- Page 2 Villa ® Bellavista ITALIAN PRESTIGE RIGID TURNTABLE Owner’s Manual...
-
Page 3: Table Of Contents
MANUFACTURED IN ITALY TEL.+39.0571.675005 FAX.+39.0571.675013 Bellavista Italian Prestige Rigid Turntable Table Of Contents Congratulations & Introduction Box Content Construction Features Set-up Instructions Positioning Operating the Bellavista Specifications Warranty, Customer Service & Warnings - Troubleshooting - Troubleshooting F.A.Q. Adjustment... - Page 4 VERY IMPORTANT Please read the following instructions carefully before installing your Bluenote Villa® Turntable Bellavista Italian Prestige Rigid Turntable Congratulations Villa Thank you for having purchased a ® product. Introduction Villa® Villa® With products you enter a new dimension. Villa® the new way of listening to music.
-
Page 5: Congratulations & Introduction
of drive speed and power that cannot be reached with conventional turntables. The synchronous motor is made to 24 pole specifications for further enhancing the performance. Villa® In a word, the range sets a new standard of reference in the turntable category. Congratulations &... -
Page 6: Set-Up Instructions
Moreover, the bearing is threaded on the outside (the only one of its kind) in order to be tightly anchored to the board of the turntable on its own axis. This allows avoiding the use of glue and anchoring screws that would lock the bearing out of align ment and prevent a fully rigid and precise coupling. -
Page 7: Positioning
The spindle should now spin smoothly, and freely in the bearing well. Now remove the platter from the foam. Gently, and carefully place the platter onto the spindle with the brass weights facing down. You may now thread the second smaller piece of the spindle into the main spindle in the center of the platter. Use the small Allen wrench to gently clamp down on the platter by inserting it into the small hole in the side, at the top of the spindle. -
Page 8: Specifications
Operating conditions Once you have connected the power supply cable to an AC current power plug as well as the cable supplied with the tonearm that you will previously have installed and connected, your BELLAVISTA will be ready to use. PLEASE NOTE.: Check that the correct acceptance voltage is indicated on your turntable. -
Page 9: Customer Service
The warranty certificate is enclosed separately and to be valid must be completed fill and returned to Bluenote factory or the official distribution. In all countries where there is an official distribution network, the dealer must stamp the warranty certificate. In compliance with the laws in force, the dealer may modify the official Bluenote warranty certificate wholly or partially without notice and without further mention being made in this instruction manual. -
Page 10: Troubleshooting
Bellavista Italian Prestige Rigid Turntable Troubleshooting SYNPTOM DESCRIPTION CAUSE REMEDY • • BELT NOISE DURING The Green Belt makes a Because its low elasticity and If a quieter belt is requested PLAY (GREEN BELT) noise during playing the presence of ceramic particles the ask your local dealer for one of the characteristics of the green belt make it newest Bluenote Black Rubber Belts... -
Page 11: Troubleshooting
one needs to be tighten more. Be careful not to tight the hex bolts to much, the pulley threaded hex bolt holes could be damaged • • SPEED VARIATIONS The turntable speed vary [The AC synchronous motors Any speed variation with a up and down continuously speeds can be affected only by the fixed pulley dimension is caused by your... - Page 12 • • The electrical connection inside Contact your dealer the turntable could be damaged assistance • • When turntable The Belt is too slack and does switched on it does not not produce the necessary friction with start automatically and the the pulley motor makes a vibration •...
-
Page 13: F.a.q. & Adjustment
then once all the other adjustment are properly set fix well, but not too tighten all the 3 hex bolts • • CLEANING THE TURNTABLE The Turntable is dirty and needs With EXTREME care use ONLY pure alcohol to be cleaned and a very soft 100% cotton cloth to sweep dust and stains out.
