LB   RX-80HRT-B RX-80HRT-2B RX-80HRT-SB RX-80HRT-LB ¥1,575 (税別 ¥1,500 ) 12.7 RX-80HRT-LBJ RX-80HRT-BM RX-80HRT-1BC RX-80HRT-2.3BC 30˚ RX-80HRT-3BC RX-80HRT-0.5C RX-80HRT-1C RX-80HRT-2C 11.5 RX-80HRT-2CD RX-80HRT-3C RX-80HRT-3CD RX-80HRT-4C 11.5 11.5 11.5 RX-80HRT-4.7C RX-80HRT-0.8D RX-80HRT-1.2D RX-80HRT-1.6D RX-80HRT-2.4D RX-80HRT-3.2D...

  • Page 30: Replacement Parts

    TAIYO ELECTRIC IND.CO.,LTD. 8 Replacement Parts For replacement parts, contact a goot distributor. Item Parts No. Note RX-802AS Soldering unit RX-80GAS Tip is not included Soldering Iron Stand ST-21 STAND FOR RX-8 SERIES Soldering Iron Stand Sponge ST-53SP Replacement sponge for ST-21...

  • Page 31: Parameters

    TAIYO ELECTRIC IND.CO.,LTD. 9 Parameters Term Display Shipping Unit Range (display panel letters) Panel Default Setting ˚C — (SSt + 50) Set Temperature (PT) ˚F — (SSt + 90) Tip Number — 0—5 (tPn) Temperature Calibration ˚C -50—50 ˚F -90—90 (cAL) ˚C...
  • Page 32 TAIYO ELECTRIC IND.CO.,LTD. Customer service: Contact your nearest distributor SOLDERING EQUIPMENT AND ACCESSORIES TAIYO ELECTRIC IND.CO.,LTD. HomePage: www.goot.co.jp E-mail: info@goot.co.jp goot is registered trade mark of TAIYO ELECTRIC IND.CO.,LTD. Printed in Japan JULY 2014 A1220MY00...
